從零玩轉人臉識別

前言

在線demo

(前往享受人臉識別)

文章作者個人博客

(前往作者博客)

本期教程人臉識別第三方平臺為虹軟科技,基于Java開發，本文章講解的是人臉識別RGB活體追蹤技術，免費的功能很多可以自行搭配，希望在你看完本章課程有所識訓，

ArcFace 離線SDK，包含人臉檢測、性別檢測、年齡檢測、人臉識別、影像質量檢測、RGB活體檢測、IR活體檢測等能力，初次使用時需聯網激活，激活后即可在本地無網路環境下作業，可根據具體的業務需求結合人臉識別SDK靈活地進行應用層開發，

功能介紹

1. 人臉檢測

對傳入的影像資料進行人臉檢測，回傳人臉的邊框以及朝向資訊，可用于后續的人臉識別、特征提取、活體檢測等操作;

• 支持IMAGE模式和VIDEO模式人臉檢測，
• 支持單人臉、多人臉檢測，最多支持檢測人臉數為50，

2.人臉追蹤

對來自于視頻流中的影像資料，進行人臉檢測，并對檢測到的人臉進行持續跟蹤，(我們是實時的所以就只能使用第三方操作,先不使用這個)

3.人臉特征提取

提取人臉特征資訊，用于人臉的特征比對，

4.人臉屬性檢測

人臉屬性，支持檢測年齡、性別以及3D角度，

人臉3D角度：俯仰角（pitch）， 橫滾角（roll）， 偏航角（yaw），

5.活體檢測

離線活體檢測，靜默式識別，在人臉識別程序中判斷操作用戶是否為真人，有效防御照片、視頻、紙張等不同型別的作弊攻擊，提高業務安全性，讓人臉識別更安全、更快捷，體驗更佳，支持單目RGB活體檢測、雙目（IR/RGB）活體檢測，可滿足各類人臉識別終端產品活體檢測應用，

開造

訪問地址： https://ai.arcsoft.com.cn/technology/faceTracking.html 進入開發者中心進行注冊以及認證個人資訊

1. 點擊我的應用 > 新建應用

2.填寫資訊立即創建 點擊 添加SDK

3.選中免費版人臉識別

4. 填寫授權碼資訊

選擇平臺先選擇windows的根據你的電腦配置來 是64位還是32位的, 語言選擇Java

5. 介紹sdk檔案

構建專案工程

匯入專案依賴

    <properties>
        <java.version>1.8</java.version>
        <project.build.sourceEncoding>UTF-8</project.build.sourceEncoding>
        <project.reporting.outputEncoding>UTF-8</project.reporting.outputEncoding>
        <spring-boot.version>2.3.7.RELEASE</spring-boot.version>
        <druid-spring-boot-starter.version>1.2.6</druid-spring-boot-starter.version>
        <mybatis-spring-boot.version>2.1.4</mybatis-spring-boot.version>
        <pagehelper.boot.version>1.3.0</pagehelper.boot.version>
    </properties>

    <dependencies>
        <dependency>
            <groupId>org.springframework.boot</groupId>
            <artifactId>spring-boot-starter-web</artifactId>
        </dependency>

        <!--  人臉識別  -->
        <dependency>
            <groupId>com.arcsoft.face</groupId>
            <artifactId>arcsoft-sdk-face</artifactId>
            <scope>system</scope>
            <systemPath>${project.basedir}/lib/arcsoft-sdk-face-3.0.0.0.jar</systemPath>
            <version>3.0.0.0</version>
        </dependency>

        <!-- pool 物件池 -->
        <dependency>
            <groupId>org.apache.commons</groupId>
            <artifactId>commons-pool2</artifactId>
        </dependency>

        <!-- guava -->
        <dependency>
            <groupId>com.google.guava</groupId>
            <artifactId>guava</artifactId>
            <version>27.0.1-jre</version>
        </dependency>

        <!-- Mysql驅動包 -->
        <dependency>
            <groupId>mysql</groupId>
            <artifactId>mysql-connector-java</artifactId>
        </dependency>

        <!-- mybatis-plus 增強CRUD -->
        <dependency>
            <groupId>com.baomidou</groupId>
            <artifactId>mybatis-plus-boot-starter</artifactId>
            <version>3.4.2</version>
        </dependency>

        <!-- pagehelper 分頁插件 內置mybatis 依賴-->
        <dependency>
            <groupId>com.github.pagehelper</groupId>
            <artifactId>pagehelper-spring-boot-starter</artifactId>
            <version>${pagehelper.boot.version}</version>
        </dependency>

        <!-- 阿里資料源 -->
        <dependency>
            <groupId>com.alibaba</groupId>
            <artifactId>druid-spring-boot-starter</artifactId>
            <version>${druid-spring-boot-starter.version}</version>
        </dependency>
        <dependency>
            <groupId>org.springframework.boot</groupId>
            <artifactId>spring-boot-configuration-processor</artifactId>
            <optional>true</optional>
        </dependency>
        <!-- Spring框架基本的核心工具 -->
        <dependency>
            <groupId>org.springframework</groupId>
            <artifactId>spring-context-support</artifactId>
        </dependency>
        <!-- JSON工具類 -->
        <dependency>
            <groupId>com.fasterxml.jackson.core</groupId>
            <artifactId>jackson-databind</artifactId>
        </dependency>

        <dependency>
            <groupId>cn.hutool</groupId>
            <artifactId>hutool-all</artifactId>
            <version>5.8.0</version>
        </dependency>
        <!-- SpringWeb模塊 -->
        <dependency>
            <groupId>org.springframework</groupId>
            <artifactId>spring-web</artifactId>
        </dependency>

        <!-- servlet包 -->
        <dependency>
            <groupId>javax.servlet</groupId>
            <artifactId>javax.servlet-api</artifactId>
        </dependency>
        <!-- aop -->
        <dependency>
            <groupId>org.springframework.boot</groupId>
            <artifactId>spring-boot-starter-aop</artifactId>
        </dependency>
        <dependency>
            <groupId>org.projectlombok</groupId>
            <artifactId>lombok</artifactId>
            <optional>true</optional>
        </dependency>
    </dependencies>

