前言

在作業中是否會遇到實用websocket客戶端連接服務端的時候，網路波動，服務端斷連的情況，會導致客戶端被動斷開連接，為了解決這個問題，需要對被動斷開連接的情況進行捕獲，并重新創建連接，這篇文章主要是提供可以直接使用的斷線重連websocket客戶端代碼，

Maven依賴

        <dependency>
            <groupId>org.projectlombok</groupId>
            <artifactId>lombok</artifactId>
            <optional>true</optional>
        </dependency>
        <dependency>
            <groupId>cn.hutool</groupId>
            <artifactId>hutool-all</artifactId>
            <version>5.5.2</version>
        </dependency>
        <dependency>
            <groupId>org.java-websocket</groupId>
            <artifactId>Java-WebSocket</artifactId>
            <version>1.5.1</version>
        </dependency>

代碼

不廢話，上代碼，

package ai.guiji.csdn.ws.client;

import cn.hutool.core.thread.ThreadUtil;
import cn.hutool.core.util.StrUtil;
import lombok.extern.slf4j.Slf4j;
import org.java_websocket.WebSocket;
import org.java_websocket.client.WebSocketClient;
import org.java_websocket.framing.Framedata;
import org.java_websocket.handshake.ServerHandshake;

import javax.net.ssl.*;
import java.net.Socket;
import java.net.URI;
import java.nio.ByteBuffer;
import java.security.cert.CertificateException;
import java.security.cert.X509Certificate;
import java.util.concurrent.TimeUnit;
import java.util.concurrent.atomic.AtomicBoolean;
import java.util.concurrent.atomic.AtomicInteger;
import java.util.function.Consumer;

/** @Author huyi @Date 2021/10/15 20:03 @Description: 重連websocket客戶端 */
@Slf4j
public class ReConnectWebSocketClient {
  /** 字串訊息回呼 */
  private Consumer<String> msgStr;
  /** 位元組流訊息回呼 */
  private Consumer<ByteBuffer> msgByte;
  /** 例外回呼 */
  private Consumer<Exception> error;
  /** 連接標識 */
  private String key;
  /** ws服務端連接 */
  private URI serverUri;
  /** 嘗試重連標識 */
  private AtomicBoolean tryReconnect;
  /** 需要ping標識 */
  private AtomicBoolean needPing;
  /** websocket連接物體 */
  private WebSocketClient webSocketClient;
  /** 重連次數 */
  private AtomicInteger reConnectTimes;
  /** 連接結束標識 */
  private AtomicBoolean end;
  /** 連接后初始發送報文，這里也可以不需要，如果服務端主動斷開連接，重連后可以繼續推送報文的話， */
  private String initReConnectReq;
  /** 結束回呼 */
  private Consumer<String> endConsumer;

  public ReConnectWebSocketClient(
      URI serverUri,
      String key,
      Consumer<String> msgStr,
      Consumer<ByteBuffer> msgByte,
      Consumer<Exception> error) {
    this.msgStr = msgStr;
    this.msgByte = msgByte;
    this.error = error;
    this.key = key;
    this.serverUri = serverUri;
    this.tryReconnect = new AtomicBoolean(false);
    this.needPing = new AtomicBoolean(true);
    this.reConnectTimes = new AtomicInteger(0);
    this.end = new AtomicBoolean(false);
    this.endConsumer = this::close;
    init();
  }

  /** 初始化連接 */
  public void init() {
    // 創建連接
    createWebSocketClient();
    // ping執行緒
    circlePing();
  }

  private void needReconnect() throws Exception {
    ThreadUtil.sleep(10, TimeUnit.SECONDS);
    int cul = reConnectTimes.incrementAndGet();
    if (cul > 3) {
      close("real stop");
      throw new Exception("服務端斷連，3次重連均失敗");
    }
    log.warn("[{}]第[{}]次斷開重連", key, cul);
    if (tryReconnect.get()) {
      log.error("[{}]第[{}]次斷開重連結果 -> 連接正在重連，本次重連請求放棄", key, cul);
      needReconnect();
      return;
    }
    try {
      tryReconnect.set(true);

      if (webSocketClient.isOpen()) {
        log.warn("[{}]第[{}]次斷開重連，關閉舊連接", key, cul);
        webSocketClient.closeConnection(2, "reconnect stop");
      }
      webSocketClient = null;
      createWebSocketClient();
      connect();
      if (StrUtil.hasBlank(initReConnectReq)) {
        send(initReConnectReq);
      }
    } catch (Exception exception) {
      log.error("[{}]第[{}]次斷開重連結果 -> 連接正在重連，重連例外:[{}]", key, cul, exception.getMessage());
      needReconnect();
    } finally {
      tryReconnect.set(false);
    }
  }

  private void createWebSocketClient() {
    webSocketClient =
        new WebSocketClient(serverUri) {
          @Override
          public void onOpen(ServerHandshake serverHandshake) {
            log.info("[{}]ReConnectWebSocketClient [onOpen]連接成功{}", key, getRemoteSocketAddress());
            tryReconnect.set(false);
          }

