Flink Sql 自定義實作 kudu connector

原理
實作

眾所周知啊，flinksql 中與其他的存盤做資料的傳輸連接的時候，是需要有獨特的連接器的，mysql redis es hbase kudu ，不同的存盤他們自己使用的協議與操作都不一樣，所以需要相應的連接器來連接，這個帖子主要講一下怎么實作自定義的flink sql connector ，不只局限于kudu ，其他的連接器都是這個原理

原理

其實原理跟從網上下載的 mysql連接器一樣，打包編譯，添加好pom檔案，sql決議時，會根據程式中配置的connector 來做判斷是那種決議器，然后與pom中引入的決議器做匹配，

那么具體要如何開發引入一個connector呢？

簡單來說需要三個東西
sink類實體： KuduDynamicTableSink
工廠類： KuduDynamicTableFactory
以及一個組態檔：org.apache.flink.table.factories.Factory

其實主要利用了java的SPI原理，用戶需要在工程的resources中新建一個檔案
在這里插入圖片描述
這里放什么呢，放的是用戶開發的工廠類的地址
com.datacenter.connectors.kudu.table.KuduDynamicTableFactory
原因就是，SPI會從這個檔案中找到工廠類，然后由工廠類來構造出sink實體供sql決議出的物件使用

實作

KuduDynamicTableSink：

package com.datacenter.streaming.sql.connectors.kudu.table;

import com.datacenter.streaming.sql.connectors.kudu.KuduOptions;
import com.datacenter.streaming.sql.connectors.kudu.KuduOutputFormat;
import com.datacenter.streaming.sql.connectors.kudu.KuduSinkOptions;
import org.apache.flink.table.api.TableSchema;
import org.apache.flink.table.api.constraints.UniqueConstraint;
import org.apache.flink.table.connector.ChangelogMode;
import org.apache.flink.table.connector.sink.DynamicTableSink;
import org.apache.flink.table.connector.sink.OutputFormatProvider;
import org.apache.flink.types.RowKind;

import java.util.List;

import static org.apache.flink.util.Preconditions.checkState;

/**
 * KuduDynamicTableSink
 * @author loveyou
 */
public class KuduDynamicTableSink implements DynamicTableSink {

    private final KuduOptions kuduOptions;
    private final KuduSinkOptions kuduSinkOptions;
    private TableSchema physicalSchema;
    private int bufferFlushInterval;
    private int maxRetries;

    private List<String> keyFields;

    public KuduDynamicTableSink(KuduOptions kuduOptions, KuduSinkOptions kuduSinkOptions, TableSchema physicalSchema) {
        this.kuduOptions = kuduOptions;
        this.kuduSinkOptions = kuduSinkOptions;
        this.physicalSchema = physicalSchema;
        UniqueConstraint uniqueConstraint = physicalSchema.getPrimaryKey().orElse(null);
        if (uniqueConstraint != null) {
            this.keyFields = uniqueConstraint.getColumns();
        }
        this.bufferFlushInterval = (int) kuduSinkOptions.getBatchIntervalMs();
        this.maxRetries = kuduSinkOptions.getMaxRetries();
    }

    @Override
    public ChangelogMode getChangelogMode(ChangelogMode requestedMode) {
        validatePrimaryKey(requestedMode);
        return ChangelogMode.newBuilder()
                .addContainedKind(RowKind.INSERT)
                .addContainedKind(RowKind.UPDATE_AFTER)
                .build();
    }

    @Override
    public SinkRuntimeProvider getSinkRuntimeProvider(Context context) {
        KuduOutputFormat kuduOutputFormat = new KuduOutputFormat(
                kuduOptions.getMaster(),
                kuduOptions.getTable(),
                physicalSchema.getFieldNames(),
                physicalSchema.getFieldDataTypes(),
                bufferFlushInterval,
                maxRetries
        );

        return OutputFormatProvider.of(kuduOutputFormat);
    }

    @Override
    public DynamicTableSink copy() {
        return new KuduDynamicTableSink(
                kuduOptions,
                kuduSinkOptions,
                physicalSchema);
    }

