關于ELK是什么、做什么用，我們不在此討論，本文重點在如何實作快速方便地安裝logstash和filebeat組件，特別是在近千臺DB Server的環境下（為了安全保守，公司DB Server 目前尚未部署saltstack一類的管控軟體），在盡可能標準化的條件下，希望可以實作一鍵化安裝，下面是我們功能實作的一些嘗試，我們把手動一步步操作打包提煉到一個sh檔案中，安裝部署時只要執行sh檔案即可，部署安裝logstash和filebeat組件由原來的10分鐘縮減到目前的1分鐘左右，并且減少了因手動部署帶來的誤操作，
1.logstash和filebeat安裝包所在指定路徑下
logstash的安裝包logstash-7.6.0.zip所在路徑
/data/logstash/logstash-7.6.0.zip
filebeat的安裝包filebeat-7.4.2-linux-x86_64.tar.gz所在路徑
2.上傳經過標準化的程式組態檔
上傳程式的組態檔filebeat.service、filebeat.yml、logstash.conf、startup.options到指定位置，這些檔案是格式化后的，不是解壓的默認檔案，目的是方便替換安裝，
如何想直接使用disposelogcollectot.sh檔案，上傳的路徑一定要是/tmp/
3.撰寫一鍵安裝的可執行檔案disposelogcollectot.sh
#!/bin/bash # The version is defined V.001 # Version ModifyTime ModifyBy Desc # Ver001 2018-03-25 Carson.Xu Create the Scripts File # Desc: This file is used to despose filebeat \ logstash in order to collect slow log and error log from mysqld. #### step 1 判斷 需要上傳的檔案是否已上傳 cd /tmp/ if [ -f "filebeat.service" -a -f "filebeat.yml" -a -f "logstash.conf" -a -f "startup.options" ] then echo 'step 1 安裝程序需要的檔案已到位,上傳檔案項檢查通過....' else echo "step 1 安裝程序中需要的filebeat.service、 filebeat.yml、 logstash.conf、 startup.options，沒有到位，不能繼續安裝，安裝行程退出!!!" exit fi #### step 2 解壓指定檔案 cd /data/logstash/ unzip logstash-7.6.0.zip echo 'step 2 解壓logstash項作業完成....' sleep 3 #### step 3 洗掉解壓后的指定檔案 cd logstash-7.6.0/config/ rm -rf startup.options echo 'step 3 洗掉解壓后的指定檔案startup.options作業完成....' sleep 3 #### step 4 轉移上傳的檔案 mv /tmp/logstash.conf /tmp/startup.options -t /data/logstash/logstash-7.6.0/config/ echo 'step 4 轉移檔案logstash.conf的作業完成....' sleep 2 #### step 5 修改log上傳的ES 索引[必做 建議用業務名稱替換，例如qq/weixin/rewu] read -p "請輸入業務名稱:" product echo -e "\n" echo "用戶名為:$product" sed -i "s/qqweixinface/$product/" /data/logstash/logstash-7.6.0/config/logstash.conf echo 'step 5 洗掉解壓后的指定檔案startup.options作業完成....' sleep 2 ##### step 6 安裝logstash 服務 /data/logstash/logstash-7.6.0/bin/system-install echo 'step 6 安裝logstash 服務作業完成....' sleep 3 ##### step 7 解壓縮filebeat檔案 cd /data/filebeat/ tar -zxvf filebeat-7.4.2-linux-x86_64.tar.gz echo 'step 7 解壓縮filebeat檔案作業完成....' sleep 3 #### step 8 轉移上傳的filebeat.yml，允許覆寫掉生成默認組態檔 rm -rf /data/filebeat/filebeat-7.4.2-linux-x86_64/filebeat.yml mv /tmp/filebeat.yml /data/filebeat/filebeat-7.4.2-linux-x86_64/ echo 'step 8 轉移上傳的filebeat.yml，允許覆寫掉生成默認組態檔作業完成....' sleep 2 #### step 9 權限調整 cd /data/filebeat/filebeat-7.4.2-linux-x86_64 chown -R root:root filebeat.yml chmod 600 filebeat.yml echo 'step 9 調整filebeat檔案權限的作業完成....' sleep 2 ##### step 10 獲取 Server IP ip=$(ip a|awk -F "inet|/" '/inet.*brd/ {print $2}'|head -n 1) serverid=$(echo $ip) #去除左右空格 echo $serverid echo 'step 10 獲取Server IP的作業完成....' echo '獲取Server IP的為：' $serverid sleep 1 ###### step 11 調整host配置[必做 IP替換] sed -i "s/119.119.119.119/$serverid/" /data/filebeat/filebeat-7.4.2-linux-x86_64/filebeat.yml echo 'step 11 替換組態檔中的Server IP作業完成....' sleep 1 ###### step 12 轉移服務檔案 mv /tmp/filebeat.service /etc/systemd/system/ echo 'step 12 將filebeat服務的檔案移動到指定位置的作業完成....' sleep 1 ###### step 13 服務設定及啟動 systemctl enable logstash.service systemctl enable filebeat.service echo 'step 13 將服務設定為自啟動的作業完成....' systemctl start logstash.service sleep 20 systemctl start filebeat.service sleep 10 ##### step 14 檢查服務是否已正常啟動 logstashservice_check_result=`systemctl status logstash.service | grep "active (running)"| wc -l` if [ "$logstashservice_check_result" == "1" ] then echo 'step 14 檢查logstash.service已啟動....' else echo "step 14 檢查logstash.service未正常啟動....，安裝行程退出!!!" exit fi sleep 3 filebeatservice_check_result=`systemctl status filebeat.service | grep "active (running)"| wc -l` if [ "$filebeatservice_check_result" == "1" ] then echo 'step 14 檢查filebeat.service已啟動....' else echo "step 14 檢查filebeat.service未正常啟動....，安裝行程退出!!!" exit fi ###### step 15 安裝程序結束 echo 'step 15 安裝程序結束'
4.執行
chmod 755 disposelogcollectot.sh
sh -x disposelogcollectot.sh
5.附錄
在附錄這一部分，介紹剛剛上傳的檔案--filebeat.service、filebeat.yml、logstash.conf、startup.options
5.1 檔案startup.options
這一個檔案主要描述了logstash程式的啟動配置
