針對CCTV攝像頭的掃描爆破工具 ：Cameradar
- 可以檢測任何可訪問的目標設備并掃描出開放的RTSP主機，
- 檢測正在傳輸監控資料的設備型號，
- 內置字典自動化滲透爆破賬號密碼和目標流路徑，
- 可以很方便的批量檢測攝像頭設備的弱口令，
- 可以自定義爆破的賬密字典和目標流路徑，可以檢測的不同的攝像頭設備來改變字典，
[root@localhost docker_test]# uname -a Linux bogon 3.10.0-862.el7.x86_64 #1 SMP Fri Apr 20 16:44:24 UTC 2018 x86_64 x86_64 x86_64 GNU/Linux [root@localhost docker_test]#一、使用yum包管理器將軟體包升級到最新，
[root@localhost docker_test]# yum update Loaded plugins: fastestmirror, langpacks Determining fastest mirrors * base: mirrors.huaweicloud.com * extras: mirrors.tuna.tsinghua.edu.cn * updates: mirrors.huaweicloud.com base | 3.6 kB 00:00 extras | 2.9 kB 00:00 updates | 2.9 kB 00:00 (1/4): base/7/x86_64/group_gz | 165 kB 00:00 (2/4): extras/7/x86_64/primary_db | 153 kB 00:00 (3/4): updates/7/x86_64/primary_db | 2.8 MB 00:01 (4/4): base/7/x86_64/primary_db | 6.0 MB 00:02二、安裝相關依賴，（這里已經安裝過了）
[root@localhost docker_test]# yum install -y yum-utils device-mapper-persistent-data lvm2 Loaded plugins: fastestmirror, langpacks Loading mirror speeds from cached hostfile * base: mirrors.huaweicloud.com * extras: mirrors.tuna.tsinghua.edu.cn * updates: mirrors.huaweicloud.com Package yum-utils-1.1.31-52.el7.noarch already installed and latest version Package device-mapper-persistent-data-0.8.5-1.el7.x86_64 already installed and latest version Package 7:lvm2-2.02.185-2.el7_7.2.x86_64 already installed and latest version Nothing to do三、添加docker的yum源， 這里安裝的是docker社區免費版，
[root@localhost docker_test]# yum install docker-ce Loaded plugins: fastestmirror, langpacks Loading mirror speeds from cached hostfile * base: mirrors.huaweicloud.com * extras: mirrors.tuna.tsinghua.edu.cn * updates: mirrors.huaweicloud.com No package docker-ce available. Error: Nothing to do [root@localhost docker_test]#
在CentOS7.0上默認的源中沒有docker的資源，（我這里安裝的epel-release的源里也沒有docker資源）
[root@localhost yum.repos.d]# pwd /etc/yum.repos.d [root@localhost yum.repos.d]# ls CentOS-Base.repo CentOS-fasttrack.repo CentOS-Vault.repo CentOS-CR.repo CentOS-Media.repo epel.repo CentOS-Debuginfo.repo CentOS-Sources.repo epel-testing.repo
添加docker源，（可以看到添加docker源后，增加了一個yum源檔案docker-ce.repo）
[root@localhost yum.repos.d]# yum-config-manager --add-repo https://download.docker.com/linux/centos/docker-ce.repo Loaded plugins: fastestmirror, langpacks adding repo from: https://download.docker.com/linux/centos/docker-ce.repo grabbing file https://download.docker.com/linux/centos/docker-ce.repo to /etc/yum.repos.d/docker-ce.repo repo saved to /etc/yum.repos.d/docker-ce.repo [root@localhost yum.repos.d]# ls CentOS-Base.repo CentOS-fasttrack.repo CentOS-Vault.repo epel-testing.repo CentOS-CR.repo CentOS-Media.repo docker-ce.repo CentOS-Debuginfo.repo CentOS-Sources.repo epel.repo [root@localhost yum.repos.d]#
查看倉庫中所有docker版本，
[root@localhost yum.repos.d]# yum list docker-ce --showduplicates | sort -r * updates: mirrors.huaweicloud.com Loading mirror speeds from cached hostfile Loaded plugins: fastestmirror, langpacks * extras: mirrors.tuna.tsinghua.edu.cn * epel: mirrors.tuna.tsinghua.edu.cn docker-ce.x86_64 3:19.03.4-3.el7 docker-ce-stable docker-ce.x86_64 3:19.03.3-3.el7 docker-ce-stable docker-ce.x86_64 3:19.03.2-3.el7 docker-ce-stable docker-ce.x86_64 3:19.03.1-3.el7 docker-ce-stable . . .
