部署

服務器	角色
192.168.91.135	master
192.168.91.136	backup
192.168.91.166	VIP

一、Nginx 部署

分別在 master、backup 部署 Nginx，請參照 Nginx 部署

二、Keepalived 部署

分別在 master、backup 部署 Nginx，請參照 Keepalived 部署

三、配置

3.1 master

1 . 配置 keepalived.conf

vrrp_script：指定檢查nginx作業狀態腳本（根據nginx狀態判斷是否故障轉移）
virtual_ipaddress：虛擬IP（VIP）

cat > /etc/keepalived/keepalived.conf << EOF
global_defs {
   notification_email {
     acassen@firewall.loc
     failover@firewall.loc
     sysadmin@firewall.loc
   }
   notification_email_from Alexandre.Cassen@firewall.loc
   smtp_server 127.0.0.1
   smtp_connect_timeout 30
   router_id NGINX_MASTER
}

vrrp_script check_nginx {
    script "/etc/keepalived/check_nginx.sh"
}

vrrp_instance VI_1 {
    state MASTER
    interface ens33  # 修改為實際網卡名
    virtual_router_id 51 # VRRP 路由 ID實體，每個實體是唯一的
    priority 100    # 優先級，備服務器設定 90
    advert_int 1    # 指定VRRP 心跳包通告間隔時間，默認1秒
    authentication {
        auth_type PASS
        auth_pass 1111
    }
    # 虛擬IP
    virtual_ipaddress {
        192.168.91.166/24
    }
    track_script {
        check_nginx
    }
}
EOF

2 . 配置檢測 nginx 腳本，提供給 keepalived

cat > /etc/keepalived/check_nginx.sh  << "EOF"
#!/bin/bash
count=$(ss -antp |grep 6443 |egrep -cv "grep|$$")

if [ "$count" -eq 0 ];then
    exit 1
else
    exit 0
fi
EOF
chmod +x /etc/keepalived/check_nginx.sh

注：keepalived根據腳本回傳狀態碼（0為作業正常，非0不正常）判斷是否故障轉移，

3 . 重啟 keepalived

systemctl restart keepalived

3.2 Backup

1 . 配置 keepalived.conf

cat > /etc/keepalived/keepalived.conf << EOF
global_defs {
   notification_email {
     acassen@firewall.loc
     failover@firewall.loc
     sysadmin@firewall.loc
   }
   notification_email_from Alexandre.Cassen@firewall.loc
   smtp_server 127.0.0.1
   smtp_connect_timeout 30
   router_id NGINX_BACKUP
}

vrrp_script check_nginx {
    script "/etc/keepalived/check_nginx.sh"
}

vrrp_instance VI_1 {
    state BACKUP
    interface ens33
    virtual_router_id 51 # VRRP 路由 ID實體，每個實體是唯一的
    priority 90
    advert_int 1
    authentication {
        auth_type PASS
        auth_pass 1111
    }
    virtual_ipaddress {
        192.168.91.166/24
    }
    track_script {
        check_nginx
    }
}
EOF

2 . 配置檢測 nginx 腳本，提供給 keepalived

cat > /etc/keepalived/check_nginx.sh  << "EOF"
#!/bin/bash
count=$(ss -antp |grep 6443 |egrep -cv "grep|$$")

if [ "$count" -eq 0 ];then
    exit 1
else
    exit 0
fi
EOF
chmod +x /etc/keepalived/check_nginx.sh
