這里給大家分享我在網上總結出來的一些知識，希望對大家有所幫助
說明
基于uni-app開發，呼叫官方藍牙相關api實作連接藍牙與向藍牙熱敏列印機發送位元組流，可列印文字，二維碼，圖片，調整字體大小等，本文提供大概思路
結構
- bluetooth.js 藍牙連接相關模塊封裝
- commands.js 列印十六進制相關代碼庫
- gbk.js 編碼轉換庫地址
- printerjobs.js 列印實作庫
bluetooth.js
藍牙連接相關封裝代碼
class Bluetooth {
constructor() {
this.isOpenBle = false;
this.deviceId = "";
this.serviceId = "";
this.writeId = "";
this.notifyId = "";
this.BluetoothConnectStatus = false this.printStatus = false this.init()
}
init() {
this.closeBluetoothAdapter().then(() = >{
console.log("init初始關閉藍牙模塊") this.openBluetoothAdapter().then(() = >{
console.log("init初始化藍牙模塊") this.reconnect() //自動連接藍牙設備
})
})
}
showToast(title) {
uni.showToast({
title: title,
icon: 'none',
'duration': 2000
});
}
openBluetoothAdapter() {
return new Promise((resolve, reject) = >{
uni.openBluetoothAdapter({
success: res = >{
this.isOpenBle = true;
resolve(res);
},
fail: err = >{
this.showToast(`藍牙未打開`);
reject(err);
},
});
});
}
startBluetoothDevicesDiscovery() {
if (!this.isOpenBle) {
this.showToast(`初始化藍牙模塊失敗`) return;
}
let self = this;
uni.showLoading({
title: '藍牙搜索中'
}) return new Promise((resolve, reject) = >{
setTimeout(() = >{
uni.startBluetoothDevicesDiscovery({
success: res = >{
resolve(res)
},
fail: res = >{
self.showToast(`搜索設備失敗` + JSON.stringify(err));
reject(err);
}
})
},
300);
});
}
stopBluetoothDevicesDiscovery() {
let self = this;
return new Promise((resolve, reject) = >{
uni.stopBluetoothDevicesDiscovery({
success: e = >{
uni.hideLoading();
},
fail: e = >{
uni.hideLoading();
self.showToast(`停止搜索藍牙設備失敗` + JSON.stringify(err));
}
})
});
}
createBLEConnection() {
//設備deviceId
let deviceId = this.deviceId;
let self = this;
// uni.showLoading({
// mask: true,
// title: '設別連接中,請稍候...'
// })
console.log(this.deviceId);
return new Promise((resolve, reject) = >{
uni.createBLEConnection({
deviceId,
success: (res) = >{
console.log("res:createBLEConnection " + JSON.stringify(res));
resolve(res)
},
fail: err = >{
uni.hideLoading();
self.showToast(`停止搜索藍牙設備失敗` + JSON.stringify(err));
reject(err);
}
})
});
}
//獲取藍牙設備所有服務(service)
getBLEDeviceServices() {
let _serviceList = [];
let deviceId = this.deviceId;
let self = this;
return new Promise((resolve, reject) = >{
setTimeout(() = >{
uni.getBLEDeviceServices({
deviceId,
success: res = >{
for (let service of res.services) {
if (service.isPrimary) {
_serviceList.push(service);
}
}
uni.hideLoading();
console.log("_serviceList: " + JSON.stringify(_serviceList));
resolve(_serviceList)
},
fail: err = >{
uni.hideLoading();
// self.showToast(`獲取設備Services` + JSON.stringify(err));
reject(err);
},
})
},
500);
});
}
//獲取藍牙設備某個服務中所有特征值(characteristic)
getBLEDeviceCharacteristics() {
// console.log("getBLEDeviceCharacteristics")
let deviceId = this.deviceId;
let serviceId = this.serviceId;
let self = this;
return new Promise((resolve, reject) = >{
uni.getBLEDeviceCharacteristics({
deviceId,
serviceId,
success: res = >{
for (let _obj of res.characteristics) {
//獲取notify
