unix domain socket

unix domain socket 是在socket架構上發展起來的用于同一臺主機的行程間通訊（IPC: Inter-Process Communication），它不需要經過網路協議堆疊，不需要打包拆包、計算校驗和、維護序號和應答等，只是將應用層資料從一個行程拷貝到另一個行程，UNIX Domain Socket有SOCK_DGRAM或SOCK_STREAM兩種作業模式，類似于UDP和TCP，但是面向訊息的UNIX Domain Socket也是可靠的，訊息既不會丟失也不會順序錯亂，

UNIX Domain Socket可用于兩個沒有親緣關系的行程，是全雙工的，是目前使用最廣泛的IPC機制，比如X Window服務器和GUI程式之間就是通過UNIX Domain Socket通訊的，

UNIX Domain socket與網路socket類似，可以與網路socket對比應用，

上述二者編程的不同如下：

• address family為AF_UNIX
• 因為應用于IPC，所以UNIXDomain socket不需要IP和埠，取而代之的是檔案路徑來表示“網路地址”，這點體現在下面兩個方面，
• 地址格式不同，UNIXDomain socket用結構體sockaddr_un表示，是一個socket型別的檔案在檔案系統中的路徑，這個socket檔案由bind()呼叫創建，如果呼叫bind()時該檔案已存在，則bind()錯誤回傳，
• UNIX Domain Socket客戶端一般要顯式呼叫bind函式，而不象網路socket一樣依賴系統自動分配的地址，客戶端bind的socket檔案名可以包含客戶端的pid，這樣服務器就可以區分不同的客戶端，

下面用python代碼演示uds的使用

Python代碼演示

服務端

#!/usr/bin/env python
# -*- coding: utf-8 -*-

"""
Created on 12/11/17 11:55 AM
@author: Chen Liang
@function: socket_echo_server_uds
"""

import sys

reload(sys)
sys.setdefaultencoding('utf-8')
import socket
import os

server_address = './uds_socket'

# Make sure the socket does not already exist
try:
    os.unlink(server_address)
except OSError:
    if os.path.exists(server_address):
        raise

# Create a UDS socket
sock = socket.socket(socket.AF_UNIX, socket.SOCK_STREAM)

# Bind the socket to the address
print('starting up on {}'.format(server_address))
sock.bind(server_address)

# Listen for incoming connections
sock.listen(1)

while True:
    # Wait for a connection
    print('waiting for a connection')
    connection, client_address = sock.accept()
    try:
        print('connection from', client_address)

        # Receive the data in small chunks and retransmit it
        while True:
            data = https://www.cnblogs.com/CHLL55/p/connection.recv(16)
            print('received {!r}'.format(data))
            if data:
                print('sending data back to the client')
                connection.sendall(data)
            else:
                print('no data from', client_address)
                break

    finally:
        # Clean up the connection
        connection.close()

客戶端

#!/usr/bin/env python
# -*- coding: utf-8 -*-

"""
Created on 12/11/17 11:55 AM
@author: Chen Liang
@function: socket_echo_client_uds
"""

import sys

reload(sys)
sys.setdefaultencoding('utf-8')


import socket
import sys

# Create a UDS socket
sock = socket.socket(family=socket.AF_UNIX, type=socket.SOCK_STREAM)

# Connect the socket to the port where the server is listening
server_address = './uds_socket'
print('connecting to {}'.format(server_address))
try:
    sock.connect(server_address)
except socket.error as msg:
    print(msg)
    sys.exit(1)

try:

    # Send data
    message = b'This is the message.  It will be repeated.'
    print('sending {!r}'.format(message))
    sock.sendall(message)

    amount_received = 0
    amount_expected = len(message)

    while amount_received < amount_expected:
        data = https://www.cnblogs.com/CHLL55/p/sock.recv(16)
        amount_received += len(data)
        print('received {!r}'.format(data))

finally:
    print('closing socket')
    sock.close()

客戶端一次發送，服務端分批回傳，

服務端輸出結果如下

root@ubuntu:~/PycharmProjects/python_scripts# python socket_echo_server_uds.py
starting up on ./uds_socket
waiting for a connection
('connection from', '')
received 'This is the mess'
sending data back to the client
received 'age.  It will be'
sending data back to the client
received ' repeated.'
sending data back to the client
received ''
('no data from', '')
waiting for a connection

客戶端輸出結果如下

root@ubuntu:~/PycharmProjects/python_scripts# python socket_echo_client_uds.py
connecting to ./uds_socket
sending 'This is the message.  It will be repeated.'
received 'This is the mess'
received 'age.  It will be'
received ' repeated.'
closing socket

查看套接字檔案的型別如下

root@ubuntu:~/PycharmProjects/python_scripts# ls -l ./uds_socket
srwxr-xr-x 1 root root 0 Dec 11 13:45 ./uds_socket

可見uds檔案是socket型別，具體的linux檔案型別有以下幾種：

Linux的檔案型別有以下幾種:

參考：

• Python實體淺談之九使用本地socket檔案
• Linux下的IPC－UNIX Domain Socket
• pymotw3 unix domain socket
