原始碼分析:Spring是如何把Bean注冊到IOC容器中的?

2020-09-28 19:39:16 後端開發

前言

提到Spring就會想到IOC、DI等概念,這是Spring的核心思想,只要使用過Spring框架的人都知道這些概念,但要問到Spring具體是怎么實作IOC的,恐怕只能看Spring的原始碼才能找到答案,在我看來只要搞清楚兩個問題,就能對Spring的整體脈絡有個整體的認識

  • Bean是如何注冊到IOC注冊中的?
  • Bean是如何從IOC容器中get出來的?

一個簡單的例子

我們先從一個簡單的例子開始,基本上在最開始學習Spring的時候都會從xml配置開始,把你需要交給Spring管理的類配置到xml檔案中,你就可以不用管物件的創建了,下面來看一下代碼

1、首先定義一個User類

@Data
public class User {
    private String userName;
    private String password;
}

很簡單的一個JavaBean

2、增加一個xml配置

<?xml version="1.0" encoding="UTF-8"?>
<beans xmlns="http://www.springframework.org/schema/beans"
       xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
       xsi:schemaLocation="http://www.springframework.org/schema/beans http://www.springframework.org/schema/beans/spring-beans.xsd">
    <bean id="userBean" class="org.kxg.springDemo.User">
        <property name="userName" value="jack" />
        <property name="password" value="123456" />
    </bean>

</beans>

3、讀取配置,并運行

public class XmlBeanTest {
    public static void main(String[] args){
        ClassPathXmlApplicationContext applicationContext = new ClassPathXmlApplicationContext("bean.xml");
        User user = (User) applicationContext.getBean("userBean");
        System.out.println(user.getUserName());
    }
}

可以看到例子很簡單,堪稱Spring入門的HelloWorld

從上面幾行代碼可以看出,首先讀取bean.xml中的配置,然后就可以從applicationContext中獲取到User物件,那么肯定會有User物件注冊到IOC容器中這個步驟

下面我們一起通過原始碼來看一下Bean是如何注冊到Spring IOC容器中的

原始碼決議

從ClassPathXmlApplicationContext開始

public ClassPathXmlApplicationContext(String configLocation) throws BeansException {
		this(new String[] {configLocation}, true, null);
	}

public ClassPathXmlApplicationContext(String... configLocations) throws BeansException {
	this(configLocations, true, null);
}

從ClassPathXmlApplicationContext的構造方法入手,構造方法傳入xml組態檔的路徑,這里可以傳入單個或多個組態檔

public ClassPathXmlApplicationContext(
			String[] configLocations, boolean refresh, @Nullable ApplicationContext parent)
			throws BeansException {

		super(parent);
		//將傳入的xml配置位置資訊設定到configLocations
		setConfigLocations(configLocations);
		if (refresh) {
		    //核心方法
			refresh();
		}
	}

這里看到,我們傳入的組態檔設定到configLocations,然后呼叫了一個Spring最核心的方法refresh(),這個方法包括了容器啟動的所有內容,是我們學習Spring原始碼的一個入口,可以說你只要把這個方法里面的內容研究清楚了,對于Spring框架的整個脈絡會有一個全新的認識,下面我們來看看這個方法里面有些什么

public void refresh() throws BeansException, IllegalStateException {
		synchronized (this.startupShutdownMonitor) {
			// Prepare this context for refreshing.
			prepareRefresh();

			// 注意看這個方法
			ConfigurableListableBeanFactory beanFactory = obtainFreshBeanFactory();

			// Prepare the bean factory for use in this context.
			prepareBeanFactory(beanFactory);

			try {
				// Allows post-processing of the bean factory in context subclasses.
				postProcessBeanFactory(beanFactory);

				// Invoke factory processors registered as beans in the context.
				invokeBeanFactoryPostProcessors(beanFactory);

				// Register bean processors that intercept bean creation.
				registerBeanPostProcessors(beanFactory);

				// Initialize message source for this context.
				initMessageSource();

				// Initialize event multicaster for this context.
				initApplicationEventMulticaster();

				// Initialize other special beans in specific context subclasses.
				onRefresh();

				// Check for listener beans and register them.
				registerListeners();

				// Instantiate all remaining (non-lazy-init) singletons.
				finishBeanFactoryInitialization(beanFactory);

				// Last step: publish corresponding event.
				finishRefresh();
			}

			catch (BeansException ex) {
				if (logger.isWarnEnabled()) {
					logger.warn("Exception encountered during context initialization - " +
							"cancelling refresh attempt: " + ex);
				}

				// Destroy already created singletons to avoid dangling resources.
				destroyBeans();

				// Reset 'active' flag.
				cancelRefresh(ex);