    <dependencyManagement>
        <dependencies>
            <dependency>
                <groupId>org.springframework.boot</groupId>
                <artifactId>spring-boot-dependencies</artifactId>
                <version>${spring-boot.version}</version>
                <type>pom</type>
                <scope>import</scope>
            </dependency>
        </dependencies>
    </dependencyManagement>

    <build>
        <plugins>
            <plugin>
                <groupId>org.apache.maven.plugins</groupId>
                <artifactId>maven-compiler-plugin</artifactId>
                <version>3.8.1</version>
                <configuration>
                    <source>1.8</source>
                    <target>1.8</target>
                    <encoding>UTF-8</encoding>
                </configuration>
            </plugin>
            <plugin>
                <groupId>org.springframework.boot</groupId>
                <artifactId>spring-boot-maven-plugin</artifactId>
                <version>2.3.7.RELEASE</version>
                <configuration>
                    <mainClass>top.yangbuyi.YangbuyiFaceDemoApplication</mainClass>
                    <!-- 檔案要配置includeSystemScope屬性，否則可能會導致arcsoft-sdk-face-3.0.0.0.jar獲取不到 -->
                    <includeSystemScope>true</includeSystemScope>
                    <fork>true</fork>
                </configuration>
                <executions>
                    <execution>
                        <id>repackage</id>
                        <goals>
                            <goal>repackage</goal>
                        </goals>
                    </execution>
                </executions>
            </plugin>
        </plugins>
    </build>

使用代碼生成器生成CURD
版本請對應圖片當中的jebat全家桶群里獲取3秒破解使用

生成完畢后在根目錄創建lib目錄將下載下來的人臉識別依賴匯入->右擊添加到庫

application.yml 修改組態檔

# 開發環境配置
server:
  # 服務器的HTTP埠，默認為8080
  port: 8080
  servlet:
    # 應用的訪問路徑
    context-path: /
  tomcat:
    # tomcat的URI編碼
    uri-encoding: UTF-8
    # tomcat最大執行緒數，默認為200
    max-threads: 800
    # Tomcat啟動初始化的執行緒數，默認值25
    min-spare-threads: 30

# Spring配置
spring:
  # 同時執行其它組態檔
  profiles:
    active: druid
  mvc: # 把前端的接收到的時間格式 格式化為 yyyy-MM-dd HH:mm:ss
    date-format: yyyy-MM-dd HH:mm:ss
  jackson: # 把后臺的時間格式 格式化為 yyyy-MM-dd HH:mm:ss
    date-format: yyyy-MM-dd HH:mm:ss
    time-zone: GMT+8
  # 服務模塊
  devtools:
    restart:
      # 熱部署開關
      enabled: true
# MyBatis配置
mybatis-plus:
  # 搜索指定包別名
  typeAliasesPackage: top.yangbuyi.domain
  # 配置mapper的掃描，找到所有的mapper.xml映射檔案
  mapperLocations: classpath*:mapper/*Mapper.xml
  # 加載全域的組態檔
  configLocation: classpath:mybatis/mybatis-config.xml

# PageHelper分頁插件
pagehelper:
  helperDialect: mysql
  reasonable: true
  supportMethodsArguments: true
  params: count=countSql

# 人臉識別配置

# WIND64
config:
  sdk-lib-path: M:\yangbuyiya-RBAC\libs\WIN64
  app-id: 4QKtmacvsKqaCsoXyyujcs21JTAr79pTczPdZpuaEjhH
  sdk-key: EgBjrmidnqstaL46msfHukeKanYXCujzeHokf2qcC3br
  thread-pool-size: 5

application-druid.yml 資料源配置

# 資料源配置
spring:
  datasource:
    type: com.alibaba.druid.pool.DruidDataSource
    driverClassName: com.mysql.cj.jdbc.Driver
    druid:
      url: jdbc:mysql://127.0.0.1:3308/face?useUnicode=true&characterEncoding=utf8&zeroDateTimeBehavior=convertToNull&useSSL=true&serverTimezone=GMT%2B8
      username: root
      password: 123456
      # 初始連接數
      initialSize: 5
      # 最小連接池數量
      minIdle: 10
      # 最大連接池數量
      maxActive: 20
      # 配置獲取連接等待超時的時間
      maxWait: 60000
      # 配置間隔多久才進行一次檢測，檢測需要關閉的空閑連接，單位是毫秒
      timeBetweenEvictionRunsMillis: 60000
      # 配置一個連接在池中最小生存的時間，單位是毫秒
      minEvictableIdleTimeMillis: 300000
      # 配置一個連接在池中最大生存的時間，單位是毫秒
      maxEvictableIdleTimeMillis: 900000
      # 配置檢測連接是否有效
      validationQuery: SELECT 1 FROM DUAL
      testWhileIdle: true
      testOnBorrow: false
      testOnReturn: false
      webStatFilter:
        enabled: true
      statViewServlet:
        enabled: true
        # 設定白名單，不填則允許所有訪問
        allow:
        url-pattern: /yangbuyi/druid/*
      filter:
        stat:
          enabled: true
          # 慢SQL記錄
          log-slow-sql: true
          slow-sql-millis: 1000
          merge-sql: true
        wall:
          config:
            multi-statement-allow: true

resources 下創建mybatis檔案夾創建mybatis-config.xml檔案

<?xml version="1.0" encoding="UTF-8" ?>
<!DOCTYPE configuration
        PUBLIC "-//mybatis.org//DTD Config 3.0//EN"
        "http://mybatis.org/dtd/mybatis-3-config.dtd">
<configuration>

    <settings>
        <setting name="cacheEnabled" value="https://www.cnblogs.com/Yangbuyi/p/true"/>  <!-- 全域映射器啟用快取 -->
        <setting name="useGeneratedKeys" value="https://www.cnblogs.com/Yangbuyi/p/true"/>  <!-- 允許 JDBC 支持自動生成主鍵 -->
        <setting name="defaultExecutorType" value="https://www.cnblogs.com/Yangbuyi/p/REUSE"/> <!-- 配置默認的執行器 -->
        <setting name="logImpl" value="https://www.cnblogs.com/Yangbuyi/p/SLF4J"/> <!-- 指定 MyBatis 所用日志的具體實作 -->
        <!-- <setting name="mapUnderscoreToCamelCase" value="https://www.cnblogs.com/Yangbuyi/p/true"/>  駝峰式命名 -->
    </settings>

