ClassRoom

ClassRoom是一個練手demo，目的是為了能熟悉掌握Orleans的基本知識和使用方法，我會盡量在這個專案中加入更多的知識點，一邊學一邊練避免我看完檔案就忘掉

創建專案

依舊是四個專案起步

專案名稱	專案型別	專案說明
IGrains	.net Core 3.1 類別庫	Grain介面庫
Grains	.net Core 3.1 類別庫	實作Grain的類別庫
Silo_ConsoleApp	.net Core 3.1 控制臺	Silo服務
Client_ConsoleApp	.net Core 3.1 控制臺	客戶端程式

參考類別庫

IGrains：
Microsoft.Orleans.Core.Abstractions（3.0.2）
Microsoft.Orleans.CodeGenerator.MSBuild（3.0.2）

Grains：
Microsoft.Orleans.Core.Abstractions（3.0.2）
Microsoft.Orleans.CodeGenerator.MSBuild（3.0.2）

Silo_ConsoleApp：
Microsoft.Orleans.Server（3.0.2）

Client_ConsoleApp：
Microsoft.Orleans.Client（3.0.2）

IGrains 定義

using System.Threading.Tasks;

namespace IGrains
{
    /// <summary>
    /// 學生
    /// </summary>
    public interface IStudent : Orleans.IGrainWithIntegerKey
    {
        /// <summary>
        /// 打招呼
        /// </summary>
        /// <returns></returns>
        Task<string> SayHello();
    }
}

注意Orleans.IGrainWithIntegerKey，這個決定了Grain的key的型別，是long還是string，或者Guid.

再加個控制臺日志幫助類

using System;

namespace IGrains
{
    /// <summary>
    /// 控制臺幫助類
    /// </summary>
    public static class ConsoleHelper
    {

        static void WriteColorLine(string str, ConsoleColor color)
        {
            ConsoleColor currentForeColor = Console.ForegroundColor;
            Console.ForegroundColor = color;
            Console.WriteLine(str);
            Console.ForegroundColor = currentForeColor;
        }

        /// <summary>
        /// 列印錯誤資訊
        /// </summary>
        /// <param name="str">待列印的字串</param>
        /// <param name="color">想要列印的顏色</param>
        public static void WriteErrorLine(this string str, ConsoleColor color = ConsoleColor.Red)
        {
            WriteColorLine(str, color);
        }

        /// <summary>
        /// 列印警告資訊
        /// </summary>
        /// <param name="str">待列印的字串</param>
        /// <param name="color">想要列印的顏色</param>
        public static void WriteWarningLine(this string str, ConsoleColor color = ConsoleColor.Yellow)
        {
            WriteColorLine(str, color);
        }
        /// <summary>
        /// 列印正常資訊
        /// </summary>
        /// <param name="str">待列印的字串</param>
        /// <param name="color">想要列印的顏色</param>
        public static void WriteInfoLine(this string str, ConsoleColor color = ConsoleColor.White)
        {
            WriteColorLine(str, color);
        }
        /// <summary>
        /// 列印成功的資訊
        /// </summary>
        /// <param name="str">待列印的字串</param>
        /// <param name="color">想要列印的顏色</param>
        public static void WriteSuccessLine(this string str, ConsoleColor color = ConsoleColor.Green)
        {
            WriteColorLine(str, color);
        }
    }
}

Grains 定義

using IGrains;
using System;
using System.Threading.Tasks;

namespace Grains
{
    /// <summary>
    /// 學生
    /// </summary>
    public class Student : Orleans.Grain, IStudent
    {
        /// <summary>
        /// 打招呼
        /// </summary>
        /// <returns></returns>
        public Task<string> SayHello()
        {
            var id = this.GrainReference.GrainIdentity.PrimaryKeyLong;//當前Grain的key
            Console.WriteLine($"\n {id}收到SayHello訊息 \n");
            return Task.FromResult($"\n 大家好，我是{id} \n");
        }
    }
}

這里我使用了GrainReference.GrainIdentity.PrimaryKeyLong，這個值就是當前Grain的idkey值，有了它Grain才能知道自己是誰. =_=!

Silo_ConsoleApp

using Grains;
using Orleans;
using Orleans.Configuration;
using Orleans.Hosting;
using System;
using System.Net;
using System.Threading.Tasks;

namespace Silo_ConsoleApp
{
    class Program
    {
        static async Task Main(string[] args)
        {
            Console.WriteLine("開始啟動Silo!");
            try
            {
                var host = await StartSilo();
                Console.WriteLine("Silo啟動完成");
                Console.WriteLine("\n\n 按回車鍵停止 \n\n");
                Console.ReadLine();
                await host.StopAsync();//停止當前Silo
                return;
            }
            catch (Exception ex)
            {
                Console.WriteLine(ex);
                return;
            }
        }

        /// <summary>
        /// 啟動本地配置
        /// </summary>
        /// <returns></returns>
        private static async Task<ISiloHost> StartSilo()
        {
            var host = new SiloHostBuilder()
                 .UseLocalhostClustering()                     //配置Silo只使用開發集群，并監聽本地主機，
                 .Configure<ClusterOptions>(options =>
                 {
                     options.ClusterId = "dev";
                     options.ServiceId = "MyHost";             //獲取或設定此服務的唯一識別符號，該識別符號應在部署和重新部署后仍然有效
                 })
                 .Configure<EndpointOptions>(options => options.AdvertisedIPAddress = IPAddress.Loopback)//配置Silo的埠
                 .ConfigureApplicationParts(parts => parts.AddApplicationPart(typeof(Student).Assembly).WithReferences())
                 .Build();
            await host.StartAsync();//啟動當前Silo.
            return host;
        }
    }
}

先用本地開發配置

Client_ConsoleApp

using IGrains;
using Orleans;
using Orleans.Configuration;
using System;
using System.Threading.Tasks;

namespace Client_ConsoleApp
{
    class Program
    {
        static async Task Main(string[] args)
        {
            Console.WriteLine("開始啟動Silo!");
            try
            {
                using (var client = await ConnectClient())
                {
                    Console.WriteLine("客戶端已成功連接到Silo Host  \n");
                    await DoClientWork(client);
                }
            }
            catch (Exception ex)
            {
                Console.WriteLine(ex);
            }
            Console.WriteLine("\n\n 按任意鍵退出 \n\n");
            Console.ReadKey();
            return;
        }

        private static async Task DoClientWork(IClusterClient client)
        {
            //從客戶端呼叫Grain的示例
            var student = client.GetGrain<IStudent>(321);
            var response = await student.SayHello();
            Console.WriteLine("\n\n{0}\n\n", response);
        }

        /// <summary>
        /// 使用本地配置連接服務
        /// </summary>
        /// <returns></returns>
        private static async Task<IClusterClient> ConnectClient()
        {
            IClusterClient client;
            client = new ClientBuilder()
                .UseLocalhostClustering()           //配置客戶端以連接到本地主機上的筒倉，
                .Configure<ClusterOptions>(options =>
                {
                    options.ClusterId = "dev";
                    options.ServiceId = "MyHost";
                })
                .Build();
            await client.Connect();
            return client;
        }
    }
}

同樣適用本地配置
