文章目錄
- 布局
- MainActivity類
- 自定義Fragment類
- 效果
- 完整代碼下載地址
布局
my_fragment.xml
<RelativeLayout xmlns:android="http://schemas.android.com/apk/res/android"
xmlns:tools="http://schemas.android.com/tools"
android:layout_width="match_parent"
android:layout_height="match_parent"
tools:context=".MainActivity">
<RelativeLayout
android:id="@+id/ly_top_bar"
android:layout_width="match_parent"
android:layout_height="48dp"
>
<TextView
android:id="@+id/topBar"
android:layout_width="match_parent"
android:layout_height="match_parent"
android:layout_centerInParent="true"
android:gravity="center"
android:textSize="18sp"
android:textColor="#000"
android:text="資訊"/>
<View
android:layout_width="match_parent"
android:layout_height="2px"
android:background="#C0C0C0"
android:layout_alignParentBottom="true"/>
</RelativeLayout>
<LinearLayout
android:id="@+id/ly_tab_bar"
android:layout_width="match_parent"
android:layout_height="56dp"
android:layout_alignParentBottom="true"
android:background="#C0C0C0"
android:orientation="horizontal">
<TextView
android:id="@+id/txt_channel"
android:layout_width="0dp"
android:layout_height="match_parent"
android:layout_weight="1"
android:background="#FFF"
android:drawablePadding="3dp"
android:drawableTop="@drawable/tab_menu_channel"
android:gravity="center"
android:padding="5dp"
android:text="提醒"
android:textColor="@drawable/tab_menu_text"
android:textSize="16sp" />
<TextView
android:id="@+id/txt_message"
android:layout_width="0dp"
android:layout_height="match_parent"
android:layout_weight="1"
android:background="#FFF"
android:drawablePadding="3dp"
android:drawableTop="@drawable/tab_menu_message"
android:gravity="center"
android:padding="5dp"
android:text="訊息"
android:textColor="@drawable/tab_menu_text"
android:textSize="16sp" />
<TextView
android:id="@+id/txt_better"
android:layout_width="0dp"
android:layout_height="match_parent"
android:layout_weight="1"
android:background="#FFF"
android:drawablePadding="3dp"
android:drawableTop="@drawable/tab_menu_better"
android:gravity="center"
android:padding="5dp"
android:text="我的"
android:textColor="@drawable/tab_menu_text"
android:textSize="16sp" />
<TextView
android:id="@+id/txt_setting"
android:layout_width="0dp"
android:layout_height="match_parent"
android:layout_weight="1"
android:background="#FFF"
android:drawablePadding="3dp"
android:drawableTop="@drawable/tab_menu_setting"
android:gravity="center"
android:padding="5dp"
android:text="設定"
android:textColor="@drawable/tab_menu_text"
android:textSize="16sp"/>
</LinearLayout>
<View
android:id="@+id/div_tab_bar"
android:layout_width="match_parent"
android:layout_height="2px"
android:background="#FFF"
android:layout_above="@id/ly_tab_bar"/>
<FrameLayout
android:background="#D3D3D3"
android:layout_width="match_parent"
android:layout_height="match_parent"
android:layout_below="@id/ly_top_bar"
android:layout_above="@id/div_tab_bar"
android:id="@+id/ly_content">
</FrameLayout>
</RelativeLayout>
fg_content.xml
<?xml version="1.0" encoding="utf-8"?>
<LinearLayout xmlns:android="http://schemas.android.com/apk/res/android"
android:orientation="vertical"
android:layout_width="match_parent"
android:layout_height="match_parent"
android:background="#D3D3D3">
<TextView
android:id="@+id/txt_content"
android:layout_width="match_parent"
android:layout_height="match_parent"
android:gravity="center"
android:textColor="#000"
android:textSize="20sp"/>
</LinearLayout>
MainActivity類
package com.demo;
import android.content.Intent;
import android.os.Build;
import android.support.annotation.NonNull;
import android.support.annotation.RequiresApi;
import android.support.v4.app.FragmentManager;
import android.support.v4.app.FragmentTransaction;
import android.support.v4.view.ViewPager;
import android.support.v4.widget.DrawerLayout;
import android.support.v7.app.AppCompatActivity;
import android.os.Bundle;
import android.util.DisplayMetrics;
import android.util.Log;
import android.view.*;
import android.widget.*;
import java.util.ArrayList;
public class MainActivity extends AppCompatActivity implements View.OnClickListener{
private ViewPager pager1;
private ArrayList<View> list;