          @Override
          public void onMessage(String text) {
            log.info("[{}]ReConnectWebSocketClient [onMessage]接收到服務端資料：text={}", key, text);
            msgStr.accept(text);
          }

          @Override
          public void onMessage(ByteBuffer bytes) {
            log.info("[{}]ReConnectWebSocketClient [onMessage]接收到服務端資料：bytes={}", key, bytes);
            msgByte.accept(bytes);
          }

          @Override
          public void onWebsocketPong(WebSocket conn, Framedata f) {
            log.info(
                "[{}]ReConnectWebSocketClient [onWebsocketPong]接收到服務端資料：opcode={}",
                key,
                f.getOpcode());
          }

          @Override
          public void onClose(int i, String s, boolean b) {
            log.info("[{}]ReConnectWebSocketClient [onClose]關閉，s={}，b={}", key, s, b);
            if (StrUtil.hasBlank(s) || s.contains("https")) {
              if (end.get()) {
                return;
              }
              try {
                needReconnect();
              } catch (Exception exception) {
                endConsumer.accept("reconnect error");
                error.accept(exception);
              }
            }
          }

          @Override
          public void one rror(Exception e) {
            log.info("[{}]ReConnectWebSocketClient [onError]例外，e={}", key, e);
            endConsumer.accept("error close");
            error.accept(e);
          }
        };
    if (serverUri.toString().contains("wss://")) {
      trustAllHosts(webSocketClient);
    }
  }

  public void circlePing() {
    new Thread(
            () -> {
              while (needPing.get()) {
                if (webSocketClient.isOpen()) {
                  webSocketClient.sendPing();
                }
                ThreadUtil.sleep(5, TimeUnit.SECONDS);
              }
              log.warn("[{}]Ping回圈關閉", key);
            })
        .start();
  }

  /**
   * 連接
   *
   * @throws Exception 例外
   */
  public void connect() throws Exception {
    webSocketClient.connectBlocking(10, TimeUnit.SECONDS);
  }

  /**
   * 發送
   *
   * @param msg 訊息
   * @throws Exception 例外
   */
  public void send(String msg) throws Exception {
    this.initReConnectReq = msg;
    if (webSocketClient.isOpen()) {
      webSocketClient.send(msg);
    }
  }

  /**
   * 關閉
   *
   * @param msg 關閉訊息
   */
  public void close(String msg) {
    needPing.set(false);
    end.set(true);
    if (webSocketClient != null) {
      webSocketClient.closeConnection(3, msg);
    }
  }

  /**
   * 忽略證書
   *
   * @param client
   */
  public void trustAllHosts(WebSocketClient client) {
    TrustManager[] trustAllCerts =
        new TrustManager[] {
          new X509ExtendedTrustManager() {

            @Override
            public void checkClientTrusted(
                X509Certificate[] x509Certificates, String s, Socket socket)
                throws CertificateException {}

            @Override
            public void checkServerTrusted(
                X509Certificate[] x509Certificates, String s, Socket socket)
                throws CertificateException {}

            @Override
            public void checkClientTrusted(
                X509Certificate[] x509Certificates, String s, SSLEngine sslEngine)
                throws CertificateException {}

            @Override
            public void checkServerTrusted(
                X509Certificate[] x509Certificates, String s, SSLEngine sslEngine)
                throws CertificateException {}

            @Override
            public void checkClientTrusted(X509Certificate[] x509Certificates, String s)
                throws CertificateException {}

            @Override
            public void checkServerTrusted(X509Certificate[] x509Certificates, String s)
                throws CertificateException {}

