前言
暑假的時候想自己做一個圖傳APP，也就是把攝像頭拍攝到的影像顯示在手機上，查閱資料發現APICloud挺好用的，所以就研究了半個月自制了一個簡易APP，廢話不多說，上原始碼鏈接：
APICloud+jetson nano+websocket +OpenCV圖傳APP.rar
需要的朋友可以下載，
一、APICloud是什么？
APICloud是一個高性能多端開發技術快速開發企業級應用程式的低代碼開發平臺
一套代碼同時生成Android、iOS、小程式、Web等多端應用，非常實用，
官網下載鏈接：APICloud Studio3下載
二、設計步驟
APP設計
設計好的頁面可以在右側實時預覽，這一點我覺得很不錯，
main.html
<!DOCTYPE html>
<html>
<head>
<meta charset="utf-8">
<meta name="viewport" content="maximum-scale=1.0,minimum-scale=1.0,user-scalable=0,width=device-width,initial-scale=1.0"/>
<title>title</title>
<link rel="stylesheet" type="text/css" href="../css/api.css"/>
<style>
header{
position: absolute;
top: 0;
left: 0;
width: 100%;
height: 80px;
background-color: rgba(132, 134, 252, 0.867);
}
header .left{
position: absolute;
bottom: 0;
left: 0;
width: 60px;
height: 42px;
}
header .left .logo{
position:absolute;
bottom: 0;
left: 0;
width: 60px;
height: 42px;
background-image: url(../image/robot.png);
background-size: 40px*33px;
background-position: center center;
background-repeat: no-repeat;
}
header .left .logo_txt{
position:absolute;
width: 80px;
height: 42px;
padding-left: 60px;
line-height: 45px;
font-size: 20px;
}
header .center{
position:absolute;
width: 100%;
height: 30px;
background-color: #000;
}
framers {
position:absolute;
top: 80px;
left: 0;
width: 100%;
bottom: 0;
background-color: #fff;
text-align: center;
}
framers .Bluetooth_control{
position:absolute;
left: 20px;
top: 20px;
background-color: #66cbff;
padding-left: 120px;
line-height: 45px;
padding-right: 120px;
font-size: 20px;
color: #fff;
}
framers .Wifi_control{
position:absolute;
left: 20px;
top: 85px;
background-color: #66cbff;
padding-left: 125px;
line-height: 45px;
padding-right: 120px;
font-size: 20px;
color: #fff;
}
framers .user_html{
height: 20px;
font-size: 20px;
color: #000;
line-height: 600px;
text-align: center;
}
framers .user_html_1{
height: 20px;
font-size: 20px;
color: #000;
text-align: center;
line-height: 700px;
}
framers .user_txt{
height: 20px;
font-size: 20px;
color: #000;
text-align: center;
line-height: 800px;
}
framers .user_txt_1{
height: 20px;
font-size: 20px;
color: #000;
text-align: center;
line-height: 900px;
}
</style>
</head>
<body>
<header>
<div class="left">
<div class="logo"></div>
<div class="logo_txt">AlphaBot</div>
</div>
<div class="center"></div>
</header>
<framers>
<div class="Bluetooth_control" onclick="Bluetooth_control();">藍牙控制</div>
<div class="Wifi_control" onclick="Wifi_control();">Wifi控制</div>
<div class="user_html"><u>QQ:3075221401</u></div>
<div class="user_html_1"><u>CSDN@靜·無羨</u></div>
<div class="user_txt"><u>AJJFirstAPP</u></div>
<div class="user_txt_1"><s></u>我的APP很大你要忍一下</s></div>
</framers>
<button type="submit" id="btn_submit"> submit </button>
</body>
<script type="text/javascript" src="../script/api.js"></script>
<script type="text/javascript">
apiready = function(){
api.setScreenOrientation({
orientation:'auto_portrait'
});
api.toast({
msg:'請先配置網路連接！'
})
};
function Bluetooth_control(){
api.openWin({
name: 'Bluetooth_control',
url: 'Bluetooth_control.html',
})
};
function Wifi_control(){
api.openWin({
name: 'Wifi_control',
url: 'Wifi_Control.html',
})
};
</script>
</html>
Wifi_Control.html
<!DOCTYPE html>
<html>
<head>
<meta charset="utf-8">
<meta name="viewport" content="maximum-scale=1.0,minimum-scale=1.0,user-scalable=0,width=device-width,initial-scale=1.0"/>
<title>title</title>
<link rel="stylesheet" type="text/css" href="../css/api.css"/>
<style>
header{
position: absolute;
top: 0;
left: 0;
width: 100%;
height: 80px;
background-color: rgba(132, 134, 252, 0.867);
}
header .left{
position: absolute;
bottom: 0;
left: 0;
width: 60px;
height: 42px;
}
header .left .logo{
position:absolute;
bottom: 0;
left: 0;
width: 60px;
height: 42px;
background-image: url(../image/robot.png);
background-size: 40px*33px;