安裝docker社區免費版，
[root@localhost yum.repos.d]# yum install docker-ce Loaded plugins: fastestmirror, langpacks Loading mirror speeds from cached hostfile * base: mirrors.huaweicloud.com * epel: mirrors.tuna.tsinghua.edu.cn * extras: mirrors.tuna.tsinghua.edu.cn * updates: mirrors.huaweicloud.com Resolving Dependencies --> Running transaction check ---> Package docker-ce.x86_64 3:19.03.4-3.el7 will be installed --> Processing Dependency: container-selinux >= 2:2.74 for package: 3:docker-ce-19.03.4-3.el7.x86_64 --> Processing Dependency: containerd.io >= 1.2.2-3 for package: 3:docker-ce-19.03.4-3.el7.x86_64 --> Processing Dependency: docker-ce-cli for package: 3:docker-ce-19.03.4-3.el7.x86_64 --> Running transaction check ---> Package container-selinux.noarch 2:2.107-3.el7 will be installed ---> Package containerd.io.x86_64 0:1.2.10-3.2.el7 will be installed ---> Package docker-ce-cli.x86_64 1:19.03.4-3.el7 will be installed --> Finished Dependency Resolution Dependencies Resolved ======================================================================================= Package Arch Version Repository Size ======================================================================================= Installing: docker-ce x86_64 3:19.03.4-3.el7 docker-ce-stable 24 M Installing for dependencies: container-selinux noarch 2:2.107-3.el7 extras 39 k containerd.io x86_64 1.2.10-3.2.el7 docker-ce-stable 23 M docker-ce-cli x86_64 1:19.03.4-3.el7 docker-ce-stable 39 M Transaction Summary ======================================================================================= Install 1 Package (+3 Dependent packages) Total download size: 87 M Installed size: 362 M
查看docker版本，啟動docker
[root@localhost yum.repos.d]# docker version Client: Docker Engine - Community Version: 19.03.4 API version: 1.40 Go version: go1.12.10 Git commit: 9013bf583a Built: Fri Oct 18 15:52:22 2019 OS/Arch: linux/amd64 Experimental: false Cannot connect to the Docker daemon at unix:///var/run/docker.sock. Is the docker daemon running?
啟動docker
[root@localhost yum.repos.d]# systemctl start docker [root@localhost yum.repos.d]# systemctl status docker ● docker.service - Docker Application Container Engine Loaded: loaded (/usr/lib/systemd/system/docker.service; disabled; vendor preset: disabled) Active: active (running) since Fri 2019-11-08 03:31:55 EST; 32s ago Docs: https://docs.docker.com Main PID: 1188 (dockerd) Tasks: 8 Memory: 99.4M CGroup: /system.slice/docker.service └─1188 /usr/bin/dockerd -H fd:// --containerd=/run/containerd/containerd.sock Nov 08 03:31:54 bogon dockerd[1188]: time="2019-11-08T03:31:54.384116486-05:00" level=info msg="ccResolverWrapper: s...e=grpc Nov 08 03:31:54 bogon dockerd[1188]: time="2019-11-08T03:31:54.384130527-05:00" level=info msg="ClientConn switching...e=grpc Nov 08 03:31:54 bogon dockerd[1188]: time="2019-11-08T03:31:54.416778226-05:00" level=info msg="[graphdriver] using ...rlay2" Nov 08 03:31:54 bogon dockerd[1188]: time="2019-11-08T03:31:54.420853788-05:00" level=info msg="Loading containers: start." Nov 