            @Override
            public X509Certificate[] getAcceptedIssuers() {
              return null;
            }
          }
        };

    try {
      SSLContext ssl = SSLContext.getInstance("SSL");
      ssl.init(null, trustAllCerts, new java.security.SecureRandom());
      SSLSocketFactory socketFactory = ssl.getSocketFactory();
      client.setSocketFactory(socketFactory);
    } catch (Exception e) {
      log.error("ReConnectWebSocketClient trustAllHosts 例外，e={0}", e);
    }
  }

}

代碼說明：

1、參數的重連次數可以配置，

2、增加異步pingpong執行緒，一旦結束連接會自動關閉，

3、對字串、位元組流、例外都有回呼措施，

測驗代碼方法

  public static void main(String[] args) throws Exception {
    ReConnectWebSocketClient client =
        new ReConnectWebSocketClient(
            new URI(String.format("wss://192.168.1.77:24009")),
            "test",
            // 字串訊息處理
            msg -> {
              // todo 字串訊息處理
              System.out.println("字串訊息:" + msg);
            },
            null,
            // 例外回呼
            error -> {
              // todo 字串訊息處理
              System.out.println("例外:" + error.getMessage());
            });
    client.connect();
    client.send("haha");
  }

驗證結果

16:08:54.468 [WebSocketConnectReadThread-12] INFO ai.guiji.csdn.ws.client.ReConnectWebSocketClient - [test]ReConnectWebSocketClient [onOpen]連接成功/192.168.1.77:24009
16:08:54.475 [WebSocketConnectReadThread-12] INFO ai.guiji.csdn.ws.client.ReConnectWebSocketClient - [test]ReConnectWebSocketClient [onMessage]接收到服務端資料：text=connect success from tcp4:192.168.6.63:11018!
字串訊息:connect success from tcp4:192.168.6.63:11018!
16:08:56.080 [WebSocketConnectReadThread-12] INFO ai.guiji.csdn.ws.client.ReConnectWebSocketClient - [test]ReConnectWebSocketClient [onClose]關閉，s=，b=true
16:09:06.097 [WebSocketConnectReadThread-12] WARN ai.guiji.csdn.ws.client.ReConnectWebSocketClient - [test]第[1]次斷開重連
16:09:06.150 [WebSocketConnectReadThread-16] INFO ai.guiji.csdn.ws.client.ReConnectWebSocketClient - [test]ReConnectWebSocketClient [onOpen]連接成功/192.168.1.77:24009
16:09:06.150 [WebSocketConnectReadThread-16] INFO ai.guiji.csdn.ws.client.ReConnectWebSocketClient - [test]ReConnectWebSocketClient [onMessage]接收到服務端資料：text=connect success from tcp4:192.168.6.63:11038!
字串訊息:connect success from tcp4:192.168.6.63:11038!
16:09:09.369 [WebSocketConnectReadThread-16] INFO ai.guiji.csdn.ws.client.ReConnectWebSocketClient - [test]ReConnectWebSocketClient [onWebsocketPong]接收到服務端資料：opcode=PONG
16:09:14.370 [WebSocketConnectReadThread-16] INFO ai.guiji.csdn.ws.client.ReConnectWebSocketClient - [test]ReConnectWebSocketClient [onWebsocketPong]接收到服務端資料：opcode=PONG
16:09:19.371 [WebSocketConnectReadThread-16] INFO ai.guiji.csdn.ws.client.ReConnectWebSocketClient - [test]ReConnectWebSocketClient [onWebsocketPong]接收到服務端資料：opcode=PONG
16:09:24.379 [WebSocketConnectReadThread-16] INFO ai.guiji.csdn.ws.client.ReConnectWebSocketClient - [test]ReConnectWebSocketClient [onWebsocketPong]接收到服務端資料：opcode=PONG
16:09:29.382 [WebSocketConnectReadThread-16] INFO ai.guiji.csdn.ws.client.ReConnectWebSocketClient - [test]ReConnectWebSocketClient [onWebsocketPong]接收到服務端資料：opcode=PONG
16:09:34.398 [WebSocketConnectReadThread-16] INFO ai.guiji.csdn.ws.client.ReConnectWebSocketClient - [test]ReConnectWebSocketClient [onWebsocketPong]接收到服務端資料：opcode=PONG