private MyPagerAdapter myPagerAdapter;
private ImageView img_cursor;
private TextView tv_one;
private TextView tv_two;
private TextView tv_three;
private int offSet = 0; //移動條圖片的偏移量
private int currIndex = 0; //當前頁
private int imageWidth = 0; //移動條圖片的寬度
private int one = 0; //移動潭訓動一頁的距離
private int two = 0; //移動潭訓動兩頁的距離
private DrawerLayout drawerLayout;
private TextView ll_content;
private LinearLayout id_ll_left;
Button button;
private TextView txt_topbar;
private TextView txt_channel;
private TextView txt_message;
private TextView txt_better;
private TextView txt_setting;
private FrameLayout ly_content;
//Fragment Object
private MyFragment fg1,fg2,fg3,fg4;
private FragmentManager fManager;
@RequiresApi(api = Build.VERSION_CODES.JELLY_BEAN)
@Override
protected void onCreate(Bundle savedInstanceState) {
super.onCreate(savedInstanceState);
setContentView(R.layout.my_fragment);
// init();
bindViews();
//getFragmentManager();不推薦使用
fManager = getSupportFragmentManager();
//模擬點擊
txt_channel.performClick();
button = findViewById(R.id.button);
Intent intent =new Intent(MainActivity.this,SecondActivity.class);
startActivityForResult(intent,1);
}
private void bindViews() {
txt_topbar = findViewById(R.id.topBar);
txt_channel = findViewById(R.id.txt_channel);
txt_message =findViewById(R.id.txt_message);
txt_better = findViewById(R.id.txt_better);
txt_setting = findViewById(R.id.txt_setting);
ly_content = findViewById(R.id.ly_content);
txt_channel.setOnClickListener(this);
txt_message.setOnClickListener(this);
txt_better.setOnClickListener(this);
txt_setting.setOnClickListener(this);
}
//設定文本的選中狀態
private void setSelected(){
txt_channel.setSelected(false);
txt_better.setSelected(false);
txt_message.setSelected(false);
txt_setting.setSelected(false);
}
//隱藏所有Fragment
private void hideAllFragment(FragmentTransaction transaction){
if(fg1!=null) transaction.hide(fg1);
if(fg2!=null) transaction.hide(fg2);
if(fg3!=null) transaction.hide(fg3);
if(fg4!=null) transaction.hide(fg4);
}
@Override
public void onPageScrolled(int i, float v, int i1) {
}
@Override
public void onPageSelected(int i) {
}
@Override
public void onPageScrollStateChanged(int i) {
}
@Override
public void onClick(View view) {
FragmentTransaction fragmentTransaction = fManager.beginTransaction();
hideAllFragment(fragmentTransaction);
switch (view.getId()){
case R.id.txt_channel:
setSelected();
txt_channel.setSelected(true);
if(fg1==null){
fg1 = new MyFragment("first Fragment");
fragmentTransaction.add(R.id.ly_content,fg1);
}
else{
fragmentTransaction.show(fg1);
}
break;
case R.id.txt_message:
setSelected();
txt_message.setSelected(true);
if(fg2==null){
fg2 = new MyFragment("second Fragment");
fragmentTransaction.add(R.id.ly_content,fg2);
}
else{
fragmentTransaction.show(fg2);
}
break;
case R.id.txt_better:
setSelected();
txt_better.setSelected(true);
if(fg3==null){
fg3 = new MyFragment("third Fragment");
fragmentTransaction.add(R.id.ly_content,fg3);
}
else{
fragmentTransaction.show(fg3);
}
break;
case R.id.txt_setting:
setSelected();
txt_setting.setSelected(true);
if(fg4==null){
fg4 = new MyFragment("forth Fragment");
fragmentTransaction.add(R.id.ly_content,fg4);
}
else{
fragmentTransaction.show(fg4);
}
break;
}
fragmentTransaction.commit();
}
}
自定義Fragment類
package com.demo;
import android.annotation.SuppressLint;
import android.content.Context;
import android.os.Bundle;
import android.support.annotation.NonNull;
import android.support.annotation.Nullable;
import android.support.v4.app.Fragment;
import android.view.LayoutInflater;
import android.view.View;
import android.view.ViewGroup;
import android.widget.TextView;
@SuppressLint("ValidFragment")
public class MyFragment extends Fragment {
private String content;
public MyFragment(String content) {
this.content = content;
}
@Nullable
@Override
public View onCreateView(@NonNull LayoutInflater inflater, @Nullable ViewGroup container, @Nullable Bundle savedInstanceState) {
View view = inflater.inflate(R.layout.fg_content,null);
TextView textView = (TextView) view.findViewById(R.id.txt_content);
textView.setText(content);
return view;
}
}
效果
完整代碼下載地址