				// Propagate exception to caller.
				throw ex;
			}

			finally {
				// Reset common introspection caches in Spring's core, since we
				// might not ever need metadata for singleton beans anymore...
				resetCommonCaches();
			}
		}
	}

refresh()方法里面的內容很豐富,從各個方法名稱就大致可以看出來其作用,這里我們主要看Bean注冊的程序,將目光聚焦到

ConfigurableListableBeanFactory beanFactory = obtainFreshBeanFactory();

這一行是獲取BeanFactory,里面進行了Bean的注冊邏輯

protected ConfigurableListableBeanFactory obtainFreshBeanFactory() {
		refreshBeanFactory();
		return getBeanFactory();
	}

這里呼叫的是AbstractRefreshableApplicationContext類的refreshBeanFactory()方法,需要注意一下在看Spring原始碼的時候,同一個方法可能會有多個子類都實作了,需要注意區分一下,你當前實體化的是哪個子類

protected final void refreshBeanFactory() throws BeansException {
		if (hasBeanFactory()) {
			destroyBeans();
			closeBeanFactory();
		}
		try {
		    //創建一個BeanFactory
			DefaultListableBeanFactory beanFactory = createBeanFactory();
			beanFactory.setSerializationId(getId());
			customizeBeanFactory(beanFactory);
			//這里進行Bean的加載
			loadBeanDefinitions(beanFactory);
			synchronized (this.beanFactoryMonitor) {
				this.beanFactory = beanFactory;
			}
		}
		catch (IOException ex) {
			throw new ApplicationContextException("I/O error parsing bean definition source for " + getDisplayName(), ex);
		}
	}

因為我們使用的是xml的配置,所以這里呼叫的是AbstractXmlApplicationContext這個抽象類中的loadBeanDefinitions方法

protected void loadBeanDefinitions(DefaultListableBeanFactory beanFactory) throws BeansException, IOException {
		// 構造一個XmlBeanDefinitionReader,用于讀到xml中配置的bean
		XmlBeanDefinitionReader beanDefinitionReader = new XmlBeanDefinitionReader(beanFactory);

		// 配置XmlBeanDefinitionReader
		beanDefinitionReader.setEnvironment(this.getEnvironment());
		beanDefinitionReader.setResourceLoader(this);
		beanDefinitionReader.setEntityResolver(new ResourceEntityResolver(this));

		//初始化XmlBeanDefinitionReader
		initBeanDefinitionReader(beanDefinitionReader);
		//加載Bean
		loadBeanDefinitions(beanDefinitionReader);
	}
protected void loadBeanDefinitions(XmlBeanDefinitionReader reader) throws BeansException, IOException {
		Resource[] configResources = getConfigResources();
		if (configResources != null) {
			reader.loadBeanDefinitions(configResources);
		}
		String[] configLocations = getConfigLocations();
		if (configLocations != null) {
			reader.loadBeanDefinitions(configLocations);
		}
	}

這里進行了兩種不同方式的加載,呼叫的是不同的方法,我們傳入的是configLocations

@Override
public int loadBeanDefinitions(String... locations) throws BeanDefinitionStoreException {
	Assert.notNull(locations, "Location array must not be null");
	int count = 0;
	for (String location : locations) {
		count += loadBeanDefinitions(location);
	}
	return count;
}
	public int loadBeanDefinitions(String location, @Nullable Set<Resource> actualResources) throws BeanDefinitionStoreException {
		ResourceLoader resourceLoader = getResourceLoader();
		if (resourceLoader == null) {
			throw new BeanDefinitionStoreException(
					"Cannot load bean definitions from location [" + location + "]: no ResourceLoader available");
		}

		if (resourceLoader instanceof ResourcePatternResolver) {
			// Resource pattern matching available.
			try {
				Resource[] resources = ((ResourcePatternResolver) resourceLoader).getResources(location);
				int count = loadBeanDefinitions(resources);
				if (actualResources != null) {
					Collections.addAll(actualResources, resources);
				}
				if (logger.isTraceEnabled()) {
					logger.trace("Loaded " + count + " bean definitions from location pattern [" + location + "]");
				}
				return count;
			}
			catch (IOException ex) {
				throw new BeanDefinitionStoreException(
						"Could not resolve bean definition resource pattern [" + location + "]", ex);
			}
		}
		else {
			// Can only load single resources by absolute URL.
			Resource resource = resourceLoader.getResource(location);
			int count = loadBeanDefinitions(resource);
			if (actualResources != null) {
				actualResources.add(resource);
			}
			if (logger.isTraceEnabled()) {
				logger.trace("Loaded " + count + " bean definitions from location [" + location + "]");
			}
			return count;
		}
	}