################################################################################ # These settings are ONLY used by $LS_HOME/bin/system-install to create a custom # startup script for Logstash and is not used by Logstash itself. It should # automagically use the init system (systemd, upstart, sysv, etc.) that your # Linux distribution uses. # # After changing anything here, you need to re-run $LS_HOME/bin/system-install # as root to push the changes to the init script. ################################################################################ # Override Java location #JAVACMD=/usr/bin/java # Set a home directory LS_HOME=/data/logstash/logstash-7.6.0 # logstash settings directory, the path which contains logstash.yml LS_SETTINGS_DIR=/data/logstash/logstash-7.6.0/config # Arguments to pass to logstash LS_OPTS="--path.settings ${LS_SETTINGS_DIR} -f /data/logstash/logstash-7.6.0/config/logstash.conf" # Arguments to pass to java LS_JAVA_OPTS="" # pidfiles aren't used the same way for upstart and systemd; this is for sysv users. LS_PIDFILE=/var/run/logstash.pid # user and group id to be invoked as LS_USER=root LS_GROUP=root # Enable GC logging by uncommenting the appropriate lines in the GC logging # section in jvm.options LS_GC_LOG_FILE=/var/log/logstash/gc.log # Open file limit LS_OPEN_FILES=16384 # Nice level LS_NICE=19 # Change these to have the init script named and described differently # This is useful when running multiple instances of Logstash on the same # physical box or vm SERVICE_NAME="logstash" SERVICE_DESCRIPTION="logstash" # If you need to run a command or script before launching Logstash, put it # between the lines beginning with `read` and `EOM`, and uncomment those lines. ### ## read -r -d '' PRESTART << EOM ## EOM
5.2 附件logstash.conf
這個檔案主要說明的是格式化讀取的資料 以及 如何保存到elasticsearch中
# Sample Logstash configuration for creating a simple # Beats -> Logstash -> Elasticsearch pipeline. input { beats { port => 5044 } } filter { if [fields][log_type] == "mysql-slow" { grok { match => ["message", "(?m)^#\s+Time:\s+%{TIMESTAMP_ISO8601}\s*#\s+User@Host:\s+(?<user>.*)\[%{USERNAME:user}?\]\s*@\s*%{IPORHOST:client}?\s*\[%{IPORHOST:client}?\]\s+Id:\s+%{BASE10NUM}\s*#\s+Query_time:\s+%{BASE10NUM:query_time}\s+Lock_time:\s+%{BASE10NUM:lock_time}\s+Rows_sent:\s+%{BASE10NUM:rows_sent}\s+Rows_examined:\s+%{BASE10NUM:rows_examined}\s*(use\s+%{DATA:database};\s*)?SET\s+timestamp=%{BASE10NUM:timestamp};\s*%{GREEDYDATA:sql_stmt}$"] keep_empty_captures => true } date { match => ["timestamp", "UNIX"] remove_field => ["timestamp"] } mutate { convert => { "query_time" => "float" "lock_time" => "float" "rows_sent" => "integer" "rows_examined" => "integer" } remove_field => ["@version", "beat", "host", "input", "log", "offset", "prospector", "source", "tags"] } } if [fields][log_type] == "mysql-error" { grok { match => ["message", "(?m)^%{TIMESTAMP_ISO8601:timestamp} %{BASE10NUM} \[%{WORD:error_level}\] %{GREEDYDATA:error_msg}$"] } date { match=> ["timestamp", "ISO8601"] remove_field => ["timestamp"] } mutate { remove_field => ["@version", "beat", "host", "input", "log", "offset", "prospector", "source", "tags"] } } } output { elasticsearch { hosts => ["http://110.110.110.110:10192"] #index => "%{[@metadata][beat]}-%{[@metadata][version]}-%{+YYYY.MM.dd}" index => "%{[fields][log_type]}-qqweixinface-%{+YYYY.MM.dd}" user => "qquid_es" password => "xiang_ni_123+yidiandian" } }
5.3 附件filebeat.yml
這個檔案主要說明了filebeat讀取什么log,已經對讀取的資料如何處理
