網路攝像頭cv2.VideoCapture的延遲更低

我正在使用網路攝像頭構建一個應用程式來控制視頻游戲（有點像 kinect）。它使用網路攝像頭 (cv2.VideoCapture(0))、AI 姿勢估計 (

我們使用哪些導致延遲的步驟？

暫時原諒我們累積每個特定延遲相關成本的原始草圖：

   CAM \____/                                     python code GIL-awaiting ~ 100 [ms] chopping
        |::|                                      python code calling a cv2.<function>()
        |::|   __________________________________________-----!!!!!!!-----------
        |::|    ^     2x                                 NNNNN!!!!!!!MOVES DATA!
        |::|    | per-call                               NNNNN!!!!!!!    1.THERE
        |::|    |     COST                               NNNNN!!!!!!!    2.BACK
        |::|    |           TTTT-openCV::MAT into python numpy.array
        |::|    |          ////       forMAT TRANSFORMER TRANSFORMATIONS
        USBx    |         ////                           TRANSFORMATIONS
        |::|    |        ////                            TRANSFORMATIONS
        |::|    |       ////                             TRANSFORMATIONS
        |::|    |      ////                              TRANSFORMATIONS
        |::|    |     ////                               TRANSFORMATIONS
    H/W oooo   _v____TTTT in-RAM openCV::MAT storage     TRANSFORMATIONS
       /    \        oooo ------ openCV::MAT object-mapper
       \    /        xxxx
 O/S--- °°°°         xxxx
 driver """" _____   xxxx
         \\\\    ^   xxxx ...... openCV {signed|unsigned}-{size}-{N-channels}
 _________\\\\___|___     __________________________________________
 openCV I/O      ^   PPPP                                 PROCESSING
            as F |   ....                                 PROCESSING
               A |   ...                                  PROCESSING
               S |   ..                                   PROCESSING
               T |   .                                    PROCESSING
            as   |   PPPP                                 PROCESSING
      possible___v___PPPP _____ openCV::MAT NATIVE-object PROCESSING

我們/我們可以_{（在這里）}對抗什么延遲？

硬體延遲可能會有所幫助，但更改已購買的硬體可能會變得昂貴

已經優化了延遲的工具箱的軟體延遲是可能的，但越來越難

設計效率低下是最后也是最常見的地方，延遲可能會被削減

開放式簡歷？
這里沒什么可做的。問題在于 OpenCV-Python 系結細節：

_{... So when you call a function, say res = equalizeHist(img1,img2) in Python, you pass two numpy arrays and you expect another numpy array as the output. So these numpy arrays are converted to cv::Mat and then calls the equalizeHist() function in C . Final result, res will be converted back into a Numpy array. So in short, almost all operations are done in C which gives us almost same speed as that of C .}

This works fine "outside" a control-loop, not in our case, where both of the two transport-costs, transformation-costs and any of new or interim-data storage RAM-allocation-costs result in worsening our control-loop TAT.

So avoid any and all calls of OpenCV-native functions from Python-(behind the bindings' latency extra-miles)-side, no matter how tempting or sweet these may look on the first sight.

HUNDREDS-of-[ms] are a rather bitter cost of ignoring this advice.

Python ?
Yes, Python. Using Python interpreter introduces both latency per se, plus adds problems with concurrency-avoided processing, no matter how many cores does our hardware operate on ( while recent Py3 tries a lot to lower these costs under the interpreter-level software).

We can test & squeeze max out of the (still unavoidable, in 2022) GIL-lock interleaving - check the sys.getswitchinterval() and test increasing this amount for having less interleaved python-side processing ( tweaking is dependent on other your python-application ambitions ( GUI, distributed-computing tasks, python network-I/O workloads, python-HW-I/O-s, if applicable, etc )

RAM-memory-I/O costs ?
Our next major enemy. Using a least-sufficient-enough image-DATA-format, that MediaPipe can work with is the way forward in this segment.

Avoidable losses
All other (our) sins belong to this segment. Avoid any image-DATA-format transformations ( see above, cost may easily grow into HUNDREDS THOUSANDS of [us] just for converting an already acquired-&-formatted-&-stored numpy.array into just another colourmap)

MediaPipe
lists enumerated formats it can work with:

 // ImageFormat

  SRGB: sRGB, interleaved:   one byte for R,
                        then one byte for G,
                        then one byte for B for each pixel.

  SRGBA: sRGBA, interleaved: one byte for R,
                             one byte for G,
                             one byte for B,
                             one byte for alpha or unused.

  SBGRA: sBGRA, interleaved: one byte for B,
                             one byte for G,
                             one byte for R,
                             one byte for alpha or unused.

  GRAY8:        Grayscale,   one byte per pixel.

  GRAY16:       Grayscale,   one uint16 per pixel.

  SRGB48:  sRGB,interleaved, each component is a uint16.

  SRGBA64: sRGBA,interleaved,each component is a uint16.

  VEC32F1:                   One float per pixel.

  VEC32F2:                   Two floats per pixel.

So, choose the MVF -- the minimum viable format -- for gesture-recognition to work and downscale the amount of pixels as possible ( 400x600-GRAY8 would be my hot candidate )

預配置（不遺漏cv.CAP_PROP_FOURCC 細節）本機端OpenCV::VideoCapture處理，僅將這個 MVF 以 RAW 格式簡單存盤在 Acquisition-&-Pre-processing 鏈的本機端，這樣就沒有其他帖子了-進行格式化。

如果確實被迫接觸 python 端numpy.array物件，則更喜歡使用矢量化和跨步技巧驅動的操作而不是.view()-s 或.data-buffers，以避免任何不必要的附加延遲成本增加 control-loop TAT。

選項？

• 通過精確配置本機端 OpenCV 處理以匹配所需的 MediaPipe 資料格式，消除任何 python 端呼叫（因為這些呼叫會花費您 --2 倍的資料 I/O 成本 轉換成本）

• 最小化，最好避免任何阻塞，如果控制回路仍然過于偏斜，請嘗試使用 分布式處理將原始資料移動到 localhost 或 sub-ms LAN 域中的其他行程（不一定是 Python 解釋器）（此處提供更多提示）

• 嘗試適應熱資料 RAM 占用空間以匹配您的 CPU-Cache Hierarchy 快取行的大小和關聯性詳細資訊（請參閱此）
