進口立式排污泵原理特點及品牌（圖）

作者：托馬斯·貝爾森·伍德發布時間：2021-01-16 13:04:40點擊：201

進口立式排污泵原理特點

進口立式排污泵是在德國托馬斯(Thomas)先進技識訓礎上，通過吸收、轉化研制而成，各項性能指標均達到德國標準同類產品水平，由于采用獨特的單（雙）通道葉輪，排污能力強、能有效的通過泵口徑的5倍纖維物與直徑為泵口徑50%的固體顆粒，動密封采用兩組特殊材料的硬質合金機械密封裝置，材質為鑄鐵和不銹鋼，該系列泵采用獨特葉輪結構和新型機械密封，能有效地輸送含有固體物和長纖維，葉輪與傳統葉輪相比，該泵葉輪采用單流道或雙流道形式，它類似于一截面大小相同的彎管，具有非常好的過流性，配以合理的蝸室，使得該泵具有效率高、葉輪經動靜平衡試驗，使泵在運行中無振動，該泵水力性能先進、成熟，產品經測驗各項性能指標均達到有關標準規定，產品投放國際市場后以其獨特的功效，可靠的性能，穩定的質量受到廣大用戶的歡迎和好評，產品特點 1、采用獨特的單葉片或雙葉片葉輪結構，大大提高了污物的通過能力，能有效的通過口徑的5倍纖維物質與直徑為泵口徑約50％的同體顆粒； 2、機械密封采用新型硬質全金耐腐的碳化鎢材料，使其長期處于油室內運行，可使泵安全連續運行8000小時以上； 3、整體結構緊湊、體積小、噪聲小、節能效果顯著，檢修方便，同時因電機采用標準的Y系列電機，方便用戶更換； 4、自動控制柜可以根據所需液位變化，自動控制泵的超動與停止，不需專人看管，使用極為方便； 5、可根據用戶需要配備方盤、圓盤安裝系統，它給安裝、維修帶來極大方便，人可不必此為而進入污水坑； 6、能夠在全揚程范圍內使用，而保證電機不會過載； 7、該排污泵配上戶外型電機，則無須建泵房，可直接安裝于戶外使用節省開支； 8、泵為立式結構，產品用途適用用于工廠商業嚴重污染廢水的排放、住宅區的污水排污站、城市污水處理廠派水系統、人防系統排水站、自來水廠的給水設備、醫院、賓館的污水排放、市政工程建筑工地、礦山配套附機、農村沼氣池、農田灌溉等行業，輸送帶顆粒的污水、污物，也可用于清水及帶弱腐蝕性介質，使用條件 1、排污泵的使用環境溫度≤40℃，濕度≤95%；海拔高度≤1000米， 2、介質溫度不超過60℃，介質重度為1～1.3kg/dm3， 3、鑄鐵材質的使用范圍是PH5～9， 4、1Cr18Ni9Ti不銹鋼材質可使用一般腐蝕性介質， 5、使用環境海拔高度不超過1000米，結構說明進口立式排污泵為單吸蝸殼式泵，泵內裝有無堵塞防纏繞型單（雙）大流道葉輪，具有很好的通過能力，該系列泵具有兩種結構形式，一是電機與泵直接同軸，二是采用聯軸器聯接，電機采用標準立式電機，每種結構形式具有兩種底座連接形式，一是進口水平吸入，具有轉角功能，可根據使用要求，進出口安放成0°、90°、180°、270°，便于管路連接，二是進口軸向吸入，便于立式安裝， Vertical sewage pump is in Germany Thomas (Thomas) on the basis of advanced technology, through the absorption, transformation and development, the performance indicators have reached the German standard similar products. As a result of the unique single (double) channel impeller, sewage ability, can effectively through the pump diameter of 5 times the diameter of the fiber diameter and diameter of 50% of the solid particles, dynamic sealing two groups of special materials, carbide mechanical seal The device is made of cast iron and stainless steel. The series of pumps with a unique impeller structure and a new mechanical seal, can effectively transport containing solid and long fiber. Impeller Compared with traditional impeller, the pump impeller with a single channel or double channel form, it is similar to a cross-section of the same size of the elbow, with a very good overcurrent, coupled with a reasonable spiral chamber, making the pump with efficiency High, impeller by static and static test, so that the pump in the run without vibration. The pump hydraulic performance of advanced, mature, the product tested by the performance indicators have reached the relevant standards, products put on the international market with its unique efficacy, reliable performance, stable quality by the majority of users welcome and praise. Features 1, the use of unique single leaf or double leaf impeller structure, greatly improving the ability of dirt through, can effectively pass the diameter of 5 times the fiber material and diameter of about 50% of the diameter of the same particles; 2, the mechanical seal with a new type of hard gold-free corrosion of tungsten carbide material, so that long-term operation in the oil chamber, the pump can run continuously for more than 8000 hours; 3, the overall structure of compact, small size, low noise, energy saving effect is significant, easy maintenance, while the motor using the standard Y series motor, user-friendly replacement; 4, automatic control cabinet can be based on the required level changes, automatic control of the pump overturned and stopped, without special care, the use of extremely convenient; 5, according to the needs of users with square plate, disc installation system, it is to install, repair a great convenience, people do not have to enter the sewage pits; 6, can be used in the whole lift range, and ensure that the motor will not overload; 7, the sewage pump coupled with outdoor motor, you do not need to build a pump room, can be installed directly in the outdoor use of cost savings; 8, the pump is a vertical structure. Product Usage Applicable for the serious pollution of wastewater in the factory business, the sewage discharge station in the residential area, the sewage treatment system of the urban sewage treatment plant, the drainage system of the civil air defense system, the water supply equipment of the water plant, the sewage discharge of the hospital and the hotel, the municipal construction site, the mine Supporting the machine, rural biogas digesters, farmland irrigation and other industries, conveyor belt particles of sewage, dirt, can also be used for water and with weak corrosive media. Conditions of Use 1, the use of sewage pump ambient temperature ≤ 40 ℃, humidity ≤ 95%; altitude ≤ 1000 meters. 2, the medium temperature does not exceed 60 ℃, medium heavyness of 1 ~ 1.3kg / dm3. 3, the use of cast iron material is PH5 ~ 9. 4,1Cr18Ni9Ti stainless steel material can use the general corrosive media. 5, the use of environmental altitude of not more than 1000 meters. Structural description

Imported vertical sewage pump for a single snail-type pump, the pump is equipped with no clogging anti-winding single (double) large flow channel impeller, with good ability to pass. The series of pumps with two structural forms, one motor and pump direct coaxial, the second is the use of coupling coupling, the motor standard vertical motor. Each type of structure has two kinds of base connection form, one import level inhalation, with corner function, according to the use of requirements, import and export placed into 0 °, 90 °, 180 °, 270 °, easy to connect, Axial suction for easy installation.

進口立式排污泵品牌

德國托馬斯閥門集團于1933年創建于德國魯爾工業區，也是世界最重要的工業區，位于德國西部、萊茵河下游支流魯爾河與利珀河之間的地區，德國托馬斯閥門集團是以生產高品質、先進的閥門、測量及控制系統而享譽全球的跨國性生產企業，采用世界先進的設備及生產工藝，所有產品都在嚴格的質量體系監控下完成作業，并在各大洲幾十個國家擁有子公司及分支機構，上一篇：進口潛水排污泵原理特點及品牌（圖）下一篇：進口管道排污泵原理特點及品牌（圖）相關產品