###################### Filebeat Configuration Example ######################### # This file is an example configuration file highlighting only the most common # options. The filebeat.reference.yml file from the same directory contains all the # supported options with more comments. You can use it as a reference. # # You can find the full configuration reference here: # https://www.elastic.co/guide/en/beats/filebeat/index.html # For more available modules and options, please see the filebeat.reference.yml sample # configuration file. #=========================== Filebeat inputs ============================= filebeat.inputs: # Each - is an input. Most options can be set at the input level, so # you can use different inputs for various configurations. # Below are the input specific configurations. - type: log # Change to true to enable this input configuration. #enabled: false # Paths that should be crawled and fetched. Glob based paths. #paths: #- /var/log/*.log #- c:\programdata\elasticsearch\logs\* paths: - /data/mysql/data/slow.log fields: log_type: mysql-slow db_host: 119.119.119.119 db_port: 3306 multiline.pattern: "^# Time:" multiline.negate: true multiline.match: after - type: log paths: - /data/mysql/data/error.log fields: log_type: mysql-error db_host: 119.119.119.119 db_port: 3306 multiline.pattern: ^20\d{2}-\d{2}-\d{2}T multiline.negate: true multiline.match: after # Exclude lines. A list of regular expressions to match. It drops the lines that are # matching any regular expression from the list. #exclude_lines: ['^DBG'] # Include lines. A list of regular expressions to match. It exports the lines that are # matching any regular expression from the list. #include_lines: ['^ERR', '^WARN'] # Exclude files. A list of regular expressions to match. Filebeat drops the files that # are matching any regular expression from the list. By default, no files are dropped. #exclude_files: ['.gz$'] # Optional additional fields. These fields can be freely picked # to add additional information to the crawled log files for filtering #fields: # level: debug # review: 1 ### Multiline options # Multiline can be used for log messages spanning multiple lines. This is common # for Java Stack Traces or C-Line Continuation # The regexp Pattern that has to be matched. The example pattern matches all lines starting with [ #multiline.pattern: ^\[ # Defines if the pattern set under pattern should be negated or not. Default is false. #multiline.negate: false # Match can be set to "after" or "before". It is used to define if lines should be append to a pattern # that was (not) matched before or after or as long as a pattern is not matched based on negate. # Note: After is the equivalent to previous and before is the equivalent to to next in Logstash #multiline.match: after #============================= Filebeat modules =============================== filebeat.config.modules: # Glob pattern for configuration loading path: ${path.config}/modules.d/*.yml # Set to true to enable config reloading reload.enabled: false # Period on which files under path should be checked for changes #reload.period: 10s #==================== Elasticsearch template setting ========================== setup.template.settings: index.number_of_shards: 1 #index.codec: best_compression #_source.enabled: false #================================ General ===================================== # The name of the shipper that publishes the network data. It can be used to group # all the transactions sent by a single shipper in the web interface. #name: # The tags of the shipper are included in their own field with each # transaction published. #tags: ["service-X", "web-tier"] # Optional fields that you can specify to add additional information to the # output. #fields: # env: staging #============================== Dashboards ===================================== # These settings control loading the sample dashboards to the Kibana index. Loading # the dashboards is disabled by default and can be enabled either by setting the # options here or by using the `setup` command. #setup.dashboards.enabled: false # The URL from where to download the dashboards archive. By default this URL # has a value which is computed based on the Beat name and version. For released # versions, this URL points to the dashboard archive on the artifacts.elastic.co # website. #setup.dashboards.url: #============================== Kibana ===================================== # Starting with Beats version 6.0.0, the dashboards are loaded via the Kibana API. # This requires a Kibana endpoint configuration. setup.kibana: # Kibana Host # Scheme and port can be left out and will be set to the default (http and 5601) # In case you specify and additional path, the scheme is required: http://localhost:5601/path # IPv6 addresses should always be defined as: https://[2001:db8::1]:5601 #host: "localhost:5601" # Kibana Space ID # ID of the Kibana Space into which the dashboards should be loaded. By default, # the Default Space will be used. #space.id: #============================= Elastic Cloud ================================== # These settings simplify using Filebeat with the Elastic Cloud (https://cloud.elastic.co/). # The cloud.id setting overwrites the `output.elasticsearch.hosts` and # `setup.kibana.host` options. # You can find the `cloud.id` in the Elastic Cloud web UI. #cloud.id: # The cloud.auth setting overwrites the `output.elasticsearch.username` and # `output.elasticsearch.password` settings. The format is `<user>:<pass>`. #cloud.auth: #================================ Outputs ===================================== # Configure what output to use when sending the data collected by the beat. #-------------------------- Elasticsearch output ------------------------------ #output.elasticsearch: # Array of hosts to connect to. #hosts: ["localhost:9200"] # Optional protocol and basic auth credentials. #protocol: "https" #username: "elastic" #password: "changeme" #----------------------------- Logstash output -------------------------------- output.logstash: # The Logstash hosts hosts: ["localhost:5044"] # Optional SSL. By default is off. # List of root certificates for HTTPS server verifications #ssl.certificate_authorities: ["/etc/pki/root/ca.pem"] # Certificate for SSL client authentication #ssl.certificate: "/etc/pki/client/cert.pem" # Client Certificate Key #ssl.key: "/etc/pki/client/cert.key" #================================ Processors ===================================== # Configure processors to enhance or manipulate events generated by the beat. processors: - add_host_metadata: ~ - add_cloud_metadata: ~ #================================ Logging ===================================== # Sets log level. The default log level is info. # Available log levels are: error, warning, info, debug #logging.level: debug # At debug level, you can selectively enable logging only for some components. # To enable all selectors use ["*"]. Examples of other selectors are "beat", # "publish", "service". #logging.selectors: ["*"] #============================== X-Pack Monitoring =============================== # filebeat can export internal metrics to a central Elasticsearch monitoring # cluster. This requires xpack monitoring to be enabled in Elasticsearch. The # reporting is disabled by default. # Set to true to enable the monitoring reporter. #monitoring.enabled: false # Sets the UUID of the Elasticsearch cluster under which monitoring data for this # Filebeat instance will appear in the Stack Monitoring UI. If output.elasticsearch # is enabled, the UUID is derived from the Elasticsearch cluster referenced by output.elasticsearch. #monitoring.cluster_uuid: # Uncomment to send the metrics to Elasticsearch. Most settings from the # Elasticsearch output are accepted here as well. # Note that the settings should point to your Elasticsearch *monitoring* cluster. # Any setting that is not set is automatically inherited from the Elasticsearch # output configuration, so if you have the Elasticsearch output configured such # that it is pointing to your Elasticsearch monitoring cluster, you can simply # uncomment the following line. #monitoring.elasticsearch: #================================= Migration ================================== # This allows to enable 6.7 migration aliases #migration.6_to_7.enabled: true
5.4.附件filebeat.service
這個檔案是關于filebeat.service的定義
[Unit] Description=filebeat.service [Service] User=root ExecStart=/data/filebeat/filebeat-7.4.2-linux-x86_64/filebeat -e -c /data/filebeat/filebeat-7.4.2-linux-x86_64/filebeat.yml [Install] WantedBy=multi-user.target
