使用背景：
關于滑動驗證碼的使用場所還是非常多的，如： 調取短信介面之前，和 注冊請求之前 或者 頻繁會呼叫的介面 都需要加這個拼圖驗證，這里先上一下效果圖吧（心中無碼，自然高清），
話不多說，開擼！
實作分析：
滑動驗證碼的邏輯也很簡單，大概說一下：
1，服務器生成主圖+附圖（從主圖裁剪下來的不需要管y坐標）并且存盤X坐標；
2，前端傳入本地X坐標到服務器，
3，服務器進行計算存盤X坐標和本地X坐標相差值；
4，驗證相差值是否在 0-2 之間，判斷 true | false
后端代碼：
準備：
增加SlideCaptcha檔案夾，并且增加Captcha.cs CaptchaModel.cs Config.cs ImgFormat.cs 4個檔案，分別是：驗證，驗證物體，配置和圖片生成類，代碼如下：
Captcha.cs
CaptchaModel.cs
using System; using System.Collections.Generic; using System.Drawing; using System.Linq; using System.Text; namespace SliderCaptcha.NET { public class CaptchaModel { public int X { get; set; } public int Y { get; set; } public Image Background { get; set; } public Image Slide { get; set; } } public class Captcha64Model { public int X { get; set; } public int Y { get; set; } public string Background { get; set; } public string Slide { get; set; } } }
Config.cs
using System; namespace SliderCaptcha.NET { public class Config { /// <summary> /// 矩形寬 /// </summary> public static int l = 42; /// <summary> /// 圓形半徑 /// </summary> public static int r = 9; /// <summary> /// 圓形直徑 /// </summary> public static int d = r * 2; /// <summary> /// 計算圓形與矩形交接三角形邊 /// </summary> public static int a = (int)(r * Math.Sin(Math.PI * (50 / 180f))); public static int b = (int)(r * Math.Cos(Math.PI * (50 / 180f))); public static int c = r - a; /// <summary> /// 滑塊邊框 /// </summary> public static int blod = 2; /// <summary> /// 水印 /// </summary> public static string watermarkText = "SC.NET"; /// <summary> /// 是否顯示水印 /// </summary> public static bool showWatermark = true; } }
ImgFormat.cs
using System; using System.Collections.Generic; using System.Drawing.Imaging; namespace SliderCaptcha.NET { public class ImgFormat { private static Dictionary<string, string> Formats = new Dictionary<string, string>() { {"b96b3caa-0728-11d3-9d7b-0000f81ef32e","MemoryBmp"}, {"b96b3cab-0728-11d3-9d7b-0000f81ef32e","Bmp"}, {"b96b3cac-0728-11d3-9d7b-0000f81ef32e","Emf"}, {"b96b3cad-0728-11d3-9d7b-0000f81ef32e","Wmf"}, {"b96b3cae-0728-11d3-9d7b-0000f81ef32e","Jpeg"}, {"b96b3caf-0728-11d3-9d7b-0000f81ef32e","Png"}, {"b96b3cb0-0728-11d3-9d7b-0000f81ef32e","Gif"}, {"b96b3cb1-0728-11d3-9d7b-0000f81ef32e","Tiff"}, {"b96b3cb2-0728-11d3-9d7b-0000f81ef32e","Exif"}, {"b96b3cb5-0728-11d3-9d7b-0000f81ef32e","Icon"} }; public static ImageFormat FormatFromGuid(ImageFormat format) { return FormatFromGuid(format.Guid); } public static ImageFormat FormatFromGuid(Guid guid) { return FormatFromGuid(guid.ToString()); } public static ImageFormat FormatFromGuid(string guid) { if (Formats.ContainsKey(guid)) { string name = Formats[guid]; ImageFormat format = null; switch (name) { case "MemoryBmp": format = ImageFormat.MemoryBmp; break; case "Bmp": format = ImageFormat.Bmp; break; case "Emf": format = ImageFormat.Emf; break; case "Wmf": format = ImageFormat.Wmf; break; case "Gif": format = ImageFormat.Gif; break; case "Jpeg": format = ImageFormat.Jpeg; break; case "Png": format = ImageFormat.Png; break; case "Tiff": format = ImageFormat.Tiff; break; case "Exif": format = ImageFormat.Exif; break; case "Icon": format = ImageFormat.Icon; break; } return format; } else { return null; } } public static string NameFromGuid(ImageFormat format) { return NameFromGuid(format.Guid); } public static string NameFromGuid(Guid guid) { return NameFromGuid(guid.ToString()); } public static string NameFromGuid(string guid) { if (Formats.ContainsKey(guid)) { return Formats[guid]; } else { return string.Empty; } } } }