if (_obj.properties.notify) {
self.notifyId = _obj.uuid;
uni.setStorageSync('notifyId', self.notifyId);
}
//獲取writeId
if (_obj.properties.write) {
self.writeId = _obj.uuid;
uni.setStorageSync('writeId', self.writeId);
}
}
//console.log("res:getBLEDeviceCharacteristics " + JSON.stringify(res));
let result = {
'notifyId': self.notifyId,
'writeId': self.writeId
};
// self.showToast(`獲取服務中所有特征值OK,${JSON.stringify(result)}`);
this.BluetoothStatus = true resolve(result)
},
fail: err = >{
self.showToast(`getBLEDeviceCharacteristics` + JSON.stringify(err));
reject(err);
}
})
});
}
//斷開聯鏈接
closeBLEConnection() {
let deviceId = this.deviceId;
uni.closeBLEConnection({
deviceId,
success(res) {
console.log("closeBLEConnection" + res)
}
})
}
notifyBLECharacteristicValue() {
let deviceId = this.deviceId;
let serviceId = this.serviceId;
let characteristicId = this.notifyId;
uni.notifyBLECharacteristicValueChange({
state: true,
// 啟用 notify 功能
deviceId,
serviceId,
characteristicId,
success(res) {
uni.onBLECharacteristicValueChange(function(res) {
console.log('onBLECharacteristicValueChange', res);
});
},
fail(res) {
console.log('notifyBLECharacteristicValueChange failed:' + res.errMsg);
}
});
}
writeBLECharacteristicValue(buffer) {
let deviceId = this.deviceId;
let serviceId = this.serviceId;
let characteristicId = this.writeId;
// console.log(deviceId);
// console.log(serviceId);
// console.log(characteristicId);
return new Promise((resolve, reject) = >{
uni.writeBLECharacteristicValue({
deviceId,
serviceId,
characteristicId,
value: buffer,
success(res) {
// console.log('message發送成功', JSON.stringify(res));
resolve(res);
},
fail(err) {
// console.log('message發送失敗', JSON.stringify(err));
reject(err);
}
});
});
}
closeBluetoothAdapter() {
return new Promise((resolve, reject) = >{
uni.closeBluetoothAdapter({
success: res = >{
resolve()
}
});
})
}
//若APP在之前已有搜索過某個藍牙設備，并成功建立連接，可直接傳入之前搜索獲取的 deviceId 直接嘗試連接該設備，無需進行搜索操作，
reconnect() { (async() = >{
try {
this.deviceId = this.deviceId || uni.getStorageSync("deviceId");
this.serviceId = this.serviceId || uni.getStorageSync("serviceId");
console.log("this.deviceId", this.deviceId) console.log("this.serviceId", this.serviceId) let result1 = await this.createBLEConnection();
console.log("createBLEConnection: " + JSON.stringify(result1));
let result2 = await this.getBLEDeviceServices();
console.log("getBLEDeviceServices: " + JSON.stringify(result2));
let result3 = await this.getBLEDeviceCharacteristics();
console.log("getBLEDeviceCharacteristics: " + JSON.stringify(result3));
this.BluetoothConnectStatus = true this.showToast("藍牙列印設備連接成功")
// this.writeId = uni.getStorageSync("writeId");
// this.notifyId = uni.getStorageSync("notifyId");
} catch(err) {
console.log("err: " + err);
// this.showToast("藍牙列印設備連接失敗")
}
})();
}
}
export
default Bluetooth;
commands.js
列印機ESC/POS十六進制編碼庫
/**
* 修改自https://github.com/song940/node-escpos/blob/master/commands.js
* ESC/POS _ (Constants)
*/
var _ = {
LF: [0x0a],
FS: [0x1c],