這個里面主要方法是loadBeanDefinitions(),我們繼續往下走

中間省略了一些簡單呼叫

public int loadBeanDefinitions(EncodedResource encodedResource) throws BeanDefinitionStoreException {
		Assert.notNull(encodedResource, "EncodedResource must not be null");
		if (logger.isTraceEnabled()) {
			logger.trace("Loading XML bean definitions from " + encodedResource);
		}

		Set<EncodedResource> currentResources = this.resourcesCurrentlyBeingLoaded.get();
		if (currentResources == null) {
			currentResources = new HashSet<>(4);
			this.resourcesCurrentlyBeingLoaded.set(currentResources);
		}
		if (!currentResources.add(encodedResource)) {
			throw new BeanDefinitionStoreException(
					"Detected cyclic loading of " + encodedResource + " - check your import definitions!");
		}
		try {
			InputStream inputStream = encodedResource.getResource().getInputStream();
			try {
				InputSource inputSource = new InputSource(inputStream);
				if (encodedResource.getEncoding() != null) {
					inputSource.setEncoding(encodedResource.getEncoding());
				}
				//進行BeanDefinations加載
				return doLoadBeanDefinitions(inputSource, encodedResource.getResource());
			}
			finally {
				inputStream.close();
			}
		}
		catch (IOException ex) {
			throw new BeanDefinitionStoreException(
					"IOException parsing XML document from " + encodedResource.getResource(), ex);
		}
		finally {
			currentResources.remove(encodedResource);
			if (currentResources.isEmpty()) {
				this.resourcesCurrentlyBeingLoaded.remove();
			}
		}
	}
protected int doLoadBeanDefinitions(InputSource inputSource, Resource resource)
			throws BeanDefinitionStoreException {

		try {
		    //構造xml的Document結構,決議DOM結構
			Document doc = doLoadDocument(inputSource, resource);
			//注冊BeanDefinition
			int count = registerBeanDefinitions(doc, resource);
			if (logger.isDebugEnabled()) {
				logger.debug("Loaded " + count + " bean definitions from " + resource);
			}
			return count;
		}
		catch (BeanDefinitionStoreException ex) {
			throw ex;
		}
		catch (SAXParseException ex) {
			throw new XmlBeanDefinitionStoreException(resource.getDescription(),
					"Line " + ex.getLineNumber() + " in XML document from " + resource + " is invalid", ex);
		}
		catch (SAXException ex) {
			throw new XmlBeanDefinitionStoreException(resource.getDescription(),
					"XML document from " + resource + " is invalid", ex);
		}
		catch (ParserConfigurationException ex) {
			throw new BeanDefinitionStoreException(resource.getDescription(),
					"Parser configuration exception parsing XML from " + resource, ex);
		}
		catch (IOException ex) {
			throw new BeanDefinitionStoreException(resource.getDescription(),
					"IOException parsing XML document from " + resource, ex);
		}
		catch (Throwable ex) {
			throw new BeanDefinitionStoreException(resource.getDescription(),
					"Unexpected exception parsing XML document from " + resource, ex);
		}
	}

從上面的代碼可以看出來,Spring是將xml的DOM結構決議后注冊到IOC容器中的

public int registerBeanDefinitions(Document doc, Resource resource) throws BeanDefinitionStoreException {
		BeanDefinitionDocumentReader documentReader = createBeanDefinitionDocumentReader();
		int countBefore = getRegistry().getBeanDefinitionCount();
		documentReader.registerBeanDefinitions(doc, createReaderContext(resource));
		return getRegistry().getBeanDefinitionCount() - countBefore;
	}

這個方法構造了一個BeanDefinitionDocumentReader,進行注冊BeanDefinition,并且回傳了本次注冊Bean的數量

	protected void doRegisterBeanDefinitions(Element root) {
		// Any nested <beans> elements will cause recursion in this method. In
		// order to propagate and preserve <beans> default-* attributes correctly,
		// keep track of the current (parent) delegate, which may be null. Create
		// the new (child) delegate with a reference to the parent for fallback purposes,
		// then ultimately reset this.delegate back to its original (parent) reference.
		// this behavior emulates a stack of delegates without actually necessitating one.
		BeanDefinitionParserDelegate parent = this.delegate;
		this.delegate = createDelegate(getReaderContext(), root, parent);

		if (this.delegate.isDefaultNamespace(root)) {
			String profileSpec = root.getAttribute(PROFILE_ATTRIBUTE);
			if (StringUtils.hasText(profileSpec)) {
				String[] specifiedProfiles = StringUtils.tokenizeToStringArray(
						profileSpec, BeanDefinitionParserDelegate.MULTI_VALUE_ATTRIBUTE_DELIMITERS);
				// We cannot use Profiles.of(...) since profile expressions are not supported
				// in XML config. See SPR-12458 for details.
				if (!getReaderContext().getEnvironment().acceptsProfiles(specifiedProfiles)) {
					if (logger.isDebugEnabled()) {
						logger.debug("Skipped XML bean definition file due to specified profiles [" + profileSpec +
								"] not matching: " + getReaderContext().getResource());
					}
					return;
				}
			}
		}