</configuration>

專案基礎檔案配置

創建config檔案
創建ApplicationConfig全域配置類

/**
 * 程式注解配置
 *
 * @author yangbuyi
 */
@Configuration
// 表示通過aop框架暴露該代理物件,AopContext能夠訪問
@EnableAspectJAutoProxy(exposeProxy = true)
// 指定要掃描的Mapper類的包的路徑
@MapperScan("top.yangbuyi.mapper")
public class ApplicationConfig {
    /**
     * 時區配置
     */
    @Bean
    public Jackson2ObjectMapperBuilderCustomizer jacksonObjectMapperCustomization () {
        return jacksonObjectMapperBuilder -> jacksonObjectMapperBuilder.timeZone(TimeZone.getDefault());
    }

    /**
     * 處理Long型別精度丟失
     *
     * @return
     */
    @Bean("jackson2ObjectMapperBuilderCustomizer")
    public Jackson2ObjectMapperBuilderCustomizer jackson2ObjectMapperBuilderCustomizer () {
        return jacksonObjectMapperBuilder -> jacksonObjectMapperBuilder.serializerByType(Long.class, ToStringSerializer.instance)
                                                     .serializerByType(Long.TYPE, ToStringSerializer.instance);
    }
}

創建全域MybatisPlusConfig配置

/**
 * @program: yangbuyi-rbac
 * @ClassName: MybatisPlusConfig
 * @create: 2022-04-25 15:48
 * @author: yangbuyi.top
 * @since： JDK1.8
 * @MybatisPlusConfig: $
 **/

import com.baomidou.mybatisplus.annotation.DbType;
import com.baomidou.mybatisplus.extension.plugins.MybatisPlusInterceptor;
import com.baomidou.mybatisplus.extension.plugins.inner.BlockAttackInnerInterceptor;
import com.baomidou.mybatisplus.extension.plugins.inner.OptimisticLockerInnerInterceptor;
import com.baomidou.mybatisplus.extension.plugins.inner.PaginationInnerInterceptor;
import org.springframework.context.annotation.Bean;
import org.springframework.context.annotation.Configuration;
import org.springframework.transaction.annotation.EnableTransactionManagement;

@EnableTransactionManagement(proxyTargetClass = true)
@Configuration
public class MybatisPlusConfig {
    @Bean
    public MybatisPlusInterceptor mybatisPlusInterceptor () {
        MybatisPlusInterceptor interceptor = new MybatisPlusInterceptor();
        // 分頁插件
        interceptor.addInnerInterceptor(paginationInnerInterceptor());
        // 樂觀鎖插件
        interceptor.addInnerInterceptor(optimisticLockerInnerInterceptor());
        // 阻斷插件
        interceptor.addInnerInterceptor(blockAttackInnerInterceptor());
        return interceptor;
    }

    /**
     * 分頁插件，自動識別資料庫型別 https://baomidou.com/guide/interceptor-pagination.html
     */
    public PaginationInnerInterceptor paginationInnerInterceptor () {
        PaginationInnerInterceptor paginationInnerInterceptor = new PaginationInnerInterceptor();
        // 設定資料庫型別為mysql
        paginationInnerInterceptor.setDbType(DbType.MYSQL);
        // 設定最大單頁限制數量，默認 500 條，-1 不受限制
        paginationInnerInterceptor.setMaxLimit(-1L);
        return paginationInnerInterceptor;
    }

    /**
     * 樂觀鎖插件 https://baomidou.com/guide/interceptor-optimistic-locker.html
     */
    public OptimisticLockerInnerInterceptor optimisticLockerInnerInterceptor () {
        return new OptimisticLockerInnerInterceptor();
    }

    /**
     * 如果是對全表的洗掉或更新操作，就會終止該操作 https://baomidou.com/guide/interceptor-block-attack.html
     */
    public BlockAttackInnerInterceptor blockAttackInnerInterceptor () {
        return new BlockAttackInnerInterceptor();
    }
}

創建dto檔案夾

創建人臉回傳物體 FaceSearchResDto

/**
 * @author yangbuyi.top
 */
@Data
public class FaceSearchResDto {
    /**
     * 唯一人臉Id
     */
    private String faceId;
    /**
     * 人臉名稱
     */
    private String name;
    private Integer similarValue;
    /**
     * 年齡
     */
    private Integer age;
    /**
     * 性別
     */
    private String gender;
    /**
     * 圖片
     */
    private String image;

}

創建人臉映射 FaceUserInfo

/**
 * @author yangbuyi.top
 */
@Data
public class FaceUserInfo {
    private int id;
    private int groupId;
    private String faceId;
    private String name;
    private Integer similarValue;
    private byte[] faceFeature;
}

創建年齡映射

/**
 * @author yangbuyi.top
 */
public class ProcessInfo {
    private Integer age;
    private Integer gender;

