第十一屆藍橋杯單片機組省賽（第二場）原始碼

這個原始碼是本人在省賽當天復盤時寫的，并有幸獲得了江蘇省一等獎，不過代碼比較簡單，適合新人作為參考，如果有不足的地方，希望各位在評論區戳我，一起改正，一起學習！

#include<stc15f2k60s2.h>
#include<onewire.h>
#include<iic.h>
#define uchar unsigned char
#define uint unsigned int

void Delay(uint t);
void InitSystem();
void SelectHC573(uchar n);
void DisplaySMG(uchar pos, uchar value);
void SMG_off();
void Display_C();
void Display_P();
void Select_Display();
void Read_Temp();
void PCF8591_DAC(uchar dat);
void KeyScan();
void Setting();

sbit S7 = P3^0;         //定義S7
sbit S6 = P3^1;         //定義S6
sbit S5 = P3^2;         //定義S5
sbit S4 = P3^3;         //定義S4

uint Temp = 0x0000;              //當前溫度值
uchar Range[2] = {20,30};       //溫度上下限
uchar Oldrange[2] = {0,0};     //保存歷史設定引數
uchar code SMG_Duamma[10] = {0xc0,0xf9,0xa4,0xb0,0x99,0x92,0x82,0xf8,0x80,0x90};
bit Stat_C = 0;                  //界面切換標志位
bit Stat_P = 0;                  //引數切換標志位


void main()
{
	InitSystem();
	while(1)
	{
		Read_Temp();
		Select_Display();
		KeyScan();
		Setting();
	}
}

//****簡單的延時函式****//
void Delay(uint t)
{
	while(t--);
}

//****系統初始化函式****//
void InitSystem()
{
	SelectHC573(4);
	P0 = 0xff;               //關閉所有LED
	SelectHC573(5);
	P0 = 0x00;               //關閉蜂鳴器和繼電器
}

//****HC573選通函式****//
void SelectHC573(uchar n)
{
	switch(n)
	{
		case 4:
			P2 = (P2 & 0X1F) | 0X80;
		break;
		case 5:
			P2 = (P2 & 0X1F) | 0XA0;
		break;
		case 6:
			P2 = (P2 & 0X1F) | 0XC0;
		break;
		case 7:
			P2 = (P2 & 0X1F) | 0XE0;
		break;
	}
}

//****數碼管顯示模塊****//
void DisplaySMG(uchar pos, uchar value)       //點亮單個數碼管
{
	SelectHC573(7);
	P0 = 0x00;                 //消隱
	SelectHC573(6);
	P0 = 0x01 << pos;
	SelectHC573(7);
	P0 = value;
}

void SMG_off()                //關閉所有數碼管
{
	SelectHC573(6);
	P0 = 0xff;
	SelectHC573(7);
	P0 = 0xff;
}

void Display_C()             //資料顯示界面
{
	DisplaySMG(0, 0xc6);
	Delay(200);

	DisplaySMG(6, SMG_Duamma[Temp / 10]);
	Delay(200);
	DisplaySMG(7, SMG_Duamma[Temp % 10]);
	Delay(200);

	SMG_off();
}

void Display_P()             //引數顯示界面
{
	DisplaySMG(0, 0x8c);
	Delay(200);

	DisplaySMG(3, SMG_Duamma[Range[1] / 10]);
	Delay(200);
	DisplaySMG(4, SMG_Duamma[Range[1] % 10]);
	Delay(200);

	DisplaySMG(6, SMG_Duamma[Range[0] / 10]);
	Delay(200);
	DisplaySMG(7, SMG_Duamma[Range[0] % 10]);
	Delay(200);

	SMG_off();
}

void Select_Display()
{
	if(Stat_C == 0)
		Display_C();
	else if(Stat_C == 1)
		Display_P();
}

//****溫度采集模塊****//
void Read_Temp()
{
	uchar LSB,MSB;

	init_ds18b20();
	Write_DS18B20(0xcc);
	Write_DS18B20(0x44);

	Delay(1000);

	init_ds18b20();
	Write_DS18B20(0xcc);
	Write_DS18B20(0xbe);

	LSB = Read_DS18B20();
	MSB = Read_DS18B20();
	init_ds18b20();

	Temp = (MSB << 8) | LSB;
	Temp >>= 4;
}

//****DAC模擬電壓輸出模塊****//
void PCF8591_DAC(uchar dat)
{
	IIC_Start();
	IIC_SendByte(0x90);
	IIC_WaitAck();
	IIC_SendByte(0x40);
	IIC_WaitAck();
	IIC_SendByte(dat);
	IIC_WaitAck();
	IIC_Stop();
}

//****按鍵模塊****//
void KeyScan()
{
	if(S4 == 0)
	{
		Delay(500);
		if(S4 == 0)
		{
			if(Stat_C == 0)
			{
				Oldrange[0] = Range[0];
				Oldrange[1] = Range[1];
				Stat_P = 0;
			}
			else
			{
				if(Range[0] > Range[1])
				{
					Range[0] = Oldrange[0];
					Range[1] = Oldrange[1];
				}
			}
			Stat_C = ~Stat_C;
			while(S4 == 0);
		}
	}

	if(S5 == 0)
	{
		Delay(500);
		if(S5 == 0)
		{
			Stat_P = ~Stat_P;
		}
		while(S5 == 0);
	}

	if(S6 == 0)
	{
		Delay(500);
		if(S6 == 0)
		{
			if(Stat_C == 1)
			{
				if(Range[Stat_P] < 99)
					Range[Stat_P]++;
			}
		}
		while(S6 == 0);
	}

	if(S7 == 0)
	{
		Delay(500);
		if(S7 == 0)
		{
			if(Stat_C == 1)
			{
				if(Range[Stat_P] > 0)
					Range[Stat_P]--;
			}
		}
		while(S7 == 0);
	}
}

//****輸出功能和指示燈模塊****//
void Setting()
{
	if(Temp > Range[1])
	{
		PCF8591_DAC(204);                //輸出電壓4.0V
		SelectHC573(4);
		P0 = (P0 & 0xf8) | 0x06;         //點亮L1
	}

	else if(Temp >= Range[0])
	{
		PCF8591_DAC(153);                //輸出電壓3.0V
		SelectHC573(4);
		P0 = (P0 & 0xf8) | 0x05;         //點亮L2
	}

	else
	{
		PCF8591_DAC(102);                //輸出電壓2.0V
		SelectHC573(4);
		P0 = (P0 & 0xf8) | 0x03;         //點亮L3
	}

	if(Range[0] > Range[1])
	{
		SelectHC573(4);
		P0 &= 0xf7;                      //點亮L4
	}
	else
	{
		SelectHC573(4);
		P0 |= 0x08;                      //熄滅L4
	}
}