		preProcessXml(root);
		//進行BeanDefinition轉換,將DOM結構的物件轉換成BeanDefinition
		parseBeanDefinitions(root, this.delegate);
		postProcessXml(root);

		this.delegate = parent;
	}
protected void parseBeanDefinitions(Element root, BeanDefinitionParserDelegate delegate) {
		if (delegate.isDefaultNamespace(root)) {
			NodeList nl = root.getChildNodes();
			for (int i = 0; i < nl.getLength(); i++) {
				Node node = nl.item(i);
				if (node instanceof Element) {
					Element ele = (Element) node;
					if (delegate.isDefaultNamespace(ele)) {
					    //Spring默認元素轉換
						parseDefaultElement(ele, delegate);
					}
					else {
					    //xml中自定義的Element進行決議
						delegate.parseCustomElement(ele);
					}
				}
			}
		}
		else {
			delegate.parseCustomElement(root);
		}
	}
private void parseDefaultElement(Element ele, BeanDefinitionParserDelegate delegate) {
		if (delegate.nodeNameEquals(ele, IMPORT_ELEMENT)) {
			importBeanDefinitionResource(ele);
		}
		else if (delegate.nodeNameEquals(ele, ALIAS_ELEMENT)) {
			processAliasRegistration(ele);
		}
		else if (delegate.nodeNameEquals(ele, BEAN_ELEMENT)) {
			processBeanDefinition(ele, delegate);
		}
		else if (delegate.nodeNameEquals(ele, NESTED_BEANS_ELEMENT)) {
			// recurse
			doRegisterBeanDefinitions(ele);
		}
	}

可以看到xml中默認的配置元素包括import、alias、bean、beans,這些也是最常用的,我們主要看一個bean的轉換

protected void processBeanDefinition(Element ele, BeanDefinitionParserDelegate delegate) {
		BeanDefinitionHolder bdHolder = delegate.parseBeanDefinitionElement(ele);
		if (bdHolder != null) {
			bdHolder = delegate.decorateBeanDefinitionIfRequired(ele, bdHolder);
			try {
				// Register the final decorated instance.
				BeanDefinitionReaderUtils.registerBeanDefinition(bdHolder, getReaderContext().getRegistry());
			}
			catch (BeanDefinitionStoreException ex) {
				getReaderContext().error("Failed to register bean definition with name '" +
						bdHolder.getBeanName() + "'", ele, ex);
			}
			// Send registration event.
			getReaderContext().fireComponentRegistered(new BeanComponentDefinition(bdHolder));
		}
	}
public static void registerBeanDefinition(
			BeanDefinitionHolder definitionHolder, BeanDefinitionRegistry registry)
			throws BeanDefinitionStoreException {

		// Register bean definition under primary name.
		String beanName = definitionHolder.getBeanName();
		//注冊BeanDefinition
		registry.registerBeanDefinition(beanName, definitionHolder.getBeanDefinition());

		// Register aliases for bean name, if any.
		String[] aliases = definitionHolder.getAliases();
		if (aliases != null) {
			for (String alias : aliases) {
				registry.registerAlias(beanName, alias);
			}
		}
	}
// DefaultListableBeanFactory
public void registerBeanDefinition(String beanName, BeanDefinition beanDefinition)
			throws BeanDefinitionStoreException {

		Assert.hasText(beanName, "Bean name must not be empty");
		Assert.notNull(beanDefinition, "BeanDefinition must not be null");

		if (beanDefinition instanceof AbstractBeanDefinition) {
			try {
				((AbstractBeanDefinition) beanDefinition).validate();
			}
			catch (BeanDefinitionValidationException ex) {
				throw new BeanDefinitionStoreException(beanDefinition.getResourceDescription(), beanName,
						"Validation of bean definition failed", ex);
			}
		}

