進口耐腐蝕污水泵原理特點及品牌（圖）

作者：托馬斯·貝爾森·伍德發布時間：2021-01-16 13:03:14點擊：201

進口耐腐蝕污水泵原理特點

進口耐腐蝕污水泵由水泵、密封和電動機三部分組成，電動機位于電泵上部，為單相或三相異步電動機，水泵位于電泵下部，葉輪為多葉片旋流式結構，葉輪與渦殼底部間有寬敞的通道，能通過任何進入吸入口的雜物，水泵與電機之間采用硬質耐磨機械密封，各固定止口處采用“O”形耐油橡膠密封圈作靜密封，產品特點 1、外殼由304不銹鋼及工程塑料構成，與介質接觸的螺釘采用304不銹鋼； 2、電泵轉軸采用316不銹鋼，具有優異的耐磨性和耐腐蝕性； 3、不堵塞葉輪設計，進入吸水口的雜物可以全徑通過，不易被雜物卡死； 4、電機采用F級絕緣，內配有熱保護器，能在電泵缺相、過載、電機過熱等情況下能有效保護電機； 5、由于葉輪與渦殼間具有極為寬敞的流道空間，葉輪旋轉產生的強烈渦流能將介質中的固體顆粒直接送出渦殼而不與葉輪接觸，極大的減少了葉輪的磨損，產品用途 1、海洋養殖業、海洋船舶等海水的抽送 2、住宅區、工業廢水的排放 3、農業、水產養殖的清水抽送 4、其他場合之供排水不適用于建筑工地、礦山等場所抽送含砂粒等堅硬顆粒的介質之用，使用條件 1．水溫0~40℃ 2．水源的酸堿度PH值為4~10 3．介質密度不超過1.05×103kg/m3 4. 電源電壓：單相為220V，三相為380V，頻率50HZ，電壓波動范圍為額定值的0.9-1.1 Corrosion-resistant sewage pump consists of water pump, seal and motor three parts, the motor is located on the pump Department, for the single-phase or three-phase asynchronous motor, the pump is located in the lower part of the pump, the impeller for multi-blade swirl structure, There is a spacious passage between the impeller and the bottom of the volute, through any debris entering the suction port. Water pump and motor Between the use of hard wear-resistant mechanical seal, the fixed stop at the "O" -shaped oil-resistant rubber seal for static seal. Features 1, the shell made of 304 stainless steel and engineering plastics, and the media in contact with the screw 304 stainless steel; 2, the pump shaft with 316 stainless steel, with excellent wear resistance and corrosion resistance; 3, do not plug the impeller design, into the mouth of the debris can be the whole path through, not easy to be debris stuck; 4, the motor using F-class insulation, with a thermal protector, can be in the pump phase, overload, motor overheating, etc. Can effectively protect the motor; 5, due to the impeller and the volute between the very spacious flow channel space, the impeller rotation of the strong eddy The solid particles in the medium can be sent directly to the volute without contact with the impeller, greatly reducing the impeller wear. Product Usage 1, marine aquaculture, marine ships and other sea water pumping 2, residential areas, industrial wastewater discharge 3, agriculture, aquaculture water pumping 4, other occasions for the drainage Not suitable for construction sites, mines and other places pumping sand and other hard particles of the medium. Conditions of Use 1. Water temperature 0 ~ 40 ℃ 2. The pH value of the water source is 4 ~ 10 3. Medium density of not more than 1.05 × 103kg / m3

4. Power supply voltage: single-phase 220V, three-phase 380V, frequency 50HZ, the voltage fluctuation range of the rated 0.9-1.1

進口耐腐蝕污水泵品牌

德國托馬斯閥門集團于1933年創建于德國魯爾工業區，也是世界最重要的工業區，位于德國西部、萊茵河下游支流魯爾河與利珀河之間的地區，德國托馬斯閥門集團是以生產高品質、先進的閥門、測量及控制系統而享譽全球的跨國性生產企業，采用世界先進的設備及生產工藝，所有產品都在嚴格的質量體系監控下完成作業，并在各大洲幾十個國家擁有子公司及分支機構，上一篇：進口熱水管道泵原理特點及品牌（圖）下一篇：進口潛水污水泵原理特點及品牌（圖）相關產品