08 03:31:55 bogon dockerd[1188]: time="2019-11-08T03:31:55.048703993-05:00" level=info msg="Default bridge (dock...dress" Nov 08 03:31:55 bogon dockerd[1188]: time="2019-11-08T03:31:55.312303083-05:00" level=info msg="Loading containers: done." Nov 08 03:31:55 bogon dockerd[1188]: time="2019-11-08T03:31:55.357432633-05:00" level=info msg="Docker daemon" commi...9.03.4 Nov 08 03:31:55 bogon dockerd[1188]: time="2019-11-08T03:31:55.357497299-05:00" level=info msg="Daemon has completed...ation" Nov 08 03:31:55 bogon dockerd[1188]: time="2019-11-08T03:31:55.394993466-05:00" level=info msg="API listen on /var/r....sock" Nov 08 03:31:55 bogon systemd[1]: Started Docker Application Container Engine. Hint: Some lines were ellipsized, use -l to show in full. [root@localhost yum.repos.d]#0x03工具使用 將docker鏡像pull下來，
[root@localhost yum.repos.d]# docker pull ullaakut/cameradar Using default tag: latest latest: Pulling from ullaakut/cameradar 9d48c3bd43c5: Pull complete cc7766bf8751: Pull complete a497a345880d: Pull complete 919b21ac9ea0: Pull complete 3f9aebbc778b: Pull complete Digest: sha256:04bbc19c486584ccc12d8bca2bd07e24bb859b63c44e07c0c17e940ec8badc75 Status: Downloaded newer image for ullaakut/cameradar:latest查看本地下載下來的鏡像
[root@localhost yum.repos.d]# docker images REPOSITORY TAG IMAGE ID CREATED SIZE ullaakut/cameradar latest fe268aaf499c 5 weeks ago 68.8MB hello-world latest fce289e99eb9 10 months ago 1.84kB [root@localhost yum.repos.d]#
具體使用方法
1、使用工具掃描單個攝像頭設備： docker run ullaakut/cameradar --targets=“ip”
2、自定義掃描埠：
docker run ullaakut/cameradar --targets=“ip" --ports="554,5554,8554“
3、自定掃描的掃描使用的賬密的字典和路由字典，
用法： docker run -t -v /my/folder/with/dictionaries:/tmp/dictionaries \ ullaakut/cameradar \ -r "/tmp/dictionaries/my_routes" \ -c "/tmp/dictionaries/my_credentials.json" \ -t 172.19.124.0/24正常情況下，工具會加載docker容器中默認的賬密字典和路由字典
[root@localhost ~]# docker run ullaakut/cameradar -t192.168.64.128 Loading credentials...ok > Loading credentials dictionary from path "/app/dictionaries/credentials.json" > Loaded 14 usernames and 32 passwords Loading routes...ok > Loading routes dictionary from path "/app/dictionaries/routes" > Loaded 182 routes Scanning the network...ok > Found 0 RTSP streams ? unable to attack empty list of targets
我們可以查看該工具的源檔案，可以看到它的密碼只有 賬密字典中有14個用戶名和32個密碼，路徑字典中有182個路徑，
[root@localhost cameradar]# ls attack.go cmd Dockerfile helpers.go LICENSE README.md scan_test.go attack_test.go curl.go examples helpers_test.go loaders.go scan.go summary.go cameradar.go curl_test.go go.mod images loaders_test.go scanner.go summary_test.go CHANGELOG.md dictionaries go.sum ISSUE_TEMPLATE.md models.go scanner_test.go tools [root@localhost cameradar]# cd dictionaries/ [root@localhost dictionaries]# ls credentials.json routes [root@localhost dictionaries]# head credentials.json { "usernames": [ "", "666666", "888888", "Admin", "admin", "admin1", "administrator", "Administrator", [root@localhost dictionaries]# head routes /live/ch01_0 0/1:1/main 0/usrnm:pwd/main 0/video1 1 1.AMP 1/h264major 1/stream1 11我們在本機新建自己的賬密檔案（使用陣列的形式存盤賬密字典）