		BeanDefinition existingDefinition = this.beanDefinitionMap.get(beanName);
		if (existingDefinition != null) {
			if (!isAllowBeanDefinitionOverriding()) {
				throw new BeanDefinitionOverrideException(beanName, beanDefinition, existingDefinition);
			}
			else if (existingDefinition.getRole() < beanDefinition.getRole()) {
				// e.g. was ROLE_APPLICATION, now overriding with ROLE_SUPPORT or ROLE_INFRASTRUCTURE
				if (logger.isInfoEnabled()) {
					logger.info("Overriding user-defined bean definition for bean '" + beanName +
							"' with a framework-generated bean definition: replacing [" +
							existingDefinition + "] with [" + beanDefinition + "]");
				}
			}
			else if (!beanDefinition.equals(existingDefinition)) {
				if (logger.isDebugEnabled()) {
					logger.debug("Overriding bean definition for bean '" + beanName +
							"' with a different definition: replacing [" + existingDefinition +
							"] with [" + beanDefinition + "]");
				}
			}
			else {
				if (logger.isTraceEnabled()) {
					logger.trace("Overriding bean definition for bean '" + beanName +
							"' with an equivalent definition: replacing [" + existingDefinition +
							"] with [" + beanDefinition + "]");
				}
			}
			//將beanDefinition放入beanDefinitionMap中
			this.beanDefinitionMap.put(beanName, beanDefinition);
		}
		else {
			if (hasBeanCreationStarted()) {
				// Cannot modify startup-time collection elements anymore (for stable iteration)
				synchronized (this.beanDefinitionMap) {
				    //將beanDefinition放入beanDefinitionMap中
					this.beanDefinitionMap.put(beanName, beanDefinition);
					List<String> updatedDefinitions = new ArrayList<>(this.beanDefinitionNames.size() + 1);
					updatedDefinitions.addAll(this.beanDefinitionNames);
					updatedDefinitions.add(beanName);
					this.beanDefinitionNames = updatedDefinitions;
					removeManualSingletonName(beanName);
				}
			}
			else {
				// Still in startup registration phase
				//將beanDefinition放入beanDefinitionMap中
				this.beanDefinitionMap.put(beanName, beanDefinition);
				this.beanDefinitionNames.add(beanName);
				removeManualSingletonName(beanName);
			}
			this.frozenBeanDefinitionNames = null;
		}

		if (existingDefinition != null || containsSingleton(beanName)) {
			resetBeanDefinition(beanName);
		}
	}

原始碼跟到這里,整個流程基本清楚了,最終beanDefinition存到一個beanDefinitionMap中,key為Bean的名稱,value為beanDefinition物件

private final Map<String, BeanDefinition> beanDefinitionMap = new ConcurrentHashMap<>(256);

beanDefinitionMap是一個ConcurrentHashMap,所以本質上Bean最終是被注冊到一個Map中

上面我們說了很多次beanDefinition,最后注冊到容器中的也是這個物件,那它到底是個啥物件?

A BeanDefinition describes a bean instance, which has property values,
constructor argument values, and further information supplied by
concrete implementations.

從注釋中可以看出來BeanDefinition是一個用來描述帶有屬性值、構造方法、還有一些其他進一步資訊的Bean實體(半調子英語,也不知道翻譯的對不對~)

BeanDefinition是對Bean的抽象,因為組態檔中的Bean是多種多樣的,BeanDefinition是對Bean的公共屬性進行抽象,在BeanDefinition中很多屬性是用來描述xml配置中bean的配置屬性的

所以,下面來總結一下整個流程

  • 注冊xml組態檔到configLocations
  • 呼叫refresh()進行整個Context的重繪,實際上就是整個Context的啟動
  • Bean的加載會讀到組態檔,決議成DOM物件
  • 將DOM物件轉換成beanDefinition
  • 將beanDefinition存入beanDefinitionMap,完成整個Bean的注冊

沒看明白的同學,可以對照這個流程再回頭去看看,整個流程下來還是挺清晰的

注解方式下Bean的注冊

前面我們講到xml組態檔進行Bean的注冊,xml配置是Spring早期常用的配置方式,現在基本上大部分場景上都推薦使用注解的方式,尤其是SpringBoot時代的來臨,進一步推動了注解方式的全面使用,下面我們來看看注解方式下的Bean注冊,還是從個簡單的例子入手

@Component
public class AnnotionConfig {
    @Bean(name = "userBean")
    public User getUserBean(){
        User user = new User();
        user.setUserName("Lucy");
        return user;
    }
}
public class AnnotionBeanTest {
    public static void main(String[] args){
        AnnotationConfigApplicationContext applicationContext = new AnnotationConfigApplicationContext("org.kxg.springDemo");
        User user = (User) applicationContext.getBean("userBean");
        System.out.println(user.getUserName());
    }
}

這里用到AnnotationConfigApplicationContext,是另外一種容器的實作,傳入一個包名,會自動掃描包下面的Spring注解,然后將其注冊到容器中

public AnnotationConfigApplicationContext(String... basePackages) {
		this();
		//主要是scan方法完成bean的注冊
		scan(basePackages);
		//又到了這個方法,有沒有很熟悉~~~
		refresh();
	}

下面我們重點看一下注解方式的Bean注冊

public int scan(String... basePackages) {
		int beanCountAtScanStart = this.registry.getBeanDefinitionCount();
        //掃描包,進行Bean注冊
		doScan(basePackages);

