自定義marker與infoWindow表單
1.展示地圖布局的xml
<?xml version="1.0" encoding="utf-8"?> <LinearLayout xmlns:android="http://schemas.android.com/apk/res/android" android:layout_width="match_parent" android:orientation="vertical" android:layout_height="match_parent"> <com.amap.api.maps.MapView android:id="@+id/map" android:layout_width="match_parent" android:layout_height="match_parent" /> </LinearLayout>
2.Activity自定義marker與infowindow(代碼注釋詳細)
/** * Created by YyyyQ on 2020/3/24 */ public class MainActivity extends AppCompatActivity implements AMap.OnMarkerClickListener, AMap.InfoWindowAdapter, AMap.OnMapClickListener { private MapView mapView = null; private AMap aMap; private UiSettings uiSettings; //存放所有點的經緯度 LatLngBounds.Builder boundsBuilder = new LatLngBounds.Builder(); //當前點擊的marker private Marker clickMaker; //自定義表單 View infoWindow = null; @Override protected void onCreate(Bundle savedInstanceState) { super.onCreate(savedInstanceState); setContentView(R.layout.activity_main); mapView = findViewById(R.id.map); mapView.onCreate(savedInstanceState); if (aMap == null) { aMap = mapView.getMap(); uiSettings = aMap.getUiSettings(); //設定地圖屬性 setMapAttribute(); } //模擬資料源 List<Map<String, String>> list = getData(); //循壞在地圖上添加自定義marker for (int i = 0; i < list.size(); i++) { LatLng latLng = new LatLng(Double.parseDouble(list.get(i).get("latitude")), Double.parseDouble(list.get(i).get("longitude"))); MarkerOptions markerOption = new MarkerOptions(); markerOption.position(latLng); markerOption.title(list.get(i).get("title")); markerOption.snippet(list.get(i).get("content")); //自定義點標記的icon圖示為drawable檔案下圖片 markerOption.icon(BitmapDescriptorFactory.fromBitmap(BitmapFactory.decodeResource(getResources(), R.drawable.ditu_yiliao))); markerOption.draggable(false); aMap.addMarker(markerOption); //將所有marker經緯度include到boundsBuilder中 boundsBuilder.include(latLng); } //更新地圖狀態 aMap.animateCamera(CameraUpdateFactory.newLatLngBounds(boundsBuilder.build(), 10)); } /** * 設定地圖屬性 */ private void setMapAttribute() { //設定默認縮放級別 aMap.moveCamera(CameraUpdateFactory.zoomTo(12)); //隱藏的右下角縮放按鈕 uiSettings.setZoomControlsEnabled(false); //設定marker點擊事件監聽 aMap.setOnMarkerClickListener(this); //設定自定義資訊視窗 aMap.setInfoWindowAdapter(this); //設定地圖點擊事件監聽 aMap.setOnMapClickListener(this); } /** * 模擬資料源 */ private List<Map<String, String>> getData() { List<Map<String, String>> list = new ArrayList<>(); for (int i = 1; i < 11; i++) { Map<String, String> map = new HashMap<>(); map.put("title", "標題NO." + i); map.put("content", "這是第" + i + "個marker的內容"); map.put("latitude", 43 + Math.random() + ""); map.put("longitude", 125 + Math.random() + ""); list.add(map); } return list; } /** * marker點擊事件 */ @Override public boolean onMarkerClick(Marker marker) { clickMaker = marker; //點擊當前marker展示自定義表單 marker.showInfoWindow(); //回傳true 表示介面已回應事,無需繼續傳遞 return true; } /** * 監聽自定義視窗infoWindow事件回呼 */ @Override public View getInfoWindow(Marker marker) { if (infoWindow == null) { infoWindow = LayoutInflater.from(this).inflate(R.layout.amap_info_window, null); } render(marker, infoWindow); return infoWindow; } /** * 自定義infoWindow視窗 */ private void render(Marker marker, View infoWindow) { TextView title = infoWindow.findViewById(R.id.info_window_title); TextView content = infoWindow.findViewById(R.id.info_window_content); title.setText(marker.getTitle()); content.setText(marker.getSnippet()); } /** * 不能修改整個InfoWindow的背景和邊框，回傳null */ @Override public View getInfoContents(Marker marker) { return null; } /** * 地圖點擊事件 * 點擊地圖區域讓當前展示的表單隱藏 */ @Override public void onMapClick(LatLng latLng) { //判斷當前marker資訊視窗是否顯示 if (clickMaker != null && clickMaker.isInfoWindowShown()) { clickMaker.hideInfoWindow(); } } }
3.自定義infoWindow表單布局
<?xml version="1.0" encoding="utf-8"?> <LinearLayout xmlns:android="http://schemas.android.com/apk/res/android" android:layout_width="160dp" android:layout_height="wrap_content" android:layout_gravity="center" android:background="@drawable/infowindow" android:orientation="vertical"> <!--@drawable/infowindow為.9圖--> <TextView android:id="@+id/info_window_title" android:layout_width="match_parent" android:layout_height="wrap_content" android:gravity="center" android:padding="5dp" android:textColor="#333" android:textSize="14sp" /> <TextView android:id="@+id/info_window_content" android:layout_width="match_parent" android:layout_height="wrap_content" android:gravity="center" android:padding="5dp" android:textColor="#333" android:textSize="12sp" /> </LinearLayout>