FF: [0x0c],
GS: [0x1d],
DLE: [0x10],
EOT: [0x04],
NUL: [0x00],
ESC: [0x1b],
EOL: '\n',
};
/**
* [FEED_CONTROL_SEQUENCES Feed control sequences]
* @type {Object}
*/
_.FEED_CONTROL_SEQUENCES = {
CTL_LF: [0x0a], // Print and line feed
CTL_GLF: [0x4a, 0x00], // Print and feed paper (without spaces between lines)
CTL_FF: [0x0c], // Form feed
CTL_CR: [0x0d], // Carriage return
CTL_HT: [0x09], // Horizontal tab
CTL_VT: [0x0b], // Vertical tab
};
_.CHARACTER_SPACING = {
CS_DEFAULT: [0x1b, 0x20, 0x00],
CS_SET: [0x1b, 0x20]
};
_.LINE_SPACING = {
LS_DEFAULT: [0x1b, 0x32],
LS_SET: [0x1b, 0x33]
};
/**
* [HARDWARE Printer hardware]
* @type {Object}
*/
_.HARDWARE = {
HW_INIT: [0x1b, 0x40], // Clear data in buffer and reset modes
HW_SELECT: [0x1b, 0x3d, 0x01], // Printer select
HW_RESET: [0x1b, 0x3f, 0x0a, 0x00], // Reset printer hardware
Print:[0x1b, 0x64,0x01] //Print and feed paper
};
/**
* [CASH_DRAWER Cash Drawer]
* @type {Object}
*/
_.CASH_DRAWER = {
CD_KICK_2: [0x1b, 0x70, 0x00], // Sends a pulse to pin 2 []
CD_KICK_5: [0x1b, 0x70, 0x01], // Sends a pulse to pin 5 []
};
/**
* [MARGINS Margins sizes]
* @type {Object}
*/
_.MARGINS = {
BOTTOM: [0x1b, 0x4f], // Fix bottom size
LEFT: [0x1b, 0x6c], // Fix left size
RIGHT: [0x1b, 0x51], // Fix right size
};
/**
* [PAPER Paper]
* @type {Object}
*/
_.PAPER = {
PAPER_FULL_CUT: [0x1d, 0x56, 0x00], // Full cut paper
PAPER_PART_CUT: [0x1d, 0x56, 0x01], // Partial cut paper
PAPER_CUT_A: [0x1d, 0x56, 0x41], // Partial cut paper
PAPER_CUT_B: [0x1d, 0x56, 0x42], // Partial cut paper
};
/**
* [TEXT_FORMAT Text format]
* @type {Object}
*/
_.TEXT_FORMAT = {
TXT_NORMAL: [0x1b, 0x21, 0x00], // Normal text
TXT_2HEIGHT: [0x1b, 0x21, 0x10], // Double height text
TXT_2WIDTH: [0x1b, 0x21, 0x20], // Double width text
TXT_4SQUARE: [0x1b, 0x21, 0x30], // Double width & height text
TXT_UNDERL_OFF: [0x1b, 0x2d, 0x00], // Underline font OFF
TXT_UNDERL_ON: [0x1b, 0x2d, 0x01], // Underline font 1-dot ON
TXT_UNDERL2_ON: [0x1b, 0x2d, 0x02], // Underline font 2-dot ON
TXT_BOLD_OFF: [0x1b, 0x45, 0x00], // Bold font OFF
TXT_BOLD_ON: [0x1b, 0x45, 0x01], // Bold font ON
TXT_ITALIC_OFF: [0x1b, 0x35], // Italic font ON
TXT_ITALIC_ON: [0x1b, 0x34], // Italic font ON
TXT_FONT_A: [0x1b, 0x4d, 0x00], // Font type A
TXT_FONT_B: [0x1b, 0x4d, 0x01], // Font type B
TXT_FONT_C: [0x1b, 0x4d, 0x02], // Font type C
TXT_ALIGN_LT: [0x1b, 0x61, 0x00], // Left justification
TXT_ALIGN_CT: [0x1b, 0x61, 0x01], // Centering
TXT_ALIGN_RT: [0x1b, 0x61, 0x02], // Right justification
};
/**
* [BARCODE_FORMAT Barcode format]
* @type {Object}
*/
_.BARCODE_FORMAT = {
BARCODE_TXT_OFF: [0x1d, 0x48, 0x00], // HRI barcode chars OFF
BARCODE_TXT_ABV: [0x1d, 0x48, 0x01], // HRI barcode chars above
BARCODE_TXT_BLW: [0x1d, 0x48, 0x02], // HRI barcode chars below
BARCODE_TXT_BTH: [0x1d, 0x48, 0x03], // HRI barcode chars both above and below
BARCODE_FONT_A: [0x1d, 0x66, 0x00], // Font type A for HRI barcode chars