		// Register annotation config processors, if necessary.
		if (this.includeAnnotationConfig) {
			AnnotationConfigUtils.registerAnnotationConfigProcessors(this.registry);
		}

		return (this.registry.getBeanDefinitionCount() - beanCountAtScanStart);
	}
//ClassPathBeanDefinitionScanner
protected Set<BeanDefinitionHolder> doScan(String... basePackages) {
		Assert.notEmpty(basePackages, "At least one base package must be specified");
		Set<BeanDefinitionHolder> beanDefinitions = new LinkedHashSet<>();
		for (String basePackage : basePackages) {
		    //掃描包下打了注解的類,并將其轉換成BeanDefinition
			Set<BeanDefinition> candidates = findCandidateComponents(basePackage);
			for (BeanDefinition candidate : candidates) {
				ScopeMetadata scopeMetadata = this.scopeMetadataResolver.resolveScopeMetadata(candidate);
				candidate.setScope(scopeMetadata.getScopeName());
				String beanName = this.beanNameGenerator.generateBeanName(candidate, this.registry);
				if (candidate instanceof AbstractBeanDefinition) {
					postProcessBeanDefinition((AbstractBeanDefinition) candidate, beanName);
				}
				if (candidate instanceof AnnotatedBeanDefinition) {
					AnnotationConfigUtils.processCommonDefinitionAnnotations((AnnotatedBeanDefinition) candidate);
				}
				if (checkCandidate(beanName, candidate)) {
					BeanDefinitionHolder definitionHolder = new BeanDefinitionHolder(candidate, beanName);
					definitionHolder =
							AnnotationConfigUtils.applyScopedProxyMode(scopeMetadata, definitionHolder, this.registry);
					beanDefinitions.add(definitionHolder);
					//進行BeanDefinition注冊
					registerBeanDefinition(definitionHolder, this.registry);
				}
			}
		}
		return beanDefinitions;
	}
public static void registerBeanDefinition(
			BeanDefinitionHolder definitionHolder, BeanDefinitionRegistry registry)
			throws BeanDefinitionStoreException {

		// Register bean definition under primary name.
		String beanName = definitionHolder.getBeanName();
		registry.registerBeanDefinition(beanName, definitionHolder.getBeanDefinition());

		// Register aliases for bean name, if any.
		String[] aliases = definitionHolder.getAliases();
		if (aliases != null) {
			for (String alias : aliases) {
				registry.registerAlias(beanName, alias);
			}
		}
	}

看到這個方法,有沒有點眼熟的感覺

上面xml方式進行Bean注冊也呼叫到這個方法了,所以后面的流程都是一樣的,注解方式和xml配置方式從本質上來講,并沒有什么不同,只是Bean的描述不同而已,最終都會被決議成BeanDefinition,注冊到容器中,至此整個Bean的注冊流程就已經完了,

當然在整個程序中,忽略了很多細節,只看了主線流程,

讀原始碼的時候,很容易陷入細節中,尤其是像Spring這樣通用的框架,它為了通用性和擴展性,會把代碼寫的很“繞”,如果你過于關注細節很容易讓自己陷入實作的細節中,一開始看原始碼的時候,建議不用太關注細節,把主線功能先看完,知道大概的原理后再逐個去擊破~

如果感覺對你有些幫忙,請收藏好,你的關注和點贊是對我最大的鼓勵!
如果想跟我一起學習,堅信技術改變世界,請關注【Java天堂】公眾號,我會定期分享自己的學習成果,第一時間推送給您

在這里插入圖片描述

轉載請註明出處,本文鏈接:https://www.uj5u.com/houduan/135167.html

標籤:python

上一篇:Java崗7年經驗,面臨小廠58W年薪和位元組跳動的45W年薪,怎么選擇才最適合

下一篇:【總結】矩陣

標籤雲
其他(157675) Python(38076) JavaScript(25376) Java(17977) C(15215) 區塊鏈(8255) C#(7972) AI(7469) 爪哇(7425) MySQL(7132) html(6777) 基礎類(6313) sql(6102) 熊猫(6058) PHP(5869) 数组(5741) R(5409) Linux(5327) 反应(5209) 腳本語言(PerlPython)(5129) 非技術區(4971) Android(4554) 数据框(4311) css(4259) 节点.js(4032) C語言(3288) json(3245) 列表(3129) 扑(3119) C++語言(3117) 安卓(2998) 打字稿(2995) VBA(2789) Java相關(2746) 疑難問題(2699) 细绳(2522) 單片機工控(2479) iOS(2429) ASP.NET(2402) MongoDB(2323) 麻木的(2285) 正则表达式(2254) 字典(2211) 循环(2198) 迅速(2185) 擅长(2169) 镖(2155) 功能(1967) .NET技术(1958) Web開發(1951) python-3.x(1918) HtmlCss(1915) 弹簧靴(1913) C++(1909) xml(1889) PostgreSQL(1872) .NETCore(1853) 谷歌表格(1846) Unity3D(1843) for循环(1842)

