開始今天的文章吧，這篇文章實作了一個簡單的 RPC 遠程呼叫，在實作之前需要先了解什么是 RPC，不清楚的可以看下之前發的這篇文章 《我眼中的 RPC》，
下面的演示代碼主要使用了 Swoole 的 Task 任務池，通過 OnRequest/OnReceive 獲得資訊交給 Task 去處理，
舉個作業中的例子吧，在電商系統中的兩個模塊，個人中心模塊和訂單管理模塊，這兩個模塊是獨立部署的，可能不在一個機房，可能不是一個域名，現在個人中心需要通過 用戶ID 和 訂單型別 獲取訂單資料，
實作效果
客戶端
HTTP 請求
//代碼片段
<?php
$demo = [
'type' => 'SW',
'token' => 'Bb1R3YLipbkTp5p0',
'param' => [
'class' => 'Order',
'method' => 'get_list',
'param' => [
'uid' => 1,
'type' => 2,
],
],
];
$ch = curl_init();
$options = [
CURLOPT_URL => 'http://10.211.55.4:9509/',
CURLOPT_POST => 1,
CURLOPT_POSTFIELDS => json_encode($demo),
];
curl_setopt_array($ch, $options);
curl_exec($ch);
curl_close($ch);
TCP 請求
//代碼片段
$demo = [
'type' => 'SW',
'token' => 'Bb1R3YLipbkTp5p0',
'param' => [
'class' => 'Order',
'method' => 'get_list',
'param' => [
'uid' => 1,
'type' => 2,
],
],
];
$this->client->send(json_encode($demo));
請求方式
SW 單個請求，等待結果
發出請求后，分配給 Task ，并等待 Task 執行完成后，再回傳，
SN 單個請求，不等待結果
發出請求后，分配給 Task 之后，就直接回傳，
發送資料
$demo = [
'type' => 'SW',
'token' => 'Bb1R3YLipbkTp5p0',
'param' => [
'class' => 'Order',
'method' => 'get_list',
'param' => [
'uid' => 1,
'type' => 2,
],
],
];
type 同步/異步設定
token 可進行權限驗證
class 請求的類名
method 請求的方法名
uid 引數一
type 引數二
回傳資料
request_method 請求方式
request_time 請求開始時間
response_time 請求結束時間
code 標識
msg 標識值
data 約定資料
query 請求引數
代碼
OnRequest.php
<?php
if (!defined('SERVER_PATH')) exit("No Access");
class OnRequest
{
private static $query;
private static $code;
private static $msg;
private static $data;
public static function run($serv, $request, $response)
{
try {
$data = https://www.cnblogs.com/it-3327/p/decrypt($request->rawContent());
self::$query = $data;
if (empty($data)) {
self::$code ='-1';
self::$msg = '非法請求';
self::end($request, $response);
}
//TODO 驗證Token
switch ($data['type']) {
case 'SW': //單個請求,等待結果
$task = [
'request' => $data,
'server' => 'http'
];
$rs = $serv->task(json_encode($task), -1, function ($serv, $task_id, $rs_data) use ($request, $response) {
self::$code = '1';
self::$msg = '成功';
self::$data = https://www.cnblogs.com/it-3327/p/$rs_data['response'];
self::end($request, $response);
});
if ($rs === false) {
self::$code = '-1';
self::$msg = '失敗';
self::end($request, $response);
}
break;
case 'SN': //單個請求,不等待結果
$task = [
'request' => $data,
'server' => 'http'
];
$rs = $serv->task(json_encode($task));
if ($rs === false) {
self::$code = '-1';
self::$msg = '失敗';
} else {
self::$code = '1';
self::$msg = '成功';
}
self::end($request, $response);
break;
default:
self::$code = '-1';
self::$msg = '非法請求';
self::end($request, $response);
}
} catch(Exception $e) {
}
}
private static function end($request = null, $response = null)
{
$rs['request_method'] = $request->server['request_method'];
$rs['request_time'] = $request->server['request_time'];
$rs['response_time'] = time();
$rs['code'] = self::$code;
$rs['msg'] = self::$msg;
$rs['data'] = self::$data;
$rs['query'] = self::$query;
$response->end(json_encode($rs));
self::$data = https://www.cnblogs.com/it-3327/p/[];
return;
}
}
這里我還準備了一分學習圖和資料，如下：
鏈接：https://pan.baidu.com/s/1v5gm7n0L7TGyejCmQrMh2g 提取碼：x2p5
免費分享，但是X度限制嚴重，如若鏈接失效點擊鏈接或搜索加群 群號518475424，
OnReceive.php
<?php
if (!defined('SERVER_PATH')) exit("No Access");
class OnReceive
{
private static $request_time;
private static $query;
private static $code;
private static $msg;
private static $data;
public static function run($serv, $fd, $reactor_id, $data)
{
try {
self::$request_time = time();
$data = https://www.cnblogs.com/it-3327/p/decrypt($data);
self::$query = $data;
//TODO 驗證Token
switch ($data['type']) {
case 'SW': //單個請求,等待結果
$task = [
'fd' => $fd,
'request' => $data,
'server' => 'tcp',
'request_time' => self::$request_time,
];
$rs = $serv->task(json_encode($task));
if ($rs === false) {
self::$code = '-1';
self::$msg = '失敗';
self::handlerTask($serv, $fd);
}
break;
case 'SN': //單個請求,不等待結果
$task = [
'fd' => $fd,
'request' => $data,
'server' => 'tcp',
'request_time' => self::$request_time,
];
$rs = $serv->task(json_encode($task));
if ($rs === false) {
self::$code = '-1';
self::$msg = '失敗';
} else {
self::$code = '1';
self::$msg = '成功';
}
self::handlerTask($serv, $fd);
break;
default:
self::$code = '-1';
self::$msg = '非法請求';
self::handlerTask($serv, $fd);
}
} catch(Exception $e) {
}
}
private static function handlerTask($serv, $fd)
{
$rs['request_method'] = 'TCP';
$rs['request_time'] = self::$request_time;
$rs['response_time'] = time();
$rs['code'] = self::$code;
$rs['msg'] = self::$msg;
$rs['data'] = self::$data;
$rs['query'] = self::$query;
$serv->send($fd, json_encode($rs));
}
}
轉載請註明出處，本文鏈接：https://www.uj5u.com/houduan/119133.html