    public Integer getAge () {
        return age;
    }

    public void setAge (Integer age) {
        this.age = age;
    }

    public Integer getGender () {
        return gender;
    }

    public void setGender (Integer gender) {
        this.gender = gender;
    }
}

創建enums檔案夾

創建ErrorCodeEnum列舉類

/**
 * @author yangbuyi.top
 */


public enum ErrorCodeEnum {

    MOK(0, "成功"),
    UNKNOWN(1, "未知錯誤"),
    INVALID_PARAM(2, "無效引數"),
    UNSUPPORTED(3, "引擎不支持"),
    NO_MEMORY(4, "記憶體不足"),
    BAD_STATE(5, "狀態錯誤"),
    USER_CANCEL(6, "用戶取消相關操作"),
    EXPIRED(7, "操作時間過期"),
    USER_PAUSE(8, "用戶暫停操作"),
    BUFFER_OVERFLOW(9, "緩沖上溢"),
    BUFFER_UNDERFLOW(10, "緩沖下溢"),
    NO_DISKSPACE(11, "存貯空間不足"),
    COMPONENT_NOT_EXIST(12, "組件不存在"),
    GLOBAL_DATA_NOT_EXIST(13, "全域資料不存在"),
    NO_FACE_DETECTED(14, "未檢出到人臉"),
    FACE_DOES_NOT_MATCH(15, "人臉不匹配"),
    INVALID_APP_ID(28673, "無效的AppId"),
    INVALID_SDK_ID(28674, "無效的SdkKey"),
    INVALID_ID_PAIR(28675, "AppId和SdkKey不匹配"),
    MISMATCH_ID_AND_SDK(28676, "SdkKey 和使用的SDK 不匹配"),
    SYSTEM_VERSION_UNSUPPORTED(28677, "系統版本不被當前SDK所支持"),
    LICENCE_EXPIRED(28678, "SDK有效期過期，需要重新下載更新"),
    APS_ENGINE_HANDLE(69633, "引擎句柄非法"),
    APS_MEMMGR_HANDLE(69634, "記憶體句柄非法"),
    APS_DEVICEID_INVALID(69635, " Device ID 非法"),
    APS_DEVICEID_UNSUPPORTED(69636, "Device ID 不支持"),
    APS_MODEL_HANDLE(69637, "模板資料指標非法"),
    APS_MODEL_SIZE(69638, "模板資料長度非法"),
    APS_IMAGE_HANDLE(69639, "影像結構體指標非法"),
    APS_IMAGE_FORMAT_UNSUPPORTED(69640, "影像格式不支持"),
    APS_IMAGE_PARAM(69641, "影像引數非法"),
    APS_IMAGE_SIZE(69642, "影像尺寸大小超過支持范圍"),
    APS_DEVICE_AVX2_UNSUPPORTED(69643, "處理器不支持AVX2指令"),
    FR_INVALID_MEMORY_INFO(73729, "無效的輸入記憶體"),
    FR_INVALID_IMAGE_INFO(73730, "無效的輸入影像引數"),
    FR_INVALID_FACE_INFO(73731, "無效的臉部資訊"),
    FR_NO_GPU_AVAILABLE(73732, "當前設備無GPU可用"),
    FR_MISMATCHED_FEATURE_LEVEL(73733, "待比較的兩個人臉特征的版本不一致"),
    FACEFEATURE_UNKNOWN(81921, "人臉特征檢測錯誤未知"),
    FACEFEATURE_MEMORY(81922, "人臉特征檢測記憶體錯誤"),
    FACEFEATURE_INVALID_FORMAT(81923, "人臉特征檢測格式錯誤"),
    FACEFEATURE_INVALID_PARAM(81924, "人臉特征檢測引數錯誤"),
    FACEFEATURE_LOW_CONFIDENCE_LEVEL(81925, "人臉特征檢測結果置信度低"),
    ASF_EX_BASE_FEATURE_UNSUPPORTED_ON_INIT(86017, "Engine不支持的檢測驗性"),
    ASF_EX_BASE_FEATURE_UNINITED(86018, "需要檢測的屬性未初始化"),
    ASF_EX_BASE_FEATURE_UNPROCESSED(86019, "待獲取的屬性未在process中處理過"),
    ASF_EX_BASE_FEATURE_UNSUPPORTED_ON_PROCESS(86020, "PROCESS不支持的檢測驗性，例如FR，有自己獨立的處理函式"),
    ASF_EX_BASE_INVALID_IMAGE_INFO(86021, "無效的輸入影像"),
    ASF_EX_BASE_INVALID_FACE_INFO(86022, "無效的臉部資訊"),
    ASF_BASE_ACTIVATION_FAIL(90113, "人臉比對SDK激活失敗,請打開讀寫權限"),
    ASF_BASE_ALREADY_ACTIVATED(90114, "人臉比對SDK已激活"),
    ASF_BASE_NOT_ACTIVATED(90115, "人臉比對SDK未激活"),
    ASF_BASE_SCALE_NOT_SUPPORT(90116, "detectFaceScaleVal 不支持"),
    ASF_BASE_VERION_MISMATCH(90117, "SDK版本不匹配"),
    ASF_BASE_DEVICE_MISMATCH(90118, "設備不匹配"),
    ASF_BASE_UNIQUE_IDENTIFIER_MISMATCH(90119, "唯一標識不匹配"),
    ASF_BASE_PARAM_NULL(90120, "引數為空"),
    ASF_BASE_SDK_EXPIRED(90121, "SDK已過期"),
    ASF_BASE_VERSION_NOT_SUPPORT(90122, "版本不支持"),
    ASF_BASE_SIGN_ERROR(90123, "簽名錯誤"),
    ASF_BASE_DATABASE_ERROR(90124, "資料庫插入錯誤"),
    ASF_BASE_UNIQUE_CHECKOUT_FAIL(90125, "唯一識別符號校驗失敗"),
    ASF_BASE_COLOR_SPACE_NOT_SUPPORT(90126, "輸入的顏色空間不支持"),
    ASF_BASE_IMAGE_WIDTH_NOT_SUPPORT(90127, "輸入影像的byte資料長度不正確"),
    ASF_NETWORK_BASE_COULDNT_RESOLVE_HOST(94209, "無法決議主機地址"),
    ASF_NETWORK_BASE_COULDNT_CONNECT_SERVER(94210, "無法連接服務器"),
    ASF_NETWORK_BASE_CONNECT_TIMEOUT(94211, "網路連接超時"),
    ASF_NETWORK_BASE_UNKNOWN_ERROR(94212, "未知錯誤");


    private Integer code;
    private String description;

    ErrorCodeEnum (Integer code, String description) {
        this.code = code;
        this.description = description;
    }

    public Integer getCode () {
        return code;
    }

    public void setCode (Integer code) {
        this.code = code;
    }

    public String getDescription () {
        return description;
    }

    public void setDescription (String description) {
        this.description = description;
    }

    public static ErrorCodeEnum getDescriptionByCode (Integer code) {
        for (ErrorCodeEnum errorCodeEnum : ErrorCodeEnum.values()) {
            if (code.equals(errorCodeEnum.getCode())) {
                return errorCodeEnum;
            }
        }
        return ErrorCodeEnum.UNKNOWN;
    }

}

創建utils檔案夾

創建Base64DecodeMultipartFile

package top.yangbuyi.utils;

import org.springframework.web.multipart.MultipartFile;

import java.io.*;