熱門瀏覽
  • 【C++】Microsoft C++、C 和匯編程式檔案

    ......

    uj5u.com 2020-09-10 00:57:23 more
  • 例外宣告

    相比于斷言適用于排除邏輯上不可能存在的狀態,例外通常是用于邏輯上可能發生的錯誤。 例外宣告 Item 1:當函式不可能拋出例外或不能接受拋出例外時,使用noexcept 理由 如果不打算拋出例外的話,程式就會認為無法處理這種錯誤,并且應當盡早終止,如此可以有效地阻止例外的傳播與擴散。 示例 //不可 ......

    uj5u.com 2020-09-10 00:57:27 more
  • Codeforces 1400E Clear the Multiset(貪心 + 分治)

    鏈接:https://codeforces.com/problemset/problem/1400/E 來源:Codeforces 思路:給你一個陣列,現在你可以進行兩種操作,操作1:將一段沒有 0 的區間進行減一的操作,操作2:將 i 位置上的元素歸零。最終問:將這個陣列的全部元素歸零后操作的最少 ......

    uj5u.com 2020-09-10 00:57:30 more
  • UVA11610 【Reverse Prime】

    本人看到此題沒有翻譯,就附帶了一個自己的翻譯版本 思考 這一題,它的第一個要求是找出所有 $7$ 位反向質數及其質因數的個數。 我們應該需要質數篩篩選1~$10^{7}$的所有數,這里就不慢慢介紹了。但是,重讀題,我們突然發現反向質數都是 $7$ 位,而將它反過來后的數字卻是 $6$ 位數,這就說明 ......

    uj5u.com 2020-09-10 00:57:36 more
  • 統計區間素數數量

    1 #pragma GCC optimize(2) 2 #include <bits/stdc++.h> 3 using namespace std; 4 bool isprime[1000000010]; 5 vector<int> prime; 6 inline int getlist(int ......

    uj5u.com 2020-09-10 00:57:47 more
  • C/C++編程筆記:C++中的 const 變數詳解,教你正確認識const用法

    1、C中的const 1、區域const變數存放在堆疊區中,會分配記憶體(也就是說可以通過地址間接修改變數的值)。測驗代碼如下: 運行結果: 2、全域const變數存放在只讀資料段(不能通過地址修改,會發生寫入錯誤), 默認為外部聯編,可以給其他源檔案使用(需要用extern關鍵字修飾) 運行結果: ......

    uj5u.com 2020-09-10 00:58:04 more
  • 【C++犯錯記錄】VS2019 MFC添加資源不懂如何修改資源宏ID

    1. 首先在資源視圖中,添加資源 2. 點擊新添加的資源,復制自動生成的ID 3. 在解決方案資源管理器中找到Resource.h檔案,編輯,使用整個專案搜索和替換的方式快速替換 宏宣告 4. Ctrl+Shift+F 全域搜索,點擊查找全部,然后逐個替換 5. 為什么使用搜索替換而不使用屬性視窗直 ......

    uj5u.com 2020-09-10 00:59:11 more
  • 【C++犯錯記錄】VS2019 MFC不懂的批量添加資源

    1. 打開資源頭檔案Resource.h,在其中預先定義好宏 ID(不清楚其實ID值應該設定多少,可以先新建一個相同的資源項,再在這個資源的ID值的基礎上遞增即可) 2. 在資源視圖中選中專案資源,按F7編輯資源檔案,按 ID 型別 相對路徑的形式添加 資源。(別忘了先把檔案拷貝到專案中的res檔案 ......

    uj5u.com 2020-09-10 01:00:19 more
  • C/C++編程筆記:關于C++的參考型別,專供新手入門使用

    今天要講的是C++中我最喜歡的一個用法——參考,也叫別名。 參考就是給一個變數名取一個變數名,方便我們間接地使用這個變數。我們可以給一個變數創建N個參考,這N + 1個變數共享了同一塊記憶體區域。(參考型別的變數會占用記憶體空間,占用的記憶體空間的大小和指標型別的大小是相同的。雖然參考是一個物件的別名,但 ......

    uj5u.com 2020-09-10 01:00:22 more
  • 【C/C++編程筆記】從頭開始學習C ++:初學者完整指南

    眾所周知,C ++的學習曲線陡峭,但是花時間學習這種語言將為您的職業帶來奇跡,并使您與其他開發人員區分開。您會更輕松地學習新語言,形成真正的解決問題的技能,并在編程的基礎上打下堅實的基礎。 C ++將幫助您養成良好的編程習慣(即清晰一致的編碼風格,在撰寫代碼時注釋代碼,并限制類內部的可見性),并且由 ......