background-position: center center;
background-repeat: no-repeat;
}
header .left .logo_txt{
position:absolute;
width: 80px;
height: 42px;
padding-left: 60px;
line-height: 45px;
font-size: 20px;
}
header .center{
position:absolute;
width: 100%;
height: 30px;
background-color: #000;
}
framers {
position:absolute;
top: 80px;
left: 0;
width: 100%;
bottom: 0;
background-color: #fff;
}
framers .IP_adrress{
position: absolute;
left: 20px;
line-height: 45px;
font-size: 14px;
color: #000;
}
framers .control_port{
position: absolute;
left: 20px;
line-height: 205px;
font-size: 14px;
color: #000;
}
framers .connection{
position:absolute;
left: 20px;
right: 20px;
top: 200px;
background-color: #66cbff;
padding-left: auto;
line-height: 45px;
padding-right: auto;
font-size: 20px;
text-align: center;
color: #fff;
}
framers .user_html{
height: 20px;
font-size: 20px;
color: #000;
line-height: 600px;
text-align: center;
}
framers .user_html_1{
height: 20px;
font-size: 20px;
color: #000;
text-align: center;
line-height: 700px;
}
framers .user_txt{
height: 20px;
font-size: 20px;
color: #000;
text-align: center;
line-height: 800px;
}
framers .user_txt_1{
height: 20px;
font-size: 20px;
color: #000;
text-align: center;
line-height: 900px;
}
</style>
</head>
<body>
<header>
<div class="left">
<div class="logo"></div>
<div class="logo_txt">AlphaBot</div>
</div>
<div class="center"></div>
</header>
<style type="text/css">
framers .IP_adrress input{
position: absolute;
left: 0px;
top: 40px;
font-size: 14px;
width: 300px;
height: 30px;
}
framers .control_port input{
position: absolute;
left: 0px;
top: 120px;
font-size: 14px;
width: 300px;
height: 30px;
}
</style>
<framers>
<div class="IP_adrress" >IP 地址: <input id="IP" type =“text” value="192.168.0.102" maxlength="13"></div>
<div class="control_port">控制埠: <input id="port" type =“text” value="8080" maxlength="4"></div>
<div class="connection" onclick="Connection(host_value,port_value);">連接</div>
<div class="user_html"><u>QQ:3075221401</u></div>
<div class="user_html_1"><u>CSDN@靜·無羨</u></div>
<div class="user_txt"><u>AJJFirstAPP</u></div>
<div class="user_txt_1"><s></u>我的APP很大你要忍一下</s></div>
</framers>
</body>
<script type="text/javascript" src="../script/api.js" src="../html/Car_Control.html"></script>
<script type="text/javascript">
apiready = function(){
api.setScreenOrientation({
orientation:'portrait_up'
});
api.require('socketManager');
};
var host_value=document.getElementById("IP").value;
var port_value=document.getElementById("port").value;
function Connection(host,port)
{
ws = new WebSocket("ws://"+host+":"+port);
ws.onopen = function (msg) {
console.log('webSocket opened');
Send('ok');
api.setGlobalData({key: 'host',value: host});
api.setGlobalData({key: 'port',value: port});
ws.close();
api.openWin({name: 'Car_Control',url: 'Car_Control.html'})
};
ws.onerror = function (error) {
console.log('error :' + error.name + error.number);
api.toast({msg:'連接錯誤！'})
};
ws.onclose = function () {
console.log('webSocket closed');
api.toast({msg:'連接關閉！'})
};
// ws.onmessage = function (event) {
// let data = JSON.parse(event.data);
// if (data.command == "getplans") {f
// var planData = data.data;//回傳的資料
// console.log(planData);
// } else if (data.command == "getscenes") {
// // 其他命令
// }
// }
}
function Send(content){
ws.send(content);
}
// window.onunload = function(){
// ws.close();
// };
</script>
</html>
Car_Control.html
<!DOCTYPE html>
<html>
<head>
<meta charset="utf-8">
<meta name="viewport" content="maximum-scale=1.0,minimum-scale=1.0,user-scalable=0,width=device-width,initial-scale=1.0"/>
<title>title</title>
<link rel="stylesheet" type="text/css" href="../css/api.css"/>
<style>
header{
position: absolute;
top: 0;
left: 0;
width: 100%;
height: 30px;
background-color: #000;
}
header .car_state{