/**
 * @author yangbuyi.top
 * @program: yangbuyi-rbac
 * @ClassName: Base64DecodeMultipartFile
 * @create: 2022-04-25 16:25
 * @since： JDK1.8
 * @Base64DecodeMultipartFile: $
 **/

public class Base64DecodeMultipartFile implements MultipartFile {
    private final byte[] imgContent;
    private final String header;

    public Base64DecodeMultipartFile (byte[] imgContent, String header) {
        this.imgContent = imgContent;
        this.header = header.split(";")[0];
    }

    @Override
    public String getName () {
        return System.currentTimeMillis() + Math.random() + "." + header.split("/")[1];
    }

    @Override
    public String getOriginalFilename () {
        return System.currentTimeMillis() + (int) Math.random() * 10000 + "." + header.split("/")[1];
    }

    @Override
    public String getContentType () {
        return header.split(":")[1];
    }

    @Override
    public boolean isEmpty () {
        return imgContent == null || imgContent.length == 0;
    }

    @Override
    public long getSize () {
        return imgContent.length;
    }

    @Override
    public byte[] getBytes () throws IOException {
        return imgContent;
    }

    @Override
    public InputStream getInputStream () throws IOException {
        return new ByteArrayInputStream(imgContent);
    }

    @Override
    public void transferTo (File dest) throws IOException, IllegalStateException {
        new FileOutputStream(dest).write(imgContent);
    }
}

創建ImageUtils

package top.yangbuyi.utils;

import org.apache.tomcat.util.codec.binary.Base64;
import org.slf4j.Logger;
import org.slf4j.LoggerFactory;
import org.springframework.web.multipart.MultipartFile;

import java.io.ByteArrayInputStream;
import java.io.ByteArrayOutputStream;
import java.io.FileInputStream;
import java.io.InputStream;
import java.net.URL;
import java.net.URLConnection;
import java.util.Arrays;

/**
 * 圖片處理工具類
 *
 * @author yangbuyi.top
 */
public class ImageUtils {
    private static final Logger log = LoggerFactory.getLogger(ImageUtils.class);


    public static MultipartFile base64ToMultipartFile (String base64) {
        String[] baseStrs = base64.split(",");

        //取索引為1的元素進行處理
        byte[] b = Base64.decodeBase64(baseStrs[1]);
        for (int i = 0; i < b.length; ++i) {
            if (b[i] < 0) {
                b[i] += 256;
            }
        }

        //處理過后的資料通過Base64DecodeMultipartFile轉換為MultipartFile物件
        return new Base64DecodeMultipartFile(b, baseStrs[0]);
    }

}

專案基本需要的配置與工具已經創建完畢接下來我們開始人臉識別業務撰寫

實作BasePooledObjectFactory自定義引擎工廠

創建factory檔案夾->創建FaceEngineFactory類

import com.arcsoft.face.EngineConfiguration;
import com.arcsoft.face.FaceEngine;
import com.arcsoft.face.enums.DetectMode;
import com.arcsoft.face.enums.DetectOrient;
import lombok.extern.slf4j.Slf4j;
import org.apache.commons.pool2.BasePooledObjectFactory;
import org.apache.commons.pool2.PooledObject;
import org.apache.commons.pool2.impl.DefaultPooledObject;

/**
 * 引擎工廠
 * @author yangbuyi.top
 */
@Slf4j
public class FaceEngineFactory extends BasePooledObjectFactory<FaceEngine> {

    private final String appId;
    private final String sdkKey;
    private final String sdkLibPath;
    private final EngineConfiguration engineConfiguration;
    private final Integer detectFaceMaxNum = 10;
    private final Integer detectFaceScaleVal = 16;
    private final DetectMode detectMode = DetectMode.ASF_DETECT_MODE_IMAGE;
    private final DetectMode detectVideo = DetectMode.ASF_DETECT_MODE_VIDEO;
    private final DetectOrient detectFaceOrientPriority = DetectOrient.ASF_OP_0_ONLY;


    public FaceEngineFactory (String sdkLibPath, String appId, String sdkKey, EngineConfiguration engineConfiguration) {
        this.sdkLibPath = sdkLibPath;
        this.appId = appId;
        this.sdkKey = sdkKey;
        this.engineConfiguration = engineConfiguration;

    }


    @Override
    public FaceEngine create () throws Exception {
        FaceEngine faceEngine = new FaceEngine(sdkLibPath);
        // 用于在線激活SDK---
        int activeCode = faceEngine.activeOnline(appId, sdkKey);
        log.info("在線激活SDK完畢！,{}", activeCode);
        int initCode = faceEngine.init(engineConfiguration);
        log.info("初始化功能引擎完畢！,{}", initCode);
        return faceEngine;
    }

    @Override
    public PooledObject<FaceEngine> wrap (FaceEngine faceEngine) {
        return new DefaultPooledObject<>(faceEngine);
    }


    @Override
    public void destroyObject (PooledObject<FaceEngine> p) throws Exception {
        FaceEngine faceEngine = p.getObject();
        int unInitCode = faceEngine.unInit();
        super.destroyObject(p);
        log.info("銷毀物件完畢! faceEngineUnInitCode: {}", unInitCode);
    }
}

一、撰寫人臉識別業務介面

在service目錄下創建-> FaceEngineService

package top.yangbuyi.service;

import com.arcsoft.face.FaceInfo;
import com.arcsoft.face.toolkit.ImageInfo;
import top.yangbuyi.dto.FaceUserInfo;
import top.yangbuyi.dto.ProcessInfo;

import java.util.List;
import java.util.concurrent.ExecutionException;

/**
 * 人臉識別介面
 */
public interface FaceEngineService {

    /**
     * 人臉檢測
     * @param imageInfo
     * @return
     */
    List<FaceInfo> detectFaces (ImageInfo imageInfo);

    /**
     * 提取年齡-性別
     * @param imageInfo
     * @return
     */
    List<ProcessInfo> process (ImageInfo imageInfo);

    /**
     * 人臉特征
     * @param imageInfo
     * @return
     */
    byte[] extractFaceFeature (ImageInfo imageInfo) throws InterruptedException;