    uj5u.com 2020-09-10 01:00:41 more
最新发布
  • Rust中的智能指標:Box<T> Rc<T> Arc<T> Cell<T> RefCell<T> Weak

    Rust中的智能指標是什么 智能指標(smart pointers)是一類資料結構,是擁有資料所有權和額外功能的指標。是指標的進一步發展 指標(pointer)是一個包含記憶體地址的變數的通用概念。這個地址參考,或 ” 指向”(points at)一些其 他資料 。參考以 & 符號為標志并借用了他們所 ......

    uj5u.com 2023-04-20 07:24:10 more
  • Java的值傳遞和參考傳遞

    值傳遞不會改變本身,參考傳遞(如果傳遞的值需要實體化到堆里)如果發生修改了會改變本身。 1.基本資料型別都是值傳遞 package com.example.basic; public class Test { public static void main(String[] args) { int ......

    uj5u.com 2023-04-20 07:24:04 more
  • [2]SpinalHDL教程——Scala簡單入門

    第一個 Scala 程式 shell里面輸入 $ scala scala> 1 + 1 res0: Int = 2 scala> println("Hello World!") Hello World! 檔案形式 object HelloWorld { /* 這是我的第一個 Scala 程式 * 以 ......

    uj5u.com 2023-04-20 07:23:58 more
  • 理解函式指標和回呼函式

    理解 函式指標 指向函式的指標。比如: 理解函式指標的偽代碼 void (*p)(int type, char *data); // 定義一個函式指標p void func(int type, char *data); // 宣告一個函式func p = func; // 將指標p指向函式func ......

    uj5u.com 2023-04-20 07:23:52 more
  • Django筆記二十五之資料庫函式之日期函式

    本文首發于公眾號:Hunter后端 原文鏈接:Django筆記二十五之資料庫函式之日期函式 日期函式主要介紹兩個大類,Extract() 和 Trunc() Extract() 函式作用是提取日期,比如我們可以提取一個日期欄位的年份,月份,日等資料 Trunc() 的作用則是截取,比如 2022-0 ......

    uj5u.com 2023-04-20 07:23:45 more
  • 一天吃透JVM面試八股文

    什么是JVM? JVM,全稱Java Virtual Machine(Java虛擬機),是通過在實際的計算機上仿真模擬各種計算機功能來實作的。由一套位元組碼指令集、一組暫存器、一個堆疊、一個垃圾回收堆和一個存盤方法域等組成。JVM屏蔽了與作業系統平臺相關的資訊,使得Java程式只需要生成在Java虛擬機 ......

    uj5u.com 2023-04-20 07:23:31 more
  • 使用Java接入小程式訂閱訊息!

    更新完微信服務號的模板訊息之后,我又趕緊把微信小程式的訂閱訊息給實作了!之前我一直以為微信小程式也是要企業才能申請,沒想到小程式個人就能申請。 訊息推送平臺🔥推送下發【郵件】【短信】【微信服務號】【微信小程式】【企業微信】【釘釘】等訊息型別。 https://gitee.com/zhongfuch ......

    uj5u.com 2023-04-20 07:22:59 more
  • java -- 緩沖流、轉換流、序列化流

    緩沖流 緩沖流, 也叫高效流, 按照資料型別分類: 位元組緩沖流:BufferedInputStream,BufferedOutputStream 字符緩沖流:BufferedReader,BufferedWriter 緩沖流的基本原理,是在創建流物件時,會創建一個內置的默認大小的緩沖區陣列,通過緩沖 ......

    uj5u.com 2023-04-20 07:22:49 more
  • Java-SpringBoot-Range請求頭設定實作視頻分段傳輸

    老實說,人太懶了,現在基本都不喜歡寫筆記了,但是網上有關Range請求頭的文章都太水了 下面是抄的一段StackOverflow的代碼...自己大修改過的,寫的注釋挺全的,應該直接看得懂,就不解釋了 寫的不好...只是希望能給視頻網站開發的新手一點點幫助吧. 業務場景:視頻分段傳輸、視頻多段傳輸(理 ......

    uj5u.com 2023-04-20 07:22:42 more
  • Windows 10開發教程_編程入門自學教程_菜鳥教程-免費教程分享

    教程簡介 Windows 10開發入門教程 - 從簡單的步驟了解Windows 10開發,從基本到高級概念,包括簡介,UWP,第一個應用程式,商店,XAML控制元件,資料系結,XAML性能,自適應設計,自適應UI,自適應代碼,檔案管理,SQLite資料庫,應用程式到應用程式通信,應用程式本地化,應用程式 ......

    uj5u.com 2023-04-20 07:22:35 more