line-height: 120px;
font-size: 20px;
text-align:center;
color: #66cbff;
}
body {
/* transform: rotate(90deg);
height: 100vw;
width: 100vh;
transform-origin: 0% 100%;
top: -100vw; */
background-color: #fff;
}
lefter{
position: absolute;
top: 0;
left: 0;
width: 30px;
height: 100%;
transform: rotateZ(90);
background-color: #000;
}
control{
position: absolute;
top: 30px;
left: 30px;
bottom: 0px;
width: 345px;
}
control .Forward{
position: absolute;
top: 80px;
left: 120px;
width: 70px;
height: 70px;
background-image: url(../image/106.png);
}
control .Backward{
position: absolute;
top: 220px;
left: 120px;
width: 70px;
height: 70px;
background-image: url(../image/109.png);
}
control .TurnLeft{
position: absolute;
top: 150px;
left: 30px;
width: 70px;
height: 70px;
background-image: url(../image/102.png);
}
control .TurnRight{
position: absolute;
top: 150px;
left: 210px;
width: 70px;
height: 70px;
background-image: url(../image/105.png);
}
control .Up{
position: absolute;
top: 80px;
left: 560px;
width: 70px;
height: 70px;
background-image: url(../image/106.png);
}
control .Down{
position: absolute;
top: 220px;
left: 560px;
width: 70px;
height: 70px;
background-image: url(../image/109.png);
}
control .Left{
position: absolute;
top: 150px;
left: 470px;
width: 70px;
height: 70px;
background-image: url(../image/102.png);
}
control .Right{
position: absolute;
top: 150px;
left: 650px;
width: 70px;
height: 70px;
background-image: url(../image/105.png);
}
</style>
</head>
<body>
<header>
<div class="car_state"id="direction">Stop</div>
<div class="center"></div>
</header>
<lefter></lefter>
<control>
<div class="Forward" id="F"></div>
<div class="Backward" id="B"></div>
<div class="TurnLeft" id="TL"></div>
<div class="TurnRight"id="TR"></div>
<div class="Up" id="U"></div>
<div class="Down" id="D"></div>
<div class="Left" id="L"></div>
<div class="Right"id="R"></div>
<img id="resImg" src="" width="640" height="480"/> <!--圖片展示-->
<iframe id="inner1" src="../html/Wifi_Control.html"></iframe>
</control>
</body>
<script type="text/javascript" src="../script/api.js" src="../html/Wifi_Control.html" ></script>
<script type="text/javascript">
apiready = function(){
api.setScreenOrientation({
orientation:'landscape_left'
});
api.toast({
msg:'連接成功！'
})
api.addEventListener({
name:'keyback'
}, function(ret,err){
api.setScreenOrientation({
orientation:'portrait_up'
});
api.closeWin();
});
host = api.getGlobalData({key: 'host'});
port = api.getGlobalData({key: 'port'});
Connection(host,port);
};
var Img = document.getElementById('resImg');
function Connection(host,port)
{
ws = new WebSocket("ws://"+host+":"+port);
ws.onopen = function (msg) {
console.log('webSocket opened');
Send('ok');
};
ws.onerror = function (error) {
console.log('error :' + error.name + error.number);
api.toast({msg:'連接錯誤！'})
};
ws.onclose = function () {
console.log('webSocket closed');
api.toast({msg:'連接關閉！'})
};
ws.onmessage = function (event) {
Img.src=event.data;
}
}
function Send(content){
ws.send(content);
}
var F = document.getElementById('F');
F.addEventListener("touchstart",function()
{
F.style.backgroundImage='url(../image/107.png)';
Send('Forward');
})
F.addEventListener("touchend",function()
{
F.style.backgroundImage='url(../image/106.png)';
Send('Stop');
}
)
var B = document.getElementById('B');
B.addEventListener("touchstart",function()
{
B.style.backgroundImage='url(../image/108.png)';
Send('Backward');
})
B.addEventListener("touchend",function()
{
B.style.backgroundImage='url(../image/109.png)';
Send('Stop');
}
)
var TL = document.getElementById('TL');
TL.addEventListener("touchstart",function()
{
TL.style.backgroundImage='url(../image/103.png)';
Send('TurnLeft');
})
TL.addEventListener("touchend",function()
{
TL.style.backgroundImage='url(../image/102.png)';
Send('Stop');
}
)
