一文讀懂clickhouse集群監控

常言道，兵馬未至，糧草先行，在clickhouse上生產環境之前，我們就得制定好相關的監控方案，包括metric采集、報警策略、圖形化報表，有了全面有效的監控，我們就仿佛擁有了千里眼順風耳，對于線上任何風吹草動都能及時感知，在必要的情況下提前介入以避免線上故障，

業界常用的監控方案一般是基于prometheus + grafana生態，本文將介紹由clickhouse-exporter(node-exporter) + prometheus + grafana組成的監控方案，

以上為監控方案示意圖

• clickhouse-server中有4個系統表會記錄行程內部的指標，分別是system.metrics，system.asynchronous_metrics, system.events，system.parts
• clickhuse-exporter是一個用于采集clickhouse指標的開源組件(https://github.com/ClickHouse/clickhouse_exporter)，它會定時查詢clickhouse-server中的系統表，轉化成監控指標，并通過HTTP介面暴露給prometheus.
• node-exporter是一個用于采集硬體和作業系統相關指標的開源組件(https://github.com/prometheus/node_exporter)，
• prometheus定時抓取clickhouse-exporter暴露的指標，并判斷報警條件是否被觸發，是則推送到alert manager
• DBA可通過grafana看板實時查看當前clickhouse集群的運行狀態
• DBA可通過alertmanager設定報警通知方式，如郵件、企業微信、電話等，

1 部署與配置

1.1 clickhouse-server

我們生產環境版本為20.3.8，按照官方檔案部署即可，

1.2 clickhouse-exporter

clickhouse-exporter一般與clickhouse-server同機部署，

首先下載最新代碼并編譯(需預先安裝Go)

git clone https://github.com/ClickHouse/clickhouse_exporter
cd clickhouse_exporter
go mod init
go mod vendor
go build
ls ./clickhouse_exporter

然后啟動

export CLICKHOUSE_USER="user"
export CLICKHOUSE_PASSWORD="password"
nohup ./-scrape_uri=http://localhost:port/ >nohup.log 2>&1 &

最后檢查指標是否被正常采集：

> curl localhost:9116/metrics | head
# TYPE clickhouse_arena_alloc_bytes_total counter
clickhouse_arena_alloc_bytes_total 9.799096840192e+12
# HELP clickhouse_arena_alloc_chunks_total Number of ArenaAllocChunks total processed
# TYPE clickhouse_arena_alloc_chunks_total counter
clickhouse_arena_alloc_chunks_total 2.29782524e+08
# HELP clickhouse_background_move_pool_task Number of BackgroundMovePoolTask currently processed
# TYPE clickhouse_background_move_pool_task gauge
clickhouse_background_move_pool_task 0
# HELP clickhouse_background_pool_task Number of BackgroundPoolTask currently processed

1.3 node-exporter

node-exporter需與clickhouse-server同機部署

首先下載最新代碼并編譯

git clone https://github.com/prometheus/node_exporter
make build
ls ./node_exporter

然后啟動

nohup ./node_exporter > nohup.log 2>&1 &

最后檢查指標是否被正常采集

> curl localhost:9100/metrics
# HELP go_gc_duration_seconds A summary of the GC invocation durations.
# TYPE go_gc_duration_seconds summary
go_gc_duration_seconds{quantile="0"} 6.3563e-05
go_gc_duration_seconds{quantile="0.25"} 7.4746e-05
go_gc_duration_seconds{quantile="0.5"} 9.0556e-05
go_gc_duration_seconds{quantile="0.75"} 0.000110677
go_gc_duration_seconds{quantile="1"} 0.004362325
go_gc_duration_seconds_sum 28.451282046
go_gc_duration_seconds_count 223479
...

1.4 prometheus

修改prometheus組態檔，添加alertmanager地址、clickhouse-exporter地址

prometheus.yml示例如下：

global:
  scrape_interval:     15s # Set the scrape interval to every 15 seconds. Default is every 1 minute.
  evaluation_interval: 15s # Evaluate rules every 15 seconds. The default is every 1 minute.