    /**
     * 人臉比對
     * @param groupId
     * @param faceFeature
     * @return
     */
    List<FaceUserInfo> compareFaceFeature (byte[] faceFeature, Integer groupId) throws InterruptedException, ExecutionException;

}

service.impl 包下創建 FaceEngineServiceImpl 實作類

import cn.hutool.core.collection.CollectionUtil;
import com.arcsoft.face.*;
import com.arcsoft.face.enums.DetectMode;
import com.arcsoft.face.enums.DetectOrient;
import com.arcsoft.face.toolkit.ImageInfo;
import com.google.common.collect.Lists;
import org.apache.commons.pool2.impl.GenericObjectPool;
import org.apache.commons.pool2.impl.GenericObjectPoolConfig;
import org.slf4j.Logger;
import org.slf4j.LoggerFactory;
import org.springframework.beans.factory.annotation.Autowired;
import org.springframework.beans.factory.annotation.Value;
import org.springframework.stereotype.Service;
import top.yangbuyi.dto.FaceUserInfo;
import top.yangbuyi.dto.ProcessInfo;
import top.yangbuyi.factory.FaceEngineFactory;
import top.yangbuyi.mapper.SysUserFaceInfoMapper;
import top.yangbuyi.service.FaceEngineService;

import javax.annotation.PostConstruct;
import java.math.BigDecimal;
import java.util.ArrayList;
import java.util.List;
import java.util.concurrent.*;


/**
 * @author yangbuyi.top
 */
@Service
public class FaceEngineServiceImpl implements FaceEngineService {

    public final static Logger logger = LoggerFactory.getLogger(FaceEngineServiceImpl.class);

    @Value("${config.sdk-lib-path}")
    public String sdkLibPath;

    @Value("${config.app-id}")
    public String appId;

    @Value("${config.sdk-key}")
    public String sdkKey;

    @Value("${config.thread-pool-size}")
    public Integer threadPoolSize;

    /**
     * 人臉識別引擎
     */
    private static FaceEngine faceEngine;

    /**
     * 相似度
     */
    private final Integer passRate = 95;

    private ExecutorService executorService;

    @Autowired
    private SysUserFaceInfoMapper userFaceInfoMapper;

    /**
     * 執行緒池
     */
    private GenericObjectPool<FaceEngine> faceEngineObjectPool;


    /**
     * 專案啟動時初始化執行緒池與人臉識別引擎配置
     */
    @PostConstruct
    public void init () {
        executorService = Executors.newFixedThreadPool(threadPoolSize);
        GenericObjectPoolConfig poolConfig = new GenericObjectPoolConfig();
        poolConfig.setMaxIdle(threadPoolSize);
        poolConfig.setMaxTotal(threadPoolSize);
        poolConfig.setMinIdle(threadPoolSize);
        poolConfig.setLifo(false);

        //引擎配置
        EngineConfiguration engineConfiguration = new EngineConfiguration();
        engineConfiguration.setDetectMode(DetectMode.ASF_DETECT_MODE_IMAGE);
        engineConfiguration.setDetectFaceOrientPriority(DetectOrient.ASF_OP_0_ONLY);

        //功能配置 對應的功能請查看檔案
        FunctionConfiguration functionConfiguration = new FunctionConfiguration();
        functionConfiguration.setSupportAge(true);
        functionConfiguration.setSupportFace3dAngle(true);
        functionConfiguration.setSupportFaceDetect(true);
        functionConfiguration.setSupportFaceRecognition(true);
        functionConfiguration.setSupportGender(true);
        functionConfiguration.setSupportLiveness(true);
        functionConfiguration.setSupportIRLiveness(true);
        engineConfiguration.setFunctionConfiguration(functionConfiguration);

        // 底層庫演算法物件池
        faceEngineObjectPool = new GenericObjectPool(new FaceEngineFactory(sdkLibPath, appId, sdkKey, engineConfiguration), poolConfig);
        try {
            faceEngine = faceEngineObjectPool.borrowObject();
        } catch (Exception e) {
            e.printStackTrace();
        }

    }

    /**
     * 確保精度
     * @param value
     * @return
     */
    private int plusHundred (Float value) {
        BigDecimal target = new BigDecimal(value);
        BigDecimal hundred = new BigDecimal(100f);
        return target.multiply(hundred).intValue();

    }

}

人臉識別邏輯

1、必須進行人臉特征獲取 -> 特征獲取成功 -> 進入人臉對比 -> 人臉檢測 -> 回傳人臉資料
2、必須進行人臉特征獲取 -> 特征獲取失敗 -> 直接跳出回傳 未檢出到人臉

撰寫人臉特征獲取邏輯

/**
 * 人臉特征
 *
 * @param imageInfo
 * @return
 */
@Override
public byte[]extractFaceFeature(ImageInfo imageInfo)throws InterruptedException{

        FaceEngine faceEngine=null;
        try{
        //獲取引擎物件
        faceEngine=faceEngineObjectPool.borrowObject();

        //人臉檢測得到人臉串列
        List<FaceInfo> faceInfoList=new ArrayList<FaceInfo>();

        //人臉檢測
        int i=faceEngine.detectFaces(imageInfo.getImageData(),imageInfo.getWidth(),imageInfo.getHeight(),imageInfo.getImageFormat(),faceInfoList);

        if(CollectionUtil.isNotEmpty(faceInfoList)){
        FaceFeature faceFeature=new FaceFeature();
        //提取人臉特征
        faceEngine.extractFaceFeature(imageInfo.getImageData(),imageInfo.getWidth(),imageInfo.getHeight(),imageInfo.getImageFormat(),faceInfoList.get(0),faceFeature);

        return faceFeature.getFeatureData();
        }
        }catch(Exception e){
        logger.error("",e);
        }finally{
        if(faceEngine!=null){
        //釋放引擎物件
        faceEngineObjectPool.returnObject(faceEngine);
        }