    @Override
    public String asSummaryString() {
        return null;
    }

    private void validatePrimaryKey(ChangelogMode requestedMode) {
        checkState(ChangelogMode.insertOnly().equals(requestedMode) || keyFields == null,
                "please declare primary key for sink table when query contains update/delete record.");
    }
}

package com.datacenter.streaming.sql.connectors.kudu.table;

import com.datacenter.streaming.sql.connectors.kudu.KuduLookupOptions;
import com.datacenter.streaming.sql.connectors.kudu.KuduOptions;
import com.datacenter.streaming.sql.connectors.kudu.KuduSinkOptions;
import org.apache.flink.configuration.ConfigOption;
import org.apache.flink.configuration.ConfigOptions;
import org.apache.flink.configuration.ReadableConfig;
import org.apache.flink.table.api.TableSchema;
import org.apache.flink.table.connector.sink.DynamicTableSink;
import org.apache.flink.table.connector.source.DynamicTableSource;
import org.apache.flink.table.factories.DynamicTableSinkFactory;
import org.apache.flink.table.factories.DynamicTableSourceFactory;
import org.apache.flink.table.factories.FactoryUtil;
import org.apache.flink.table.utils.TableSchemaUtils;
import org.apache.flink.util.Preconditions;

import java.time.Duration;
import java.util.Arrays;
import java.util.HashSet;
import java.util.Set;

/**
 * KuduDynamicTableFactory
 * @author loveyou
 */
public class KuduDynamicTableFactory implements DynamicTableSourceFactory, DynamicTableSinkFactory {

    // common options
    public static final String IDENTIFIER = "kudu";
    public static final ConfigOption<String> MASTER = ConfigOptions
            .key("master")
            .stringType()
            .noDefaultValue()
            .withDescription("the kudu master address.");
    public static final ConfigOption<String> TABLE = ConfigOptions
            .key("table")
            .stringType()
            .noDefaultValue()
            .withDescription("the jdbc table name.");
    public static final ConfigOption<String> USERNAME = ConfigOptions
            .key("username")
            .stringType()
            .noDefaultValue()
            .withDescription("the jdbc user name.");
    public static final ConfigOption<String> PASSWORD = ConfigOptions
            .key("password")
            .stringType()
            .noDefaultValue()
            .withDescription("the jdbc password.");


    // lookup options
    private static final ConfigOption<Long> LOOKUP_CACHE_MAX_ROWS = ConfigOptions
            .key("lookup.cache.max-rows")
            .longType()
            .defaultValue(-1L)
            .withDescription("the max number of rows of lookup cache, over this value, the oldest rows will " +
                    "be eliminated. \"cache.max-rows\" and \"cache.ttl\" options must all be specified if any of them is " +
                    "specified. Cache is not enabled as default.");
    private static final ConfigOption<Duration> LOOKUP_CACHE_TTL = ConfigOptions
            .key("lookup.cache.ttl")
            .durationType()
            .defaultValue(Duration.ofSeconds(-1))
            .withDescription("the cache time to live.");
    private static final ConfigOption<Integer> LOOKUP_MAX_RETRIES = ConfigOptions
            .key("lookup.max-retries")
            .intType()
            .defaultValue(3)
            .withDescription("the max retry times if lookup database failed.");

    // write options
    //private static final ConfigOption<Integer> SINK_BUFFER_FLUSH_MAX_ROWS = ConfigOptions
    //        .key("sink.buffer-flush.max-rows")
    //        .intType()
    //        .defaultValue(100)
    //        .withDescription("the flush max size (includes all append, upsert and delete records), over this number" +
    //                " of records, will flush data. The default value is 100.");
    private static final ConfigOption<Duration> SINK_BUFFER_FLUSH_INTERVAL = ConfigOptions
            .key("sink.buffer-flush.interval")
            .durationType()
            .defaultValue(Duration.ofSeconds(1))
            .withDescription("the flush interval mills, over this time, asynchronous threads will flush data. The " +
                    "default value is 1s.");
    private static final ConfigOption<Integer> SINK_MAX_RETRIES = ConfigOptions
            .key("sink.max-retries")
            .intType()
            .defaultValue(3)
            .withDescription("the max retry times if writing records to database failed.");

    /**
     * DynamicTableSource 實體
     *
     * @param context
     * @return
     */
    @Override
    public DynamicTableSource createDynamicTableSource(Context context) {
        final FactoryUtil.TableFactoryHelper helper = FactoryUtil.createTableFactoryHelper(this, context);
        final ReadableConfig config = helper.getOptions();
        helper.validate();
        validateConfigOptions(config);
        TableSchema physicalSchema = TableSchemaUtils.getPhysicalSchema(context.getCatalogTable().getSchema());
        return new KuduDynamicTableSource(
                getKuduOptions(helper.getOptions()),
                getKuduLookupOptions(helper.getOptions()),
                physicalSchema);
    }

