求C#和AE代碼

uj5u.com熱心網友回復：

using System;

using System.Collections.Generic;

using System.ComponentModel;

using System.Data;

using System.Drawing;

using System.Linq;

using System.Text;

using System.Threading.Tasks;

using System.Windows.Forms;

using ESRI.ArcGIS.Carto;

using ESRI.ArcGIS.Controls;

using ESRI.ArcGIS.DataSourcesFile;

using ESRI.ArcGIS.DataSourcesGDB;

using ESRI.ArcGIS.Display;

using ESRI.ArcGIS.esriSystem;

using ESRI.ArcGIS.Geodatabase;

using ESRI.ArcGIS.Geometry;

using ESRI.ArcGIS.Output;

using ESRI.ArcGIS.SystemUI;



namespace WindowsFormsApplication1

{

    public partial class Form1 : Form

    {

        public Form1()

        {

            InitializeComponent();

        }



        // 確定

        private void button1_Click(object sender, EventArgs e)

        {

            // 創建點圖層

            IFeatureClass pPointFeatureClass = CreateShapefile(@"E:\Users\DSF\Desktop\point.shp", esriGeometryType.esriGeometryPoint);



            // 創建線圖層

            IFeatureClass pPolylineFeatureClass = CreateShapefile(@"E:\Users\DSF\Desktop\polyline.shp", esriGeometryType.esriGeometryPolyline);



            // 創建面圖層

            IFeatureClass pPolygonFeatureClass = CreateShapefile(@"E:\Users\DSF\Desktop\polygon.shp", esriGeometryType.esriGeometryPolygon);

        }



        // 創建shp檔案

        private IFeatureClass CreateShapefile(string filePath, esriGeometryType geometryType)

        {

            ISpatialReferenceFactory pSpatialReferenceFactory = new SpatialReferenceEnvironment();

            IGeographicCoordinateSystem pGeographicCoordinateSystem = pSpatialReferenceFactory.CreateGeographicCoordinateSystem((int)esriSRGeoCSType.esriSRGeoCS_WGS1984);



            // 幾何型別

            IGeometryDef pGeometryDef = new GeometryDef();

            IGeometryDefEdit pGeometryDefEdit = pGeometryDef as IGeometryDefEdit;

            pGeometryDefEdit.GeometryType_2 = geometryType;

            pGeometryDefEdit.HasM_2 = false;

            pGeometryDefEdit.HasZ_2 = false;

            pGeometryDefEdit.SpatialReference_2 = pGeographicCoordinateSystem;



            // 欄位集合

            IFields pFields = new Fields();

            IFieldsEdit pFieldsEdit = pFields as IFieldsEdit;



            // Shape欄位

            IField pField = new Field();

            IFieldEdit pFieldEdit = pField as IFieldEdit;

            pFieldEdit.Type_2 = esriFieldType.esriFieldTypeGeometry;

            pFieldEdit.GeometryDef_2 = pGeometryDef;

            pFieldEdit.AliasName_2 = "Shape";

            pFieldEdit.Name_2 = "Shape";

            pFieldEdit.IsNullable_2 = false;

            pFieldEdit.Required_2 = true;

            pFieldsEdit.AddField(pField);



            // A欄位

            pField = new Field();

            pFieldEdit = pField as IFieldEdit;

            pFieldEdit.Type_2 = esriFieldType.esriFieldTypeString;

            pFieldEdit.AliasName_2 = "A";

            pFieldEdit.Name_2 = "A";

            pFieldEdit.Length_2 = 254;

            pFieldsEdit.AddField(pField);



            // 創建shp

            IWorkspaceFactory pWorkspaceFactory = new ShapefileWorkspaceFactory();

            IWorkspace pWorkspace = pWorkspaceFactory.OpenFromFile(System.IO.Path.GetDirectoryName(filePath), 0);

            IFeatureWorkspace pFeatureWorkspace = pWorkspace as IFeatureWorkspace;

            return pFeatureWorkspace.CreateFeatureClass(System.IO.Path.GetFileName(filePath), pFields, null, null, esriFeatureType.esriFTSimple, "Shape", "");

        }

    }

}

標籤：C#