BARCODE_FONT_B: [0x1d, 0x66, 0x01], // Font type B for HRI barcode chars
BARCODE_HEIGHT: function (height) { // Barcode Height [1-255]
return [0x1d, 0x68, height];
},
BARCODE_WIDTH: function (width) { // Barcode Width [2-6]
return [0x1d, 0x77, width];
},
BARCODE_HEIGHT_DEFAULT: [0x1d, 0x68, 0x64], // Barcode height default:100
BARCODE_WIDTH_DEFAULT: [0x1d, 0x77, 0x01], // Barcode width default:1
BARCODE_UPC_A: [0x1d, 0x6b, 0x00], // Barcode type UPC-A
BARCODE_UPC_E: [0x1d, 0x6b, 0x01], // Barcode type UPC-E
BARCODE_EAN13: [0x1d, 0x6b, 0x02], // Barcode type EAN13
BARCODE_EAN8: [0x1d, 0x6b, 0x03], // Barcode type EAN8
BARCODE_CODE39: [0x1d, 0x6b, 0x04], // Barcode type CODE39
BARCODE_ITF: [0x1d, 0x6b, 0x05], // Barcode type ITF
BARCODE_NW7: [0x1d, 0x6b, 0x06], // Barcode type NW7
BARCODE_CODE93: [0x1d, 0x6b, 0x48], // Barcode type CODE93
BARCODE_CODE128: [0x1d, 0x6b, 0x49], // Barcode type CODE128
};
/**
* [IMAGE_FORMAT Image format]
* @type {Object}
*/
_.IMAGE_FORMAT = {
S_RASTER_N: [0x1d, 0x76, 0x30, 0x00], // Set raster image normal size
S_RASTER_2W: [0x1d, 0x76, 0x30, 0x01], // Set raster image double width
S_RASTER_2H: [0x1d, 0x76, 0x30, 0x02], // Set raster image double height
S_RASTER_Q: [0x1d, 0x76, 0x30, 0x03], // Set raster image quadruple
};
/**
* [BITMAP_FORMAT description]
* @type {Object}
*/
_.BITMAP_FORMAT = {
BITMAP_S8: [0x1b, 0x2a, 0x00],
BITMAP_D8: [0x1b, 0x2a, 0x01],
BITMAP_S24: [0x1b, 0x2a, 0x20],
BITMAP_D24: [0x1b, 0x2a, 0x21]
};
/**
* [GSV0_FORMAT description]
* @type {Object}
*/
_.GSV0_FORMAT = {
GSV0_NORMAL: [0x1d, 0x76, 0x30, 0x00],
GSV0_DW: [0x1d, 0x76, 0x30, 0x01],
GSV0_DH: [0x1d, 0x76, 0x30, 0x02],
GSV0_DWDH: [0x1d, 0x76, 0x30, 0x03]
};
/**
* [BEEP description]
* @type {string}
*/
_.BEEP = [0x1b, 0x42]; // Printer Buzzer pre hex
/**
* [COLOR description]
* @type {Object}
*/
_.COLOR = {
0: [0x1b, 0x72, 0x00], // black
1: [0x1b, 0x72, 0x01] // red
};
/**
* [exports description]
* @type {[type]}
*/
module.exports = _;
printerjobs.js
const commands = require('./commands');
const gbk = require('./gbk');
const printerJobs = function() {
this._queue = Array.from(commands.HARDWARE.HW_INIT);
this._enqueue = function(cmd) {
this._queue.push.apply(this._queue, cmd);
}
};
/**
* 增加列印內容
* @param {string} content 文字內容
*/
printerJobs.prototype.text = function(content) {
if (content) {
let uint8Array = gbk.encode(content);
let encoded = Array.from(uint8Array);
this._enqueue(encoded);
}
return this;
};
/**
* 列印文字
* @param {string} content 文字內容
*/
printerJobs.prototype.print = function(content) {
this.text(content);
// this._enqueue(commands.LF);
return this;
};
printerJobs.prototype.printL = function(content) {
this.text(content);
this._enqueue(commands.LF);
return this;
};
printerJobs.prototype.printImage = function(content) {
if (content) {
const cmds = [].concat([29, 118, 48, 0], content);
// console.log("cmds",cmds)
this._enqueue(cmds);
this._enqueue(commands.LF);
}
return this;
};
/**
* 列印文字并換行
* @param {string} content 文字內容
*/