使用：
這里用的是asp.net mvc 的框架，用的是api介面，前后端分離供前端使用，具體使用根據個人需求，可以是介面呼叫亦可以是專案呼叫，
呼聲如果很高的話，考慮出一個winfrom版本的滑動驗證碼~（滑稽）
[HttpGet] public IHttpActionResult GetCaptcha() { Captcha64Model model = Captcha.GenerateBase64(); CacheHelper.Cache.SetCache("sliderX", model.X); Hashtable ht = new Hashtable(); ht.Add("background", model.Background); ht.Add("slider", model.Slide); ht.Add("sliderXXXXX", model.X); return Json(ht); } /// <summary> /// 檢查驗證 /// </summary> /// <param name="x"></param> /// <returns></returns> [HttpPost] public IHttpActionResult CheckCaptcha([FromBody] int x = 0) { Hashtable hs = new Hashtable(); string Mess = ""; int Code = 0; var session = CacheHelper.Cache.GetCache("sliderX"); if (session == null) { Mess = "請重繪驗證碼"; Code = 500; goto block; } string sliderXStr = session?.ToString();// as string int sliderX = Convert.ToInt32(sliderXStr); int difX = sliderX - x; if (difX >= 0 - Config.blod && difX <= Config.blod) { Mess = "success"; Code = 0; } else { session = null; Mess = "錯誤"; Code = 500; } block: hs.Add("Mess", Mess); hs.Add("Code", Code); return Json(hs); }
前端代碼：
<!DOCTYPE HTML PUBLIC "-//W3C//DTD HTML 4.0 Transitional//EN"> <html> <head> <title>Splide Captcha</title> <style> * { -webkit-user-select: none; -moz-user-select: none; -ms-user-select: none; user-select: none; } .sc-captcha { width: 300px; margin: 100px auto; } .sc_net_panel { padding: 10px; } .sc_net_panel > div { position: relative; } .bg_slider { position: absolute; left: 0; top: 0; } .bg_refresh { position: absolute; right: 5px; top: 5px; background: #808080; color: #fff; border-radius: 3px; width: 16px; line-height: 16px; text-align: center; cursor: pointer; } .sc_net_slider_icon { position: absolute; left: 0; top: 0; height: 37px; text-align: center; border-radius: 5px; border: #808080 1px solid; width: 37px; line-height: 37px; cursor: pointer; } .sc_net_slider_icon:hover { color: #fff; background: #1991fa; } .sc_net_slider_text { position: absolute; left: 0; top: 0; text-align: center; width: 280px; color: #45494c; border: #808080 1px solid; border-radius: 5px; line-height: 35px; height: 37px; cursor: default; } .sc_net_slider_area { position: absolute; left: 0; top: 0; height: 37px; } </style> <script src=https://www.cnblogs.com/BFMC/p/"E:\porject\碚煜Api\ByzkApi\Scripts\jquery-3.4.1.js"></script> <script src=https://www.cnblogs.com/BFMC/p/"E:\porject\碚煜Api\ByzkApi\Scripts\jquery-3.4.1.min.js"></script> </head> <body> <div> <div class="sc-captcha"> <div class="sc_net_panel"> <div class="sc_net_bg"> <div class="sc_net_bgimg"> </div> <div class="bg_refresh" onclick="loadCaptcha()" title="重繪">?</div> </div> </div> <div class="sc_net_panel"> <div class="sc_net_slider"> <div class="sc_net_slider_text">向右拖動滑塊填充拼圖</div> <div class="sc_net_slider_area"></div> <div class="sc_net_slider_icon">?