[root@localhost tools]# ls my_credentials.json my_routes [root@localhost tools]# vim my_credentials.json { "usernames": [ "", "666666", "888888", "Admin", "admin", "admin1", "administrator", "Administrator", "aiphone", "Dinion", "root", "service", "supervisor", "ubnt", "test", "ciby", "hello" ], "passwords": [ "", "111111", "1111111", "1234", "12345", "123456", "12345678", "4321", "666666", "888888", "9999", "admin", "administrator", "aiphone", "camera", "fliradmin", "hikvision", "hikadmin", "ikwd", "jvc", "meinsm", "pass", "password", "reolink", "root", "service", "supervisor", "system", "toor", "tp-link", "ubnt", "wbox123", "test.com", "test1.com", "123.com" ] } [root@localhost tools]# head my_routes /live/ch01_0 0/1:1/main 0/usrnm:pwd/main 0/video1 1 1.AMP 1/h264major 1/stream1 11
將我們本機的字典掛在到容器中，然后使用-c -r 引數來呼叫自定義的字典，
[root@localhost tools]# docker run -t -v /home/docker_test/tools:/tmp ullaakut/cameradar -c "/tmp/my_credentials.json" -r "/tmp/my_routes" -t 192.168.64.128 Loading credentials...ok > Loading credentials dictionary from path "/tmp/my_credentials.json" > Loaded 17 usernames and 35 passwords Loading routes...ok > Loading routes dictionary from path "/tmp/my_routes" > Loaded 182 routes Scanning the network...ok > Found 0 RTSP streams ? unable to attack empty list of targets4、批量掃描檔案中的目標IP（這里IP可以有多種格式）
[root@localhost tools]# docker run -t -v /home/docker_test/tools:/tmp ullaakut/cameradar -c "/tmp/my_credentials.json" -r "/tmp/my_routes" -t "/home/docker_test/tools/target.txt" Loading credentials...ok > Loading credentials dictionary from path "/tmp/my_credentials.json" > Loaded 17 usernames and 35 passwords Loading routes...ok > Loading routes dictionary from path "/tmp/my_routes" > Loaded 182 routes Scanning the network...ko ? error while scanning network: Unable to split netmask from target expression: "/home/docker_test/tools/target.txt" WARNING: No targets were specified, so 0 hosts scanned
（這里報錯了，未能拆分網路掩碼，不懂go語言暫未解決）
可以掃C段：[root@localhost tools]# docker run -t -v /home/docker_test/tools:/tmp ullaakut/cameradar -c "/tmp/my_credentials.json" -r "/tmp/my_routes" -t 192.168.64.0/24 Loading credentials...ok > Loading credentials dictionary from path "/tmp/my_credentials.json" > Loaded 17 usernames and 35 passwords Loading routes...ok > Loading routes dictionary from path "/tmp/my_routes" > Loaded 182 routes Scanning the network...
5、其他引數
* “ -h”：顯示用法資訊 * “ -T，--2000ms timeout ”：（默認：）設定自定義超時值，在此之后應放棄沒有答案的攻擊嘗試，在嘗試掃描不穩定和慢速的網路時，建議增加該值；在快速可靠的網路中，建議減少該值， * “ -d，-- debug ”：啟用除錯日志 * “ -v，-- verbose ”：啟用詳細的curl日志（不推薦用于大多數用途） “ -s，--scan-speed”：（默認：）4設定自定義nmap發現預設以提高速度或準確性，如果您嘗試掃描不穩定和慢速的網路，建議降低它，如果在性能良好且可靠的網路上，則建議增加它，您可能還希望將其保持在較低水平，以使發現變得隱秘，
參考鏈接： https://github.com/Ullaakut/cameradar https://blog.csdn.net/enter89/article/details/90295701 https://mp.weixin.qq.com/s/qB8IFgLPbgY0qQz5UO0Gsg https://www.cnblogs.com/qgc1995/archive/2018/08/29/9553572.html https://www.freebuf.com/sectool/150254.html https://www.cnblogs.com/ECJTUACM-873284962/p/9789130.html