printerJobs.prototype.println = function(content = '') {
return this.print(content + commands.EOL);
};
/**
* 設定對齊方式
* @param {string} align 對齊方式 LT/CT/RT
*/
printerJobs.prototype.setAlign = function(align) {
this._enqueue(commands.TEXT_FORMAT['TXT_ALIGN_' + align.toUpperCase()]);
return this;
};
/**
* 設定字體
* @param {string} family A/B/C
*/
printerJobs.prototype.setFont = function(family) {
this._enqueue(commands.TEXT_FORMAT['TXT_FONT_' + family.toUpperCase()]);
return this;
};
/**
* 設定字體尺寸
* @param {number} width 字體寬度 1~2
* @param {number} height 字體高度 1~2
*/
printerJobs.prototype.setSize = function(width, height) {
if (2 >= width && 2 >= height) {
this._enqueue(commands.TEXT_FORMAT.TXT_NORMAL);
if (2 === width && 2 === height) {
this._enqueue(commands.TEXT_FORMAT.TXT_4SQUARE);
} else if (1 === width && 2 === height) {
this._enqueue(commands.TEXT_FORMAT.TXT_2HEIGHT);
} else if (2 === width && 1 === height) {
this._enqueue(commands.TEXT_FORMAT.TXT_2WIDTH);
}
}
return this;
};
/**
* 設定字體是否加粗
* @param {boolean} bold
*/
printerJobs.prototype.setBold = function(bold) {
if (typeof bold !== 'boolean') {
bold = true;
}
this._enqueue(bold ? commands.TEXT_FORMAT.TXT_BOLD_ON : commands.TEXT_FORMAT.TXT_BOLD_OFF);
return this;
};
/**
* 設定是否開啟下劃線
* @param {boolean} underline
*/
printerJobs.prototype.setUnderline = function(underline) {
if (typeof underline !== 'boolean') {
underline = true;
}
this._enqueue(underline ? commands.TEXT_FORMAT.TXT_UNDERL_ON : commands.TEXT_FORMAT.TXT_UNDERL_OFF);
return this;
};
/**
* 設定行間距為 n 點行,默認值行間距是 30 點
* @param {number} n 0≤n≤255
*/
printerJobs.prototype.setLineSpacing = function(n) {
if (n === undefined || n === null) {
this._enqueue(commands.LINE_SPACING.LS_DEFAULT);
} else {
this._enqueue(commands.LINE_SPACING.LS_SET);
this._enqueue([n]);
}
return this;
};
/**
* 列印空行
* @param {number} n
*/
printerJobs.prototype.lineFeed = function(n = 1) {
return this.print(new Array(n).fill(commands.EOL).join(''));
};
/**
* 設定字體顏色，需要列印機支持
* @param {number} color - 0 默認顏色黑色 1 紅色
*/
printerJobs.prototype.setColor = function(color) {
this._enqueue(commands.COLOR[color === 1 ? 1 : 0]);
return this;
};
/**
* https://support.loyverse.com/hardware/printers/use-the-beeper-in-a-escpos-printers
* 蜂鳴警報，需要列印機支持
* @param {number} n 蜂鳴次數,1-9
* @param {number} t 蜂鳴長短,1-9
*/
printerJobs.prototype.beep = function(n, t) {
this._enqueue(commands.BEEP);
this._enqueue([n, t]);
return this;
};
/**
* 清空任務
*/
printerJobs.prototype.clear = function() {
this._queue = Array.from(commands.HARDWARE.HW_RESET);
// this._enqueue(commands.HARDWARE.Print);
return this;
};
/**
* 回傳ArrayBuffer
*/
printerJobs.prototype.buffer = function() {
return new Uint8Array(this._queue).buffer;
};
module.exports = printerJobs;
代碼實作
封裝藍牙連接，搜索，斷開相關操作模塊
藍牙搜索
startBluetoothDeviceDiscovery() {
let self = this;
self.tempDeviceList = [];
uni.startBluetoothDevicesDiscovery({
success: res = >{
uni.onBluetoothDeviceFound(devices = >{