        }

        return null;
        }

撰寫人臉對比邏輯

/**
 * 人臉比對
 * @param groupId
 * @param faceFeature
 * @return 人臉組
 */
@Override
public List<FaceUserInfo> compareFaceFeature(byte[]faceFeature,Integer groupId)throws InterruptedException,ExecutionException{
        // 識別到的人臉串列
        List<FaceUserInfo> resultFaceInfoList=Lists.newLinkedList();
        // 創建人臉特征物件
        FaceFeature targetFaceFeature=new FaceFeature();
        targetFaceFeature.setFeatureData(faceFeature);
        // 根據分組拿人臉庫,從資料庫中取出人臉庫
        List<FaceUserInfo> faceInfoList=userFaceInfoMapper.getUserFaceInfoByGroupId(groupId);
        // 分成50一組，多執行緒處理， 資料量大1000組
        List<List<FaceUserInfo>>faceUserInfoPartList=Lists.partition(faceInfoList,50);
        // 多執行緒
        CompletionService<List<FaceUserInfo>>completionService=new ExecutorCompletionService(executorService);
        for(List<FaceUserInfo> part:faceUserInfoPartList){
        // 開始執行緒掃描人臉匹配度
        completionService.submit(new CompareFaceTask(part,targetFaceFeature));
        }
        // 獲取執行緒任務引數
        for(List<FaceUserInfo> faceUserInfos:faceUserInfoPartList){
        List<FaceUserInfo> faceUserInfoList=completionService.take().get();
        if(CollectionUtil.isNotEmpty(faceInfoList)){
        resultFaceInfoList.addAll(faceUserInfoList);
        }
        }
        // 從大到小排序
        resultFaceInfoList.sort((h1,h2)->h2.getSimilarValue().compareTo(h1.getSimilarValue()));
        return resultFaceInfoList;
        }


/**
 * 多執行緒跑人臉對比邏輯
 */
private class CompareFaceTask implements Callable<List<FaceUserInfo>> {

    private final List<FaceUserInfo> faceUserInfoList;
    private final FaceFeature targetFaceFeature;


    public CompareFaceTask (List<FaceUserInfo> faceUserInfoList, FaceFeature targetFaceFeature) {
        this.faceUserInfoList = faceUserInfoList;
        this.targetFaceFeature = targetFaceFeature;
    }

    @Override
    public List<FaceUserInfo> call () throws Exception {
        FaceEngine faceEngine = null;
        //識別到的人臉串列
        List<FaceUserInfo> resultFaceInfoList = Lists.newLinkedList();
        try {
            faceEngine = faceEngineObjectPool.borrowObject();
            for (FaceUserInfo faceUserInfo : faceUserInfoList) {
                FaceFeature sourceFaceFeature = new FaceFeature();
                // 設定人臉特征
                sourceFaceFeature.setFeatureData(faceUserInfo.getFaceFeature());
                FaceSimilar faceSimilar = new FaceSimilar();
                faceEngine.compareFaceFeature(targetFaceFeature, sourceFaceFeature, faceSimilar);
                //獲取相似值
                Integer similarValue = https://www.cnblogs.com/Yangbuyi/p/plusHundred(faceSimilar.getScore());
                //相似值大于配置預期，加入到識別到人臉的串列
                if (similarValue > passRate) {
                    FaceUserInfo info = new FaceUserInfo();
                    info.setName(faceUserInfo.getName());
                    info.setFaceId(faceUserInfo.getFaceId());
                    info.setSimilarValue(similarValue);
                    resultFaceInfoList.add(info);
                }
            }
        } catch (Exception e) {
            logger.error("", e);
        } finally {
            if (faceEngine != null) {
                faceEngineObjectPool.returnObject(faceEngine);
            }
        }
        return resultFaceInfoList;
    }

}

撰寫根據根據分組ID獲取人臉庫資料

在mapper下SysUserFaceInfoMapper -> 創建介面 getUserFaceInfoByGroupId

/**
 * 根據分組Id
 * 從資料庫中取出人臉庫
 *
 * @param groupId
 * @return 人臉庫
 */
    List<FaceUserInfo> getUserFaceInfoByGroupId(Integer groupId);

sql實作

<resultMap id="userFace2" type="top.yangbuyi.dto.FaceUserInfo">
<id column="id" property="id" javaType="int"/>
<result column="group_id" property="groupId" javaType="java.lang.Integer"/>
<result column="name" property="name" javaType="java.lang.String"/>
<result column="face_id" property="faceId" javaType="String"/>
<result column="face_feature" property="faceFeature"/>
</resultMap>

<
select id = "getUserFaceInfoByGroupId" resultMap="userFace2" parameterType="java.lang.Integer"
        resultType="top.yangbuyi.dto.FaceUserInfo">
select id, group_id, face_id, name, face_feature
from `sys_user_face_info`
where group_id = #{groupId}
          < /
select>

二、撰寫人臉添加業務介面

userFaceInfoService 新增人臉業務介面

    /**
 * 新增用戶人臉識別
 *
 * @param sysUserFaceInfo 用戶人臉識別
 * @return 結果
 */
public int insertSysUserFaceInfo(SysUserFaceInfo sysUserFaceInfo);

就是一共簡簡單單的新增插入資料 這個就不用我教了吧？？？？？？？？？

三、 撰寫Controller業務控制層

import top.yangbuyi.domain.AjaxResult;

/**
 * (sys_user_face_info)表控制層
 *
 * @author yangbuyi.top
 */
@RestController
@Slf4j
@RequestMapping("face")
@RequiredArgsConstructor
public class SysUserFaceInfoController {
    public final static Logger logger = LoggerFactory.getLogger(SysUserFaceInfoController.class);

    private final FaceEngineService faceEngineService;

    private final SysUserFaceInfoService userFaceInfoService;


    /**
     * 人臉添加
     *
     * @param file    人臉附件
     * @param groupId 分組id
     * @param name    用戶登錄名稱
     */
    @RequestMapping(value = "https://www.cnblogs.com/faceAdd", method = RequestMethod.POST)
    public AjaxResult faceAdd (@RequestBody Map<String, Object> map) {
        // 業務.... yangbuyi.top 著作權所有
        return AjaxResult.success();
    }