# Alertmanager configuration
alerting:
  alertmanagers:
  - static_configs:
    - targets:
      - alertmanager:9093

# Load rules once and periodically evaluate them according to the global 'evaluation_interval'.
rule_files:
  - ./rules/*.rules

# A scrape configuration containing exactly one endpoint to scrape:
# Here it's Prometheus itself.
scrape_configs:
  # The job name is added as a label `job=<job_name>` to any timeseries scraped from this config.
  - job_name: 'clickhouse'

    # metrics_path defaults to '/metrics'
    # scheme defaults to 'http'.
    static_configs:
    - targets: ['clickhouseexporter1:9116', 'clickhouseexporter2:9116', ...]

*.rules示例如下：

groups:
 - name: qps_too_high
   rules:
   - alert: clickhouse qps超出閾值
     expr: rate(clickhouse_query_total[1m]) > 100
     for: 2m
     labels:
      job: clickhouse-server
      severity: critical
      alertname: clickhouse qps超出閾值
     annotations:
      summary: "clickhouse qps超出閾值"
      description: "clickhouse qps超過閾值(100), qps: {{ $value }}"

啟動promethus

nohup ./prometheus --config.file=/path/to/config --storage.tsdb.path=/path/to/storage --web.external-url=prometheus --web.enable-admin-api --web.enable-lifecycle --log.level=warn >nohup.log 2>&1 &

瀏覽器輸入http://prometheus_ip:9090檢查prometheus狀態

1.5 alert manager

首先修改組態檔

組態檔示例如下：

route:
  receiver: 'default'
  group_by: ['service','project']

receivers:
- name: "電話"
  webhook_configs:
  - url: <url>

- name: "企業微信"
  webhook_configs:
  - url: <url>

- name: "郵箱"
  webhook_configs:
  - url: <url>

然后啟動

nohup ./alertmanager --config.file=/path/to/config --log.level=warn >nohup.log 2>&1 &

1.6 grafana

關于clickhouse的dashboard模板已經有很多，在這里推薦：https://grafana.com/grafana/dashboards/882 將它匯入到新建的grafana dashboard之后，即可得到漂亮的clickhouse集群看板(可能需要微調)，

另外建議安裝clickhouse datasource插件，有了這個插件便能在grafana中配置clickhouse資料源，并通過Clickhouse SQL配置圖表，詳細檔案見：https://grafana.com/grafana/plugins/vertamedia-clickhouse-datasource

2 重要指標和監控

我們可以看到，不管是node-exporter還是clickhouse-exporter，它們的指標種類很多，大概有幾百個，我們的策略是抓大放小，對于重要的指標才設定報警策略并創建看板，

下面列舉一些個人覺得比較重要的指標

2.1 系統指標

系統指標由node-exporter采集

2.2 clickhouse指標

2.3 其他常用SQL

在clickhouse中，所有被執行的Query都會記錄到system.query_log表中，因此我們可通過該表監控集群的查詢情況，以下列舉幾種用于監控的常用SQL，為了更方便的查看，可添加到grafana看板中，

最近查詢

SELECT
    event_time,
    user,
    query_id AS query,
    read_rows,
    read_bytes,
    result_rows,
    result_bytes,
    memory_usage,
    exception
FROM clusterAllReplicas('cluster_name', system, query_log)
WHERE (event_date = today()) AND (event_time >= (now() - 60)) AND (is_initial_query = 1) AND (query NOT LIKE 'INSERT INTO%')
ORDER BY event_time DESC
LIMIT 100

慢查詢

SELECT
    event_time,
    user,
    query_id AS query,
    read_rows,
    read_bytes,
    result_rows,
    result_bytes,
    memory_usage,
    exception
FROM clusterAllReplicas('cluster_name', system, query_log)
WHERE (event_date = yesterday()) AND query_duration_ms > 30000 AND (is_initial_query = 1) AND (query NOT LIKE 'INSERT INTO%')
ORDER BY query_duration_ms desc
LIMIT 100

Top10大表

SELECT
    database,
    table,
    sum(bytes_on_disk) AS bytes_on_disk
FROM clusterAllReplicas('cluster_name', system, parts)
WHERE active AND (database != 'system')
GROUP BY
    database,
    table
ORDER BY bytes_on_disk DESC
LIMIT 10

Top10查詢用戶

SELECT
    user,
    count(1) AS query_times,
    sum(read_bytes) AS query_bytes,
    sum(read_rows) AS query_rows
FROM clusterAllReplicas('cluster_name', system, query_log)
WHERE (event_date = yesterday()) AND (is_initial_query = 1) AND (query NOT LIKE 'INSERT INTO%')
GROUP BY user
ORDER BY query_times DESC
LIMIT 10