var TR = document.getElementById('TR');
TR.addEventListener("touchstart",function()
{
TR.style.backgroundImage='url(../image/104.png)';
Send('TurnRight');
})
TR.addEventListener("touchend",function()
{
TR.style.backgroundImage='url(../image/105.png)';
Send('Stop');
}
)
var U = document.getElementById('U');
U.addEventListener("touchstart",function()
{
U.style.backgroundImage='url(../image/107.png)';
Send('Up');
})
U.addEventListener("touchend",function()
{
U.style.backgroundImage='url(../image/106.png)';
Send('Stop');
}
)
var D = document.getElementById('D');
D.addEventListener("touchstart",function()
{
D.style.backgroundImage='url(../image/108.png)';
Send('Down');
})
D.addEventListener("touchend",function()
{
D.style.backgroundImage='url(../image/109.png)';
Send('Stop');
}
)
var L = document.getElementById('L');
L.addEventListener("touchstart",function()
{
L.style.backgroundImage='url(../image/103.png)';
Send('Left');
})
L.addEventListener("touchend",function()
{
L.style.backgroundImage='url(../image/102.png)';
Send('Stop');
}
)
var R = document.getElementById('R');
R.addEventListener("touchstart",function()
{
R.style.backgroundImage='url(../image/104.png)';
Send('Right');
})
R.addEventListener("touchend",function()
{
R.style.backgroundImage='url(../image/105.png)';
Send('Stop');
}
)
</script>
</html>
jetson nano Python代碼設計
image_socket.py
#! /usr/bin/env python3
# -*- coding: utf-8 -*-
from websocket_server import WebsocketServer
import threading
import cv2
import base64
import time
import subprocess
time.sleep(5)
cmd = "hostname -I | cut -d\' \' -f1"
host = subprocess.check_output(cmd,shell = True )
print(host)
# Called for every client connecting (after handshake)
def new_client(client, server):
print("got connection from ",client['address'] )
# 發送給所有的連接
server.send_message_to_all("Hey all, a new client has joined us")
# Called for every client disconnecting
def client_left(client, server):
print("Client disconnected!" )
# Called when a client sends a message
def message_received(client, server, message):
if len(message) > 200:
message = message[:200]+'..'
print("Client(%d) said: %s" % (client['id'], message))
# 發送給所有的連接
#server.send_message_to_all(message)
def vedio_thread2(n):
cap = cv2.VideoCapture(0)
width = 640
height = 480
cap.set(cv2.CAP_PROP_FRAME_WIDTH, width)
cap.set(cv2.CAP_PROP_FRAME_HEIGHT, height)
while(True):
ret, img_bgr = cap.read()
if img_bgr is None:
print('lose image_value')
else:
frame = cv2.flip(img_bgr, 1)
image = cv2.imencode('.jpg', frame)[1]
base64_data = base64.b64encode(image)
s = base64_data.decode()
#cv2.imshow("video", frame)
cv2.waitKey(50)
time.sleep(0.05)
def vedio_thread1(n):
print('send')
while True:
if len(server.clients)>0:
image = cv2.imencode('.jpg', frame)[1]
base64_data = base64.b64encode(image)
s = base64_data.decode()
time.sleep(0.05)
def from_camera():
thread1 = threading.Thread(target=vedio_thread1, args=(1,))
thread1.setDaemon(True)
thread1.start()
thread2 = threading.Thread(target=vedio_thread2, args=(1,))
thread2.setDaemon(True)
thread2.start()
print('start')
print('server is running....')
# Server Port
port=8080
# 創建Websocket Server
server = WebsocketServer(port,host)
from_camera()
# 有設備連接上了
server.set_fn_new_client(new_client)
# 斷開連接
server.set_fn_client_left(client_left)
# 接收到資訊
server.set_fn_message_received(message_received)
# 開始監聽
server.run_forever()
運行代碼
運行APICloud APP代碼
手機下載好AppLoader，官方下載鏈接：AppLoader，通過資料線連接上電腦并開啟除錯模式，右擊專案點擊USB同步
專案編譯完成后會顯示可連接設備：
點擊選擇手機設備，手機就會自動打開AppLoader進入APP界面：
確保nano和手機連接同一個網路，在nano上運行image_socket.py：
由圖可以看出nano的IP地址為192.168.0.102，代碼中埠設定為8080
APP點擊WIFI控制，輸入IP地址和埠后點擊連接，就可以在手機APP上看到nano攝像頭采集的影像了，
總結
雖然花了半個月時間才搞定，但是這次也是學習到了不少東西，嘿嘿，源代碼已經上傳到CSDN了，有錢的捧個錢場哈，當然想白嫖的同學可以在評論區留下郵箱，我有空就會發，
轉載請註明出處，本文鏈接：https://www.uj5u.com/qita/323266.html
標籤：其他
下一篇：OpenCV 矩陣的掩膜操作