    /**
     * DynamicTableSink 實體
     *
     * @param context
     * @return
     */
    @Override
    public DynamicTableSink createDynamicTableSink(Context context) {
        final FactoryUtil.TableFactoryHelper helper = FactoryUtil.createTableFactoryHelper(this, context);
        final ReadableConfig config = helper.getOptions();
        helper.validate();
        validateConfigOptions(config);
        TableSchema physicalSchema = TableSchemaUtils.getPhysicalSchema(context.getCatalogTable().getSchema());
        return new KuduDynamicTableSink(
                getKuduOptions(config),
                getKuduSinkOptions(config),
                physicalSchema);
    }

    private KuduOptions getKuduOptions(ReadableConfig readableConfig) {
        KuduOptions.KuduOptionsBuilder builder = KuduOptions.builder()
                .master(readableConfig.get(MASTER))
                .table(readableConfig.get(TABLE));
        readableConfig.getOptional(USERNAME).ifPresent(builder::username);
        readableConfig.getOptional(PASSWORD).ifPresent(builder::password);
        return builder.build();
    }

    private KuduLookupOptions getKuduLookupOptions(ReadableConfig readableConfig) {
        KuduLookupOptions.KuduLookupOptionsBuilder builder = KuduLookupOptions.builder();
        builder.cacheMaxSize(readableConfig.get(LOOKUP_CACHE_MAX_ROWS));
        builder.cacheExpireMs(readableConfig.get(LOOKUP_CACHE_TTL).toMillis());
        builder.maxRetryTimes(readableConfig.get(LOOKUP_MAX_RETRIES));

        return builder.build();
    }

    private KuduSinkOptions getKuduSinkOptions(ReadableConfig config) {
        KuduSinkOptions.KuduSinkOptionsBuilder builder = KuduSinkOptions.builder();
        //builder.batchSize(config.get(SINK_BUFFER_FLUSH_MAX_ROWS));
        builder.batchIntervalMs(config.get(SINK_BUFFER_FLUSH_INTERVAL).toMillis());
        builder.maxRetries(config.get(SINK_MAX_RETRIES));
        return builder.build();
    }


    /**
     * 工廠唯一識別符號
     *
     * @return
     */
    @Override
    public String factoryIdentifier() {
        return IDENTIFIER;
    }

    /**
     * 必選項
     *
     * @return
     */
    @Override
    public Set<ConfigOption<?>> requiredOptions() {
        Set<ConfigOption<?>> requiredOptions = new HashSet<>();
        requiredOptions.add(MASTER);
        requiredOptions.add(TABLE);
        return requiredOptions;
    }

    /**
     * 可選項
     *
     * @return
     */
    @Override
    public Set<ConfigOption<?>> optionalOptions() {
        Set<ConfigOption<?>> optionalOptions = new HashSet<>();
        optionalOptions.add(USERNAME);
        optionalOptions.add(PASSWORD);

        optionalOptions.add(LOOKUP_CACHE_MAX_ROWS);
        optionalOptions.add(LOOKUP_CACHE_TTL);
        optionalOptions.add(LOOKUP_MAX_RETRIES);

        //optionalOptions.add(SINK_BUFFER_FLUSH_MAX_ROWS);
        optionalOptions.add(SINK_BUFFER_FLUSH_INTERVAL);
        optionalOptions.add(SINK_MAX_RETRIES);
        return optionalOptions;
    }


    /**
     * 驗證配置
     *
     * @param config
     */
    private void validateConfigOptions(ReadableConfig config) {
        checkAllOrNone(config, new ConfigOption[]{
                USERNAME,
                PASSWORD
        });

        checkAllOrNone(config, new ConfigOption[]{
                LOOKUP_CACHE_MAX_ROWS,
                LOOKUP_CACHE_TTL
        });

        Preconditions.checkArgument(
                config.get(SINK_BUFFER_FLUSH_INTERVAL).compareTo(Duration.ofSeconds(1)) >= 0,
                SINK_BUFFER_FLUSH_INTERVAL.key() + " must >= 1000"
        );
    }

    /**
     * 要么一個都沒有，要么都要有
     *
     * @param config
     * @param configOptions
     */
    private void checkAllOrNone(ReadableConfig config, ConfigOption<?>[] configOptions) {
        int presentCount = 0;
        for (ConfigOption configOption : configOptions) {
            if (config.getOptional(configOption).isPresent()) {
                presentCount++;
            }
        }
        String[] propertyNames = Arrays.stream(configOptions).map(ConfigOption::key).toArray(String[]::new);
        Preconditions.checkArgument(configOptions.length == presentCount || presentCount == 0,
                "Either all or none of the following options should be provided:\n" + String.join("\n", propertyNames));
    }
}

看代碼中
呼叫工廠類，由工廠類實作的DynamicTableSinkFactory介面匯總的create方法，來回傳一個KuduDynamicTableSink 方法實體，

完成后可以把這個代碼片段拷貝進你的java專案中，在 pom中添加

<modules>
	<module>connector-kudu</module>
</modules>

或者直接打包成jar ，將jar拷貝進你的本地倉庫，像引入mysql connector一樣的方式來引如檔案