    /**
     * 人臉識別
     *
     * @param file    人臉附件
     * @param groupId 分組ID 方便快速識別
     */
    @RequestMapping(value = "https://www.cnblogs.com/faceSearch", method = RequestMethod.POST)
    public AjaxResult faceSearch (@RequestBody Map<String, Object> map) throws Exception {
        // 業務... yangbuyi.top 著作權所有
        return AjaxResult.success();
    }

faceAdd 具體業務撰寫

1. 根據前端傳遞的
   file -> 人臉圖片
   groupId -> 用戶分組(用于縮小范圍查詢該人員的位置有效減少資料量大的問題)
   name -> 當前用戶名稱(實際開發當中應該是存盤id)

        String file = String.valueOf(map.get("file"));
        String groupId = String.valueOf(map.get("groupId"));
        String name = String.valueOf(map.get("name"));
        try {
            if (file == null) {
                return AjaxResult.error("file is null");
            }
            if (groupId == null) {
                return AjaxResult.error("file is null");
            }
            if (name == null) {
                return AjaxResult.error("file is null");
            }
            // 轉換物體
            byte[] decode = Base64.decode(base64Process(file));
            ImageInfo imageInfo = ImageFactory.getRGBData(decode);

            //人臉特征獲取
            byte[] bytes = faceEngineService.extractFaceFeature(imageInfo);
            if (bytes == null) {
                return AjaxResult.error(ErrorCodeEnum.NO_FACE_DETECTED.getDescription());
            }
            List<ProcessInfo> processInfoList = faceEngineService.process(imageInfo);
            // 開始將人臉識別Base64轉換檔案流->用于檔案上傳
            // final MultipartFile multipartFile = ImageUtils.base64ToMultipartFile(file);
            final SysUserFaceInfo one = this.userFaceInfoService.lambdaQuery().eq(SysUserFaceInfo::getName, name).one();
            // 如果存在則更新人臉和特征
            if (null != one) {
                this.userFaceInfoService.lambdaUpdate().set(SysUserFaceInfo::getFaceFeature, bytes)
                        .set(SysUserFaceInfo::getFpath, "存盤頭像地址")
                        .eq(SysUserFaceInfo::getFaceId, name).update();
            } else {
                // 組裝人臉物體
                SysUserFaceInfo userFaceInfo = new SysUserFaceInfo();
                userFaceInfo.setName(name);
                userFaceInfo.setAge(processInfoList.get(0).getAge());
                userFaceInfo.setGender(processInfoList.get(0).getGender().shortValue());
                userFaceInfo.setGroupId(Integer.valueOf(groupId));
                userFaceInfo.setFaceFeature(bytes);
                userFaceInfo.setFpath("存盤頭像地址");
                // 存盤用戶ID -> 我這里先使用name代替 -> 假如是唯一性
                userFaceInfo.setFaceId(name);
                //人臉特征插入到資料庫
                userFaceInfoService.insertSysUserFaceInfo(userFaceInfo);
            }
            logger.info("faceAdd:" + name);
            return AjaxResult.success("人臉系結成功!");
        } catch (Exception e) {
            logger.error("", e);
        }
        // 錯誤回傳
        return AjaxResult.error(ErrorCodeEnum.UNKNOWN.getDescription());

faceSearch 具體業務撰寫

1. 根據前端傳遞的
   file -> 人臉圖片
   groupId -> 用戶分組(用于縮小范圍查詢該人員的位置有效減少資料量大的問題)

String file = String.valueOf(map.get("file"));
        String groupId = String.valueOf(map.get("groupId"));

        if (groupId == null) {
            return AjaxResult.error("groupId is null");
        }
        byte[] decode = Base64.decode(base64Process(file));
        BufferedImage bufImage = ImageIO.read(new ByteArrayInputStream(decode));
        ImageInfo imageInfo = ImageFactory.bufferedImage2ImageInfo(bufImage);


        //人臉特征獲取
        byte[] bytes = faceEngineService.extractFaceFeature(imageInfo);
        // 校驗是否顯示出人臉
        if (bytes == null) {
            return AjaxResult.error(ErrorCodeEnum.NO_FACE_DETECTED.getDescription());
        }

        //人臉比對，獲取比對結果
        List<FaceUserInfo> userFaceInfoList = faceEngineService.compareFaceFeature(bytes, Integer.valueOf(groupId));

        if (CollectionUtil.isNotEmpty(userFaceInfoList)) {
            FaceUserInfo faceUserInfo = userFaceInfoList.get(0);
            FaceSearchResDto faceSearchResDto = new FaceSearchResDto();
            BeanUtil.copyProperties(faceUserInfo, faceSearchResDto);
            List<ProcessInfo> processInfoList = faceEngineService.process(imageInfo);
            if (CollectionUtil.isNotEmpty(processInfoList)) {
                //人臉檢測
                List<FaceInfo> faceInfoList = faceEngineService.detectFaces(imageInfo);
                int left = faceInfoList.get(0).getRect().getLeft();
                int top = faceInfoList.get(0).getRect().getTop();
                int width = faceInfoList.get(0).getRect().getRight() - left;
                int height = faceInfoList.get(0).getRect().getBottom() - top;

                Graphics2D graphics2D = bufImage.createGraphics();
                // 紅色
                graphics2D.setColor(Color.RED);
                BasicStroke stroke = new BasicStroke(5f);
                graphics2D.setStroke(stroke);
                graphics2D.drawRect(left, top, width, height);
                ByteArrayOutputStream outputStream = new ByteArrayOutputStream();
                ImageIO.write(bufImage, "jpg", outputStream);
                byte[] bytes1 = outputStream.toByteArray();
                faceSearchResDto.setAge(processInfoList.get(0).getAge());
                faceSearchResDto.setGender(processInfoList.get(0).getGender().equals(1) ? "女" : "男");
            }
            return AjaxResult.success(faceSearchResDto);
        }
        return AjaxResult.error(ErrorCodeEnum.FACE_DOES_NOT_MATCH.getDescription());

測驗介面流程

準備兩張圖片
百度隨便搜索個在線轉換 Base64

(在線圖片轉Base64)

1、人臉添加

新增有臉的

新增測驗無臉的

2、人臉識別

有臉的

無臉的

結尾在線演示

(前往享受人臉識別)

標籤：Java

上一篇：OutputStream詳解

下一篇：Java執行緒數過多解決之路——利用Arthas解決Jenkins執行緒數飆升問題