</div> </div> </div> </div> </div> </body> <script> loadCaptcha(); function loadCaptcha() { $.ajax({ url: "http://192.168.1.216:5500/api/TestApi/GetCaptcha", type: "Get", dataType: "JSON", success: function (json) { var bg = createCanvas(280, 155); bg.className = 'bg_img'; bg_slider = createCanvas(62, 155); bg_slider.className = 'bg_slider'; CanvasSetImage(bg, json.background); CanvasSetImage(bg_slider, json.slider); var doc = document.getElementsByClassName("sc_net_bgimg")[0]; doc.innerHTML = ""; doc.appendChild(bg); doc.appendChild(bg_slider); console.log(json.modelX); } }) } function createCanvas(width, height) { var canvas = document.createElement('canvas'); canvas.width = width; canvas.height = height; return canvas; }; function CanvasSetImage(_canvas, base64) { //獲取2d畫布物件 var ctx = _canvas.getContext("2d"); //創建圖片標簽 var _img = document.createElement("img"); //設定圖片地址 _img.src =https://www.cnblogs.com/BFMC/p/ base64; //ctx.fillRect(0, 0, _canvas.clientWidth, _canvas.clientHeight); //ctx.fillStyle = 'rgba(255, 255, 255, 0)'; _img.onload = function () { ctx.drawImage(_img, 0, 0); } /* ctx.drawImage(_img, 10, 10);*/ } function getByClassName0(className) { return document.getElementsByClassName(className)[0]; }; var slider = getByClassName0("sc_net_slider_icon"); var text = getByClassName0("sc_net_slider_text"); var area = getByClassName0("sc_net_slider_area"); var bg_slider; slider.addEventListener('mousedown', handleDragStart); slider.addEventListener('touchstart', handleDragStart); document.addEventListener('mousemove', handleDragMove); document.addEventListener('touchmove', handleDragMove); document.addEventListener('mouseup', handleDragEnd); document.addEventListener('touchend', handleDragEnd); document.addEventListener('mousedown', function () { return false; }); document.addEventListener('touchstart', function () { return false; }); var originX, originY, trail = [], isMouseDown = false; var isOk = false; function handleDragStart(e) { console.log("handleDragStart"); if (isOk) return; originX = e.clientX || e.touches[0].clientX; originY = e.clientY || e.touches[0].clientY; isMouseDown = true; }; function handleDragMove(e) { if (!isMouseDown) return false; var eventX = e.clientX || e.touches[0].clientX; var eventY = e.clientY || e.touches[0].clientY; var moveX = eventX - originX; var moveY = eventY - originY; if (moveX >= 0 && moveX <= 243) { slider.style.left = moveX + "px"; bg_slider.style.left = moveX / 243 * 218 + "px"; } }; function handleDragEnd(e) { if (!isMouseDown) return false isMouseDown = false var eventX = e.clientX || e.changedTouches[0].clientX if (eventX == originX) return false //獲取前端的x坐標； var a = $(".bg_slider"); var localX = a[0].offsetLeft; $.ajax({ url: "http://192.168.1.216:5500/api/TestApi/CheckCaptcha?x=" + localX, type: "Post", dataType: "JSON", success: function (res) { alert(res.Mess); } }) }; </script> </html>
結語：
到這里基本上就已經完成了，以上前端地址更換成自己的介面即可，正常業務 驗證碼是很頻發的一個操作并且是多用戶，所以快取存盤的時候也需要注意一下，最后有問題的話，可以評論區溝通，感謝觀看！（這次很用心在寫，能否上個推薦~）