16:09:39.402 [WebSocketConnectReadThread-16] INFO ai.guiji.csdn.ws.client.ReConnectWebSocketClient - [test]ReConnectWebSocketClient [onWebsocketPong]接收到服務端資料：opcode=PONG
16:09:44.404 [WebSocketConnectReadThread-16] INFO ai.guiji.csdn.ws.client.ReConnectWebSocketClient - [test]ReConnectWebSocketClient [onWebsocketPong]接收到服務端資料：opcode=PONG
16:09:49.415 [WebSocketConnectReadThread-16] INFO ai.guiji.csdn.ws.client.ReConnectWebSocketClient - [test]ReConnectWebSocketClient [onWebsocketPong]接收到服務端資料：opcode=PONG
16:09:54.429 [WebSocketConnectReadThread-16] INFO ai.guiji.csdn.ws.client.ReConnectWebSocketClient - [test]ReConnectWebSocketClient [onWebsocketPong]接收到服務端資料：opcode=PONG
16:09:59.437 [WebSocketConnectReadThread-16] INFO ai.guiji.csdn.ws.client.ReConnectWebSocketClient - [test]ReConnectWebSocketClient [onWebsocketPong]接收到服務端資料：opcode=PONG
16:10:04.449 [WebSocketConnectReadThread-16] INFO ai.guiji.csdn.ws.client.ReConnectWebSocketClient - [test]ReConnectWebSocketClient [onWebsocketPong]接收到服務端資料：opcode=PONG
16:10:06.154 [WebSocketConnectReadThread-16] INFO ai.guiji.csdn.ws.client.ReConnectWebSocketClient - [test]ReConnectWebSocketClient [onWebsocketPong]接收到服務端資料：opcode=PONG
16:10:09.455 [WebSocketConnectReadThread-16] INFO ai.guiji.csdn.ws.client.ReConnectWebSocketClient - [test]ReConnectWebSocketClient [onWebsocketPong]接收到服務端資料：opcode=PONG
16:10:14.462 [WebSocketConnectReadThread-16] INFO ai.guiji.csdn.ws.client.ReConnectWebSocketClient - [test]ReConnectWebSocketClient [onWebsocketPong]接收到服務端資料：opcode=PONG
16:10:19.468 [WebSocketConnectReadThread-16] INFO ai.guiji.csdn.ws.client.ReConnectWebSocketClient - [test]ReConnectWebSocketClient [onWebsocketPong]接收到服務端資料：opcode=PONG
16:10:19.644 [WebSocketConnectReadThread-16] INFO ai.guiji.csdn.ws.client.ReConnectWebSocketClient - [test]ReConnectWebSocketClient [onClose]關閉，s=，b=true
16:10:29.654 [WebSocketConnectReadThread-16] WARN ai.guiji.csdn.ws.client.ReConnectWebSocketClient - [test]第[2]次斷開重連
16:10:31.710 [WebSocketConnectReadThread-19] INFO ai.guiji.csdn.ws.client.ReConnectWebSocketClient - [test]ReConnectWebSocketClient [onError]例外，e={}
java.net.ConnectException: Connection refused: connect
	at java.net.DualStackPlainSocketImpl.connect0(Native Method)
	at java.net.DualStackPlainSocketImpl.socketConnect(DualStackPlainSocketImpl.java:79)
	at java.net.AbstractPlainSocketImpl.doConnect(AbstractPlainSocketImpl.java:350)
	at java.net.AbstractPlainSocketImpl.connectToAddress(AbstractPlainSocketImpl.java:206)
	at java.net.AbstractPlainSocketImpl.connect(AbstractPlainSocketImpl.java:188)
	at java.net.PlainSocketImpl.connect(PlainSocketImpl.java:172)
	at java.net.SocksSocketImpl.connect(SocksSocketImpl.java:392)
	at java.net.Socket.connect(Socket.java:589)
	at sun.security.ssl.SSLSocketImpl.connect(SSLSocketImpl.java:673)
	at org.java_websocket.client.WebSocketClient.run(WebSocketClient.java:461)
	at java.lang.Thread.run(Thread.java:748)
16:10:31.710 [WebSocketConnectReadThread-19] INFO ai.guiji.csdn.ws.client.ReConnectWebSocketClient - [test]ReConnectWebSocketClient [onClose]關閉，s=error close，b=false
例外:Connection refused: connect
16:10:34.473 [Thread-0] WARN ai.guiji.csdn.ws.client.ReConnectWebSocketClient - [test]Ping回圈關閉

這里我才用的是手動關閉服務端方式觸發，客戶端被動斷連情況，重連兩次，第二次服務端還未啟動導致例外觸發，

總結

沒啥好總結的，代碼注釋比較清楚，

如果對你有用，一健三連走一波！
