我需要將用于按鈕的 VisualBrush 適合整個視窗。VisualBrush 鏈接到一個影像，該影像被拉伸到整個可視化，但在視覺中，該影像開始出現在按鈕的角落。
<Button x:Name="button" HorizontalAlignment="Center" VerticalAlignment="Center" Content="Acquista ora- $23.99" FontSize="48" BorderBrush="{x:Null}">
<Button.Background>
<VisualBrush Visual="{Binding ElementName=img}" Stretch="None" AlignmentX="Center" AlignmentY="Center" ViewboxUnits="RelativeToBoundingBox" ViewportUnits="RelativeToBoundingBox" />
</Button.Background>
</Button>
我能怎么做？提前致謝。
uj5u.com熱心網友回復：
如果想要模糊后面的影像Button（或一般的透明控制元件），您必須遵循不同的方法。
您需要影像的確切平鋪，以便使用BlurEffect.
為了不模糊Button本身，您必須在應用的按鈕下方添加圖層BlurEffect。
下面的示例擴展了一個ContentControlnamed BlurHost，它在一個元素的頂部呈現Content例如，the Button，該Border元素實際上會使用VisualBrush.
畫筆本身定義了一個磁貼，該磁貼位于BlurHost承載Button（或任何其他透明控制元件）的位置。
實作模糊背景的基本步驟：
- 添加背景圖片
- 在元素下方創建一個模糊層
- 獲取元素的邊界，例如，相對于 Image 的父級（最好是根容器）定位的 Button
- 使用邊界矩形定義 VisualBrush 的平鋪（影像的實際部分）
- 在模糊層上應用畫筆
使用示例
主視窗.xaml
<Window>
<!-- Allow the root grid to stretch accross the Window -->
<Grid>
<Image x:Name="img" Source="/someImage.png" />
<!--
Optionally override the default BlurEffect
by setting the BlurHost.BlurEffect property
-->
<local:BlurHost BlurBackground="{Binding ElementName=img}"
BlurOpacity="1"
HorizontalAlignment="Center"
VerticalAlignment="Center">
<Button Background="Transparent"
FontSize="48"
Content="Acquista ora- $23.99" />
</local:BlurHost>
</Grid>
</Window>
實作示例
The implementation is simple. You have to add property changed handlers in order to make the control dynamic.
BlurHost.cs
The ContentControl serves as a container. The blurred background is visible at the transparent areas of the content.
public class BlurHost : ContentControl
{
public Visual BlurBackground
{
get => (Visual)GetValue(BlurBackgroundProperty);
set => SetValue(BlurBackgroundProperty, value);
}
public static readonly DependencyProperty BlurBackgroundProperty =
DependencyProperty.Register(
"BlurBackground",
typeof(Visual),
typeof(BlurHost),
new PropertyMetadata(default(Visual), OnBlurBackgroundChanged));
public double BlurOpacity
{
get => (double)GetValue(BlurOpacityProperty);
set => SetValue(BlurOpacityProperty, value);
}
public static readonly DependencyProperty BlurOpacityProperty =
DependencyProperty.Register(
"BlurOpacity",
typeof(double),
typeof(BlurHost),
new PropertyMetadata(1.0));
public BlurEffect BlurEffect
{
get => (BlurEffect)GetValue(BlurEffectProperty);
set => SetValue(BlurEffectProperty, value);
}
public static readonly DependencyProperty BlurEffectProperty =
DependencyProperty.Register(
"BlurEffect",
typeof(BlurEffect),
typeof(BlurHost),
new PropertyMetadata(
new BlurEffect()
{
Radius = 10,
KernelType = KernelType.Gaussian,
RenderingBias = RenderingBias.Performance
}));
private Border PART_BlurDecorator { get; set; }
private VisualBrush BlurDecoratorBrush { get; set; }
static BlurHost()
{
DefaultStyleKeyProperty.OverrideMetadata(typeof(BlurHost), new FrameworkPropertyMetadata(typeof(BlurHost)));
}
public BlurHost()
{
Loaded = onl oaded;
// TODO::Update Opacity of VisualBrush when property BlurOpacity changes
this.BlurDecoratorBrush = new VisualBrush()
{
ViewboxUnits = BrushMappingMode.Absolute,
Opacity = this.BlurOpacity
};
}
private void DrawBlurredElementBackground()
{
if (!TryFindVisualRootContainer(this, out FrameworkElement rootContainer))
{
return;
}
// Get the section of the image where the BlurHost element is located
Rect elementBounds = TransformToVisual(rootContainer)
.TransformBounds(new Rect(this.RenderSize));
// Use the section bounds to actually "cut out" the image tile
this.BlurDecoratorBrush.Viewbox = elementBounds;
}
private void OnLoaded(object sender, RoutedEventArgs e)
{
if (TryFindVisualRootContainer(this, out FrameworkElement rootContainer))
{
rootContainer.SizeChanged = OnRootContainerElementResized;
}
DrawBlurredElementBackground();
}
public override void OnApplyTemplate()
{
base.OnApplyTemplate();
this.PART_BlurDecorator = GetTemplateChild("PART_BlurDecorator") as Border;
this.PART_BlurDecorator.Effect = this.BlurEffect;
this.PART_BlurDecorator.Background = this.BlurDecoratorBrush;
}
private static void OnBlurBackgroundChanged(DependencyObject d, DependencyPropertyChangedEventArgs e)
{
var this_ = d as BlurHost;
this_.BlurDecoratorBrush.Visual = e.NewValue as Visual;
this_.DrawBlurredElementBackground();
}
private void OnRootContainerElementResized(object sender, SizeChangedEventArgs e)
=> DrawBlurredElementBackground();
private bool TryFindVisualRootContainer(DependencyObject child, out FrameworkElement rootContainerElement)
{
rootContainerElement = null;
DependencyObject parent = VisualTreeHelper.GetParent(child);
if (parent == null)
{
return false;
}
if (parent is not Window visualRoot)
{
return TryFindVisualRootContainer(parent, out rootContainerElement);
}
rootContainerElement = visualRoot.Content as FrameworkElement;
return true;
}
}
Generic.xaml
The default Style for the BlurHost. The Generic.xaml file is located in the Themes folder of the application (project).
<ResourceDictionary xmlns="http://schemas.microsoft.com/winfx/2006/xaml/presentation"
xmlns:x="http://schemas.microsoft.com/winfx/2006/xaml"
xmlns:local="clr-namespace:Net.Wpf">
<Style TargetType="local:BlurHost">
<Setter Property="Template">
<Setter.Value>
<ControlTemplate TargetType="local:BlurHost">
<Grid>
<!-- Blur layer beneath the hosted element (ContentPresenter) -->
<Border x:Name="PART_BlurDecorator"
BorderBrush="{TemplateBinding BorderBrush}"
BorderThickness="{TemplateBinding BorderThickness}"/>
<ContentPresenter />
</Grid>
</ControlTemplate>
</Setter.Value>
</Setter>
</Style>
</ResourceDictionary>