// console.log("發現設備: " + JSON.stringify(devices));
if (!self.tempDeviceList.some(item = >{
return item.deviceId === devices.devices[0].deviceId || item.name === devices.devices[0].name
})) {
// console.log("new", devices.devices)
self.tempDeviceList.push(devices.devices[0])
}
});
this.connect = false this.$refs.popup.open()
},
fail: err = >{
uni.showToast({
title: '搜索設備失敗' + JSON.stringify(err),
icon: 'none'
})
}
})
},
搜索完成選擇設備
async select_deviceId(item) {
this.deviceId = item.deviceId;
this.$bluetooth.deviceId = item.deviceId;
uni.setStorageSync('deviceId', this.$bluetooth.deviceId);
this.serviceList = [];
try {
//1.鏈接設備
let result = await this.$bluetooth.createBLEConnection();
//2.尋找服務
let result2 = null setTimeout(async() = >{
result2 = await this.$bluetooth.getBLEDeviceServices();
console.log("獲取服務: " + JSON.stringify(result2));
this.serviceList = result2;
console.log("serviceList", this.serviceList.length)
if (this.serviceList[2].uuid) {
this.select_service(this.serviceList[2].uuid)
} else {
uni.showToast({
title: '不是列印設備',
icon: 'none'
})
}
},
1000)
} catch(e) {
//TODO handle the exception
console.log("e: " + JSON.stringify(e));
}
},
選中服務
async select_service(res) {
console.log("select_service", res)
this.$bluetooth.serviceId = res;
console.log("this.$bluetooth.serviceId", this.$bluetooth.serviceId) uni.setStorageSync('serviceId', res);
try {
let result = await this.$bluetooth.getBLEDeviceCharacteristics();
console.log("resultresult", result) this.$refs.popup.close()
uni.showToast({
title: "連接成功"
})
// this.pickUpOnce()
} catch(e) {
//TODO handle the exception
console.log("e: " + JSON.stringify(e));
}
},
列印內容組合
async writeBLECharacteristicValueTongzhishu() {
let Qrcode_res = await this.get_Qrcode()
let sign = await this.getSign()
console.log("sign")
let printerJobs = new PrinterJobs()
let p = printerJobs.setAlign('ct')
.setBold(true)
.printL("列印測驗")
let buffer = printerJobs.buffer();
this.printbuffs(buffer);
},
列印內容組合
主要是實作列印編碼推送回圈，手機藍牙可能出現編碼發送失敗情況，這個時候就是要回圈保證每個位元組準確推送
printbuffs(buffer, fun) {
console.log("printbuffs", buffer.byteLength) const maxChunk = 8;
let p = Promise.resolve();
for (let i = 0, j = 0, length = buffer.byteLength; i < length; i += maxChunk, j++) {
let subPackage = buffer.slice(i, i + maxChunk <= length ? (i + maxChunk) : length);
p = p.then(() = >{
if (i == 0) {
this.$bluetooth.printStatus = true this.$refs.loading.open();
}
if ((i + maxChunk) >= length) {
console.log("printEnd")
setTimeout(() = >{
this.$bluetooth.printStatus = false this.$refs.loading.close();
},
1000)
}
return this.printbuff(subPackage)
})
}
p = p.then(() = >{
console.log("printEve") fun()
})
},
async printbuff(buffer) {
while (true) {
try {
await this.$bluetooth.writeBLECharacteristicValue(buffer);
break;
} catch(e) {}
}
},
本文轉載于:
https://juejin.cn/post/7001752261722537991
如果對您有所幫助，歡迎您點個關注，我會定時更新技術檔案，大家一起討論學習，一起進步，
轉載請註明出處，本文鏈接：https://www.uj5u.com/qiye/507233.html
標籤：其他
上一篇：基于 vite 創建 vue3 全家桶專案（vite + vue3 + tsx + pinia）
下一篇：jsonp跨